2008 MERCEDES-BENZ C300 4MATIC Owner's Manual

280 Controls in detail
Loading and storing
Roof rack*
1CoversFlip the covers1 upward in direction
of arrow.
Vehicles with panorama roof with
tilt/sliding panel*: Open the cover 1
carefully in the opposite direction to
that indicated by the arrow.
Only attach the roof-rack system to the
anchorage points under the covers.
Observe manufacturer’s instructions
for installation.
Warning!G
Only use roof racks approved by
Mercedes-Benz for your vehicle model to
avoid damage to the vehicle.
Follow the manufacturer’s installation
instructions. Otherwise, an improperly
attached roof rack system or its load could
become detached from the vehicle.
Do not exceed the maximum roof load of
220 lb (100 kg).
Take into consideration that when the roof
rack is loaded, the handling characteristics
are different from those when operating the
vehicles without the roof rack loaded.
!Load the roof rack in such a way that the ve-
hicle cannot be damaged while driving.
Make sure

you can fully raise tilt/sliding sunroof or the
panorama roof with tilt/sliding panel*

you can fully open the trunk

281 Controls in detail
Loading and storing
Split rear bench seat*
To expand the cargo area, you can fold
down the left and right rear seat backrests.
The two sections can be folded down
separately.Folding the backrest forward
The release handles1 is located in the
trunk.
1Release handle
Open the trunk.
Pull on left and/or right release
handle1.
Fully retract the head restraints
(
page 89).
If necessary, pull the driver's and/or
front-passenger seat forward.2Rear seat backrests
Fold rear seat backrests2 forward.
Warning!G
When expanding the luggage compartment,
always fold the seat cushions fully forward.
Unless you are transporting cargo, the back-
rests must remain properly locked in the up-
right position.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle, and cause injury
to vehicle occupants unless the items are
securely fastened in the vehicle.

282 Controls in detail
Loading and storing
Setting up rear seat backrest
1Rear seat backrests
Fold backrest1 rearward until it en-
gages.
Check for secure locking by pushing
and pulling on the backrest.
Loading instructions
The total load weight including vehicle
occupants and luggage/cargo should not
exceed the load limit or vehicle capacity
weight as indicated on the corresponding
placard located on the driver’s door B-pillar
(
page 334).
The handling characteristics of a fully load-
ed vehicle depend greatly on the load dis-
tribution. It is therefore recommended to
load the vehicle according to the illustra-
tions shown, with the heaviest items being
placed towards the front of the vehicle.
!Take care not to clamp the seat belt.
Warning!G
Always lock backrest in its upright position
when rear seat bench is occupied, or the ex-
tended trunk compartment is not in use.
Check for secure locking by pushing and
pulling on the backrest.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle, and cause injury
to vehicle occupants unless the items are
securely fastened in the vehicle.
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo.
iTo prevent unauthorized persons from ac-
cess to the trunk, always lock backrest in its up-
right position.

283 Controls in detail
Loading and storing
Always place items being carried against
front or rear seat backrests, and fasten
them as securely as possible.
The heaviest portion of the cargo should al-
ways be kept as low as possible since it in-
fluences the handling characteristics of
the vehicle.Storage compartments
Warning!G
Always fasten items being carried as secure-
ly as possible using cargo tie-down hooks
and fastening materials appropriate for the
weight and size of the load.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle and can cause in-
jury to vehicle occupants unless the items
are securely fastened in the vehicle.
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo. Put luggage or car-
go in the trunk if possible.
Do not pile luggage or cargo higher than the
seat backs. Do not place anything on the
rear-window shelf.
Never drive vehicle with trunk open. Deadly
carbon monoxide (CO) gases may enter ve-
hicle interior resulting in unconsciousness
and death.
iThe trunk is the preferred place to carry ob-
jects.
The enlarged cargo area should only be used for
items which do not fit in the trunk alone.
Warning!G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when storing objects in the vehicle. Put lug-
gage or cargo in the trunk if possible. Do not
pile luggage or cargo higher than the seat
backs.
Parcel nets cannot secure hard or heavy ob-
jects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during

braking

vehicle maneuvers or

an accident.
iAn overview of the storage compartments
can be found on (
page 22).

284 Controls in detail
Loading and storing
Storage compartments in the front pas-
senger compartment
Glove box
1Glove box lid release
The glove box can be unlocked and locked
with the mechanical key (
page 424).
Opening: Pull glove box lid release1.
Closing: Push the lid up until it
engaged.
Locking: Insert the mechanical key
into the glove box lock and turn it
clockwise to position2.
Unlocking: Insert the mechanical key
into the glove box lock and turn it coun-
terclockwise to position1.Storage compartments in the front
armrest
1Right button for storage compartments
2Left button for large storage compart-
ments
1Unlocking glove box
2Locking glove box

285 Controls in detail
Loading and storing
Opening small and large storage
compartment: Press button1 or2
the armrests opens automatically to
the left and right side.
Closing small or large storage com-
partment: Swing the left or right arm-
rest backward until it engage.Parcel net in front passenger footwellA small convenience parcel net is located
in the front passenger footwell. It is for
small and light items, such as road maps,
mail, etc.
iThere is a small and a large storage compart-
ment located underneath the left armrest. The
small storage compartment can be removed for
the purpose of emptying.
Warning!G
The parcel net is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel net. In an accident, during hard brak-
ing, or sudden maneuvers, they could be in-
jury to vehicle occupants.
The parcel net cannot protect transported
goods in the event of an accident.

286 Controls in detail
Loading and storing
Storage compartments in rear passen-
ger compartment
Armrest with integrated storage
compartment
1Release catch
Opening: Pull down the armrest.
Pull release catch 1 and swing the
cover upward in direction of arrow.Storage pockets
Storage pockets 1 are located on the
back of the front seats.
!Before storing the armrest in the backrest,
close the storage compartment cover.
!Do not sit on or lean your body weight
against the armrest when it is folded down, as
you could otherwise damage it.
Warning!G
The storage pocket is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
storage pocket. In an accident, during hard
braking, or sudden maneuvers, they could
be thrown around inside the vehicle and
cause injury to vehicle occupants.
The storage pocket cannot protect trans-
ported goods in the event of an accident.

287 Controls in detail
Loading and storing
Cup holders
Cup holder in front center console
1Cup holderCup holder in rear center armrest
1Release button
2Cup holder
Opening: Pull down the armrest.
Pull the release catch and swing the
armrest storage compartment cover
upward.
Press release button1.
Cup holder2 swing out and open au-
tomaticaly.
Warning!G
In order to help prevent spilling liquids on
vehicle occupants and/or vehicle equip-
ment, only use containers that fit into the
cup holder. Use lids on open containers and
do not fill containers to a height where the
contents, especially hot liquids, could spill
during braking, vehicle maneuvers, or in an
accident. Liquids spilled on vehicle occu-
pants may cause serious personal injury.
Liquids spilled on vehicle equipment may
cause damage not covered by the
Mercedes-Benz Limited Warranty.
When not in use, keep the cup holders
closed. An open cup holder may cause injury
to you or others when contacted during
braking, vehicle maneuvers, or in an
accident.
Keep in mind that objects placed in the cup
holder may come loose during braking, vehi-
cle maneuvers, or in an accident and be
thrown around in the vehicle interior.
Objects thrown around in the vehicle interi-
or may cause an accident and/or serious
personal injury.
iYou can now close the armrest storage
compartment.
