ROAD TEST
ROAD TEST
DescriptionINFOID:0000000003806508
DESCRIPTION
 The purpose of the test is to determine the overall performance of
CVT and analyze causes of problems.
 The road test consists of the following three parts:
1. “Check Before Engine Is Started” TM-310
.
2. “Check at Idle” TM-311
.
3. “Cruise Test” TM-312
.
 Before the road test, familiarize yourself with all test procedures
and items to check.
 Perform tests for all the check items until a malfunction phenome-
non is detected. Perform diagnosis for NG items after the comple-
tion of road tests.
CONSULT-III SETTING PROCEDURE
 Using CONSULT-III, perform a cruise test and record the result.
 Print the result and ensure that shifts and lock-ups take place as per Shift Schedule.
1. Touch “Data Monitor” on “Direct Diagnostic Mode” screen.
2. Touch “MAIN SIGNALS” to set recording condition.
3. See “Numerical Display”, “Barchart Display” or “Line Graph Display”.
4. Touch “START”.
5. When performing cruise test. Refer to TM-312, "
Cruise Test".
6. After finishing cruise test part, touch “RECORD”.
7. Touch “STORE”.
8. Touch “BACK”.
9. Touch “DISPLAY”.
10. Touch “PRINT”.
11. Check the monitor data printed out.
Check before Engine Is StartedINFOID:0000000003806509
1.CHECK SHIFT POSITION INDICATOR
1. Park vehicle on flat surface.
2. Move selector lever to “P” position.
3. Turn ignition switch OFF. Wait at least 5 seconds.
4. Turn ignition switch ON. (Never start engine.)
Has shift position indicator been turned ON for about 2 seconds?
YES >> 1. Turn ignition switch OFF.
2. Perform self-diagnosis and note NG items.
Refer to TM-204, "
CONSULT-III Function (TRANSMISSION)".
3. Go to TM-311, "
Check at Idle".
SAT786A
SAT496G

ROAD TEST
TM-311
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
NO >> Stop “Road Test”. Refer to TM-286, "Symptom Table".
Check at IdleINFOID:0000000003806510
1.CHECK STARTING THE ENGINE
1. Park vehicle on flat surface.
2. Move selector lever to “P” or “N” position.
3. Turn ignition switch OFF.
4. Turn ignition switch to “START” position.
Is engine started?
YES >> GO TO 2.
NO >> Stop “Road Test”. Refer to TM-286, "
Symptom Table".
2.CHECK STARTING THE ENGINE
1. Turn ignition switch ON.
2. Move selector lever to “D”, “L” or “R” position.
3. Turn ignition switch to “START” position.
Is engine started?
YES >> Stop “Road Test”. Refer to TM-286, "Symptom Table".
NO >> GO TO 3.
3.CHECK “P” POSITION FUNCTION
1. Move selector lever to “P” position.
2. Turn ignition switch OFF.
3. Release parking brake.
4. Push vehicle forward or backward.
5. Apply parking brake.
Does vehicle move forward or backward?
YES >> Refer to TM-286, "Symptom Table". GO TO 4.
NO >> GO TO 4.
4.CHECK “N” POSITION FUNCTION
1. Start engine.
2. Move selector lever to “N” position.
3. Release parking brake.
Does vehicle move forward or backward?
YES >> Refer to TM-286, "Symptom Table". GO TO 5.
NO >> GO TO 5.
5.CHECK SHIFT SHOCK
1. Apply foot brake.
2. Move selector lever to “R” position.
Is there large shock when changing from
“N” to “R” position?
YES >> Refer to TM-286, "Symptom Table". GO TO 6.
NO >> GO TO 6.
6.CHECK “R” POSITION FUNCTION
Release foot brake for several seconds.
Does vehicle creep backward when foot brake is released?
YES >> GO TO 7.
NO >> Refer to TM-286, "
Symptom Table". GO TO 7.
7.CHECK “D” POSITION FUNCTION
Move selector lever to “D” position and check if vehicle creeps forward.
Does vehicle creep forward in all positions?
YES >> Go to TM-312, "Cruise Test".
NO >> Stop “Road Test”. Refer to TM-286, "
Symptom Table".

TM-312
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
ROAD TEST
Cruise Test
INFOID:0000000003806511
1.CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 1
1. Drive vehicle for approximately 10 minutes to warm engine oil and CVT fluid up to operating temperature.
2. Park vehicle on flat surface.
3. Move selector lever to “P” position.
4. Start engine.
5. Move selector lever to “D” position.
6. Accelerate vehicle at 2/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Is the inspection results normal?
YES >> GO TO 2.
NO >> Refer to TM-286, "
Symptom Table". GO TO 2.
2.CHECK VEHICLE SPEED WHEN SHIFTING GEARS — PART 2
1. Park vehicle on flat surface.
2. Move selector lever to “D” position.
3. Accelerate vehicle at 8/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Is the inspection results normal?
YES >> GO TO 3.
NO >> Refer to TM-286, "
Symptom Table". GO TO 3.
3.CHECK SPORT MODE CONDITION (PART 1)
1. Park vehicle on flat surface.
2. Push sport mode switch. (Sport mode ON.)
3. Accelerate vehicle at 2/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Is the inspection results normal?
YES >> GO TO 4.
NO >> Refer to TM-286, "
Symptom Table". GO TO 4.
4.CHECK SPORT MODE CONDITION (PART 2)
1. Park vehicle on flat surface.CVT fluid operating temperature : 50 – 80°C (122 – 176°F)
SCIA6644E
SCIA4366E
SCIA6644E

ROAD TEST
TM-313
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Accelerate vehicle at 8/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Is the inspection results normal?
YES >> GO TO 5.
NO >> Refer to TM-286, "
Symptom Table". GO TO 5.
5.CHECK “L” POSITION FUNCTION (PART 1)
1. Park vehicle on flat surface.
2. Move selector lever to “L” position.
3. Accelerate vehicle at 2/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Is the inspection results normal?
YES >> GO TO 6.
NO >> Refer to TM-286, "
Symptom Table". GO TO 6.
6.CHECK “L” POSITION FUNCTION (PART 2)
1. Park vehicle on flat surface.
2. Accelerate vehicle at 8/8 throttle opening and check “Vehicle
Speed When Shifting Gears”.
With CONSULT-III
- Read vehicle speed and engine speed. Refer to TM-337, "Vehi-
cle Speed When Shifting Gears".
Does it switch to manual mode?
YES >> GO TO 7.
NO >> Refer to TM-286, "
Symptom Table". GO TO 7.
7.CHECK ENGINE BRAKE FUNCTION
Check engine brake.
Does engine braking effectively reduce vehicle speed in
“L” position?
YES >> 1. Stop the vehicle.
2. Perform self-diagnosis. Refer to TM-204, "
CONSULT-III Function (TRANSMISSION)".
NO >> Refer to TM-286, "
Symptom Table". Then continue trouble diagnosis.
SCIA4366E
SCIA6644E
SCIA4366E

TM-314
< ON-VEHICLE MAINTENANCE >[CVT: RE0F10A]
CVT POSITION
CVT POSITION
Inspection and AdjustmentINFOID:0000000003806512
INSPECTION
1. Place selector lever in “P” position, and turn ignition switch ON (engine stop).
2. Check that selector lever can be shifted to other than “P” position when brake pedal is depressed. Also
check that selector lever can be shifted from “P” position only when brake pedal is depressed.
3. Move the selector lever and check for excessive effort, sticking, noise or rattle.
4. Check that selector lever stops at each position with the feel of engagement when it is moved through all
the positions. Check that the actual position of the selector lever matches the position shown by the shift
position indicator and the manual lever on the transaxle.
5. The method of operating the selector lever to individual posi-
tions correctly should be as shown.
6. When selector button is pressed in “P”, “R”, “N”, “D” or “L” posi-
tion without applying forward/backward force to selector lever,
check button operation for sticking.
7. Check that back-up lamps illuminate only when selector lever is
placed in the “R” position.
8. When in “R” position, check that back-up lamps illuminate even
when the selector lever is pushed toward the “P” position.
CAUTION:
Check the lighting without pressing shift button.
9. Check that the back-up lamps do not illuminate when selector lever is pushed toward the “R” position
when in the “P” or “N” position.
CAUTION:
Check the lighting without pressing shift button.
10. Check that the engine can only be started with the selector lever in the “P” and “N” positions.
11. Check that transaxle is locked completely in “P” position.
ADJUSTMENT
1. Place selector lever in “ P” position.
CAUTION:
Turn wheels more than 1/4 rotations and apply the park lock.
2. Loosen nut (A) and place manual lever (B) in “P” position.
CAUTION:
Never apply any force to the manual lever.
3. Tighten nut. Refer to TM-319, "
Exploded View".
CAUTION:
Fix the manual lever when tightening.
JPDIA0343GB
JPDIA0780ZZ

FLUID COOLER SYSTEM
TM-329
< ON-VEHICLE REPAIR >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
FLUID COOLER SYSTEM
Exploded ViewINFOID:0000000003886234
Removal and InstallationINFOID:0000000003886235
REMOVAL
1. Remove air duct (inlet). Refer to EM-26, "Exploded View".
2. Remove engine under cover. Refer to EXT-28, "
Exploded View".
3. Remove fender protector (left side). Refer to EXT-22, "
FENDER PROTECTOR : Exploded View".
4. Remove fluid cooler hose A and fluid cooler hose B.
5. Remove CVT fluid cooler tube from transaxle assembly.
INSTALLATION
Note the following, and install in the reverse order of removal.
CAUTION:
Never reuse copper washer.
1. Hose clamp 2. Fluid cooler hose A 3. Fluid cooler hose B
4. Copper washer 5. CVT fluid cooler tube 6. CVT fluid cooler tube
7. Transaxle assembly
A. To radiator
: Vehicle front
Refer to GI-4, "
Components" for symbols in the figure.
JPDIA0787GB

TM-332
< REMOVAL AND INSTALLATION >[CVT: RE0F10A]
TRANSAXLE ASSEMBLY
REMOVAL AND INSTALLATION
TRANSAXLE ASSEMBLY
Exploded ViewINFOID:0000000003806551
Removal and InstallationINFOID:0000000003806552
WARNING:
Never remove the reservoir tank cap when the engine is hot. Serious burns could occur from high
pressure engine coolant escaping from the reservoir tank.
REMOVAL
1. Remove the engine, the transaxle assembly and front suspension member. Refer to EM-67, "Exploded
View".
2. Lift with hoist and separate engine, transaxle assembly from front suspension member. Refer to EM-67,
"Exploded View".
3. Remove air breather hose. Refer to TM-328, "
Exploded View".
4. Remove CVT fluid level gauge and CVT fluid charging pipe.
5. Disconnect the following connectors:
 Primary speed sensor connector
 Secondary speed sensor connector
 PNP switch connector
 CVT unit connector
6. Remove crankshaft position sensor (POS). Refer to EM-38, "
Exploded View".
1. Transaxle assembly 2. O-ring 3. CVT fluid charging pipe
4. CVT fluid level gauge
A. For tightening torque, refer to TM-332, "
Removal and Installation".
B. To water outlet
Refer to GI-4, "
Components" for symbols in the figure.
JPDIA0736GB

TRANSAXLE ASSEMBLY
TM-333
< REMOVAL AND INSTALLATION >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
7. Remove rear plate. Refer to EM-38, "Exploded View".
8. Turn crankshaft, and remove the four tightening bolts ( ) for
drive plate and torque converter.
CAUTION:
When turning crankshaft, turn it clockwise as viewed from
the front of the engine.
9. Remove transaxle assembly fixing bolts with power tool.
10. Remove transaxle assembly from engine assembly with a hoist.
11. Remove CVT fluid cooler tube from transaxle assembly. Refer to
TM-329, "
Exploded View".
INSTALLATION
Note following, and install in the reverse order of removal.
CAUTION:
 Never reuse O-ring.
 Apply petroleum jelly to O-ring.
 Check fitting of dowel pin ( ) when installing transaxle
assembly to engine assembly.
 When installing transaxle assembly to the engine assembly, attach
the fixing bolts in accordance with the following.
SCIA1861E
JPDIA0598ZZ
JPDIA0602ZZ
JPDIA0737ZZ
