2008 MERCEDES-BENZ C300 4MATIC Owner's Manual

264 Controls in detail
3-zone automatic climate control* (Canada only)
Front defroster
You can use this setting to defrost the
windshield, for example if it is iced up. You
can also defog the windshield and the side
windows.
Activating: Press buttony
(
page 259).
The indicator lamp in the button comes
on.
The air conditioning switches
automatically to the following functions:

cooling on to dehumidify

most efficient blower speed and
heating power, depending on out-
side temperature

air flows onto the windshield and
the front side windows

the air recirculation mode is
switched off
Deactivating: Press buttony
(
page 259) again.
The indicator lamp in the button goes
out. Defrosting is turned off.
The previous settings are once again in
effect.Windshield fogged on the outsideSwitch the windshield wipers on
(
page 118).
If the automatic mode of the climate con-
trol is switched off:
Press righta and/or lefte air distri-
bution buttonZ (
page 259) re-
peatedly until one of the following
symbols appears in
displayd:aorY
(
page 259).
iKeep this setting selected only until the
windshield is clear again.
iYou can adjust the air distribution when the
front defroster is switched on.
iTo switch defrosting off, you can also press
button´, U,·,Q or temperature
controls1 and8 (
page 259).
iThe cooling remains switched on.
iKeep this setting selected only until the
windshield is clear again.

265 Controls in detail
3-zone automatic climate control* (Canada only)
Rear window defroster
Activating: Switch on the ignition.
Press button¯ (page 259).
The indicator lamp in the button comes
on.
Deactivating: Press button¯
(
page 259).
The indicator lamp in the button goes
out.
Air recirculation mode
Switch to air recirculation mode to prevent
unpleasant odors from entering the vehicle
from the outside (e.g. before driving
through a tunnel). This setting cuts off the
intake of outside air and recirculates the
air in the passenger compartment.
!The rear window defroster uses a large
amount of power. To keep battery drain to a min-
imum, switch off the defroster as soon as the
rear window is clear.
iThe rear window defroster is automatically
deactivated after some time of operation de-
pending on the outside temperature.
Warning!G
Any accumulation of snow and ice should be
removed from the rear window before driv-
ing. Visibility could otherwise be impaired,
endangering you and others.
iIf the rear window defroster switches off too
soon and the indicator lamp goes out, this indi-
cates that too many electrical consumers are op-
erating simultaneously and the load on the
battery is reducing available voltage. The system
responds automatically by deactivating the rear
window defroster.
Warning!G
Fogged windows impair visibility, endanger-
ing you and others. If the windows begin to
fog on the inside, switching off the air
recirculation mode immediately should clear
interior window fogging. If interior window
fogging persists, make sure the air
conditioning (
page 267) is activated, or
press buttony.

266 Controls in detail
3-zone automatic climate control* (Canada only)
Activating: Press button,
(
page 259).
The indicator lamp in the button comes
on.
Deactivating: Press button,
(
page 259) again.
The indicator lamp in the button goes
out.
Residual engine heat and ventilation
With the engine switched off, it is possible
to continue to heat or ventilate the interior
for approximately 30 minutes. This feature
makes use of the residual heat produced
by the engine.
Activating: Switch off the ignition.
Press buttonT (page 259).
The indicator lamp in the button comes
on.
Deactivating: Press buttonT
(
page 259) again.
The indicator lamp in the button goes
out.
iThe air recirculation mode is activated auto-
matically at high outside temperatures.
The indicator lamp on button, is not lit when
the air recirculation mode is automatically
switched on.
A quantity of outside air is added after approxi-
mately 30 minutes.
iThe air recirculation mode is deactivated au-
tomatically:

after 5 minutes if the outside temperature is
below approximately 7°C (45°F)

after 5 minutes if the air conditioning is
turned off

after 30 minutes if the outside temperature
is above approximately 5°C (41°F)
iIf you switch on the residual heat function
when outside temperatures are high, only the
ventilation will be switched on.
iRegardless of the selected air volume, the
blower operates at low speed when heating. In
case of ventilation the blower operates at higher
speed.
iHow long the system will provide heating de-
pends on

the coolant temperature

the temperature set by the operator
iThe residual heat is automatically turned off:

when the ignition is switched on

after approximately 30 minutes

if the battery voltage drops

if the coolant temperature is too low

267 Controls in detail
3-zone automatic climate control* (Canada only)
Air conditioning
The cooling function, is only operational
when the engine is running, cools the vehi-
cle interior down to the selected tempera-
ture. The cooling function also
dehumidifies the air in the vehicle interior,
thus preventing the windows from fogging
up.It is possible to deactivate the air condi-
tioning (cooling) function of the climate
control system. The air in the vehicle will
then no longer be cooled or dehumidified.
Deactivating: Press button2
(
page 250).
The indicator lamp in the button goes
out.
The cooling function switches off after
a short delay.
Moist air can fog up the windows. You can
dehumidify the air with the air condition-
ing.
Activating: Press button2
(
page 250) again.
The indicator lamp in the button comes
on.
The air conditioning uses the
refrigerant R134a. This refrigerant is free
of CFCs which are harmful to the ozone
layer.
iCondensation may drip out from underneath
the vehicle. This is normal and not an indication
of a malfunction.
Warning!G
If you turn off the cooling function, the
vehicle will not be cooled when weather
conditions are warm. The windows can fog
up more quickly. Window fogging may
impair visibility and endanger you and
others.
!If the air conditioning cannot be turned on
again, this indicates that the air conditioning is
losing refrigerant. The compressor has turned it-
self off.
Have the air conditioning checked at the nearest
authorized Mercedes-Benz Center.

268 Controls in detail
3-zone automatic climate control* (Canada only)
Rear climate control
The rear climate control panel is located in
the rear center console.
Setting temperature
Use temperature control 5 to adjust the
air temperature in the rear passenger com-
partment. You should raise or lower the
temperature setting in small increments,
preferably starting at 22°C (72°F). The cli-
mate control will adjust to the set temper-
ature as fast as possible.Increasing/decreasing: Press the re-
spective temperature control
button5.
The 3-zone automatic climate control
system will correspondingly adjust the
temperature in the rear passenger
compartment.
Adjusting air volume
Use button· orQ (
page 268) to
adjust the air volume.
Press button· to decrease, or
buttonQ to increase air volume to
the desired level.
The air volume is adjusted correspond-
ing to the set blower speed.
Warning!G
Follow the recommended settings for heat-
ing and cooling as given in the instructions
for the front 3-zone automatic climate con-
trol (
page 259). Otherwise the windows
could fog up, impairing visibility for the driv-
er and endangering you and others.
Item
1Decreasing/increasing air volume
for rear center air vents
2Right rear center air vent, adjustable
3Decreasing/increasing air volume
for rear center air vents
4Display
5Temperature control
6Left rear center air vent, adjustable
iAt low outside temperatures or if you have
switched off the cooling function, you cannot
cool the rear passenger compartment.
iIf you have switched off the cooling function
with the front 3-zone automatic climate control
panel, the cooling of the rear passenger com-
partment is also switched off. Adjusting with the
rear control panel is not possible.

269 Controls in detail
Trunk
Trunk
Opening trunk
You can open the trunk if the vehicle is sta-
tionary.
A minimum height clearance of 5.9 ft
(1.90 m) is required to open the trunk lid.Opening trunk from outside
1Trunk lid handle
Press and hold button Š on the
SmartKey or SmartKey with
KEYLESS-GO* until trunk unlocks and
begins to open.
or
Pull on handle1.
In vehicles without KEYLESS-GO*: The
vehicle must be unlocked.Opening trunk from inside
1Remote trunk opening switch
Press switch1 until the trunk begins
to open.
Warning!G
Make sure the trunk is closed when the en-
gine is running and while driving. Among
other dangers, such as blocked visibility, ex-
haust fumes may enter the vehicle interior.
These fumes are damaging to your health.
!The trunk lid swings open upwards automat-
ically. Always make sure there is sufficient over-
head clearance.
iIf the trunk does not open, it is still locked
separately (
page 272).

270 Controls in detail
Trunk
Closing trunk Closing trunk from outside manually
1Handles
Lower trunk lid by pulling firmly on
handles1 or2.
Close the trunk with hands placed flat
on the trunk lid.
iDo not place the SmartKey in the open
trunk. You may lock yourself out.
iIf the vehicle was previously centrally
locked, the trunk will lock automatically after
closing it. All turn signal lamps flash three times
and an acoustic signal sounds three times to
confirm locking.
Vehicles with KEYLESS-GO* (Canada only): To
prevent a possible inadvertent lockout, the trunk
will open automatically if a SmartKey with
KEYLESS-GO* (Canada only) is recognized
inside the vehicle or in the trunk.
The vehicle is only locked when the turn signals
flash three times and an acoustic signal sounds
three times. If you are carrying a second
SmartKey with KEYLESS-GO* (Canada only) with
you, you can still lock the vehicle.
Warning!G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
lid opening when closing the trunk. Be espe-
cially careful when small children are
around.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
(Canada only) from the starter switch, take
it with you, and lock the vehicle. Do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could re-
sult in an accident and/or serious personal
injury.

271 Controls in detail
Trunk
Trunk emergency release
With the emergency release button, the
trunk can be opened from inside the trunk.
1Emergency release buttonBriefly press emergency release
button1.
The trunk opens.Illumination of the emergency release but-
ton:

The button will flash for 30 minutes af-
ter opening the trunk.

The button will flash for 60 minutes af-
ter closing the trunk.iThe emergency release button unlocks and
opens the trunk while the vehicle is standing still
or in motion.
iThe emergency release button does not
open the trunk if the vehicle battery is dis-
charged or disconnected.
