2008 INFINITI FX35 washer fluid

FRONT WIPER AND WASHER SYSTEMWW-27
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
WW
N
O P
Washer Tube LayoutINFOID:0000000001328568
Removal and Installation of Front Washer NozzleINFOID:0000000001328569
Replace wiper arm assembly. Refer to WW-23, "Removal and Installation of Front Wiper Arms, Adjustment of
Wiper Arms Stop Location".
CAUTION:
Removal/installation of the washer no zzle as a unit must not be done.
Removal and Installation of Front Washer Tube JointINFOID:0000000001328570
REMOVAL
1. Remove upwards while pressing the pawls on reverse side.
2. Remove washer tube.
INSTALLATION
Installation is the reverse order of removal.
Inspection of Washer NozzleINFOID:0000000001328571
CHECK VALVE
Blow check valve. Confirm that t he air ventilates. Also confirm that
inhalation is impossible.
CAUTION:
A check valve is provided in the w asher fluid line. Be careful not
to connect check valve to washer tube in the wrong direction.
PKID0570E
PKIA1159E
PKIA3131E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

WW-28
< SERVICE INFORMATION >
FRONT WIPER AND WASHER SYSTEM
Inspection of Front Wiper and Washer Switch Circuit
INFOID:0000000001328572
Refer to LT-104, "Combination Switch Inspection".
Removal and Installation of Fr ont Wiper and Washer SwitchINFOID:0000000001328573
REMOVAL
1. Remove steering column upper cover. Refer to IP-10, "Compo-
nent Parts Location".
2. Disconnect wiper and washer switch connector.
3. Pull wiper and washer switch toward the passenger door while pressing pawls in direction shown by the arrow in the figure, and
remove it from the base.
INSTALLATION
Installation is the reverse order of removal.
Removal and Installation of Washer TankINFOID:0000000001328574
REMOVAL
1. Remove bolt and pull out washer tank inlet out of washer tank.
2. Remove front fillet molding (RH). Refer to EI-14, "
Component
Parts Location".
3. Remove fender protector front (RH). Refer to EI-24, "
Compo-
nent Parts Location".
4. Remove front bumper fascia assembly. Refer to EI-14, "
Compo-
nent Parts Location".
5. Disconnect washer pump connector and wash fluid level sensor connector.
6. Remove washer tank mounting bolt and nuts.
PKIB6026E
SKIA5076E
PKIC9705E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

REAR WIPER AND WASHER SYSTEMWW-41
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
WW
N
O P
3. Lift the blade up and then set it down onto back door window glass surface to set the blade center to lowest heat wire immedi-
ately.
4. Tighten rear wiper arm nuts to specified torque.
5. Spray washer fluid. Turn on rear wiper switch ON to operate wiper motor, and then turn rear wiper switch OFF (auto stop).
6. Ensure that wiper blade stop within the following range.
7. Install rear wiper arm cap.
Removal and Installation of Rear Wiper BladeINFOID:0000000001328590
REMOVAL
1. Remove rear wiper arm. Refer to WW-40, "Removal and Instal-
lation of Rear Wiper Arm, Adjustment of Wiper Arms Stop Loca-
tion".
2. Turn rear wiper blade 90 degrees against rear wiper arm, and pull it out downward for removal.
CAUTION:
Replace rear wiper blade as rear wiper blade assembly.
INSTALLATION
Installation is the reverse order of removal. Rear wiper arm nut : 8.8 N·m (0.90 kg-m, 78 in-lb)
Lowest heat wire :
± 3.75 mm ( ± 0.148 in)
PKID0496E
SKIA6169E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

WW-44
< SERVICE INFORMATION >
REAR WIPER AND WASHER SYSTEM
1. Remove high-mounted stop lamp. Refer to LT-114, "High-
Mounted Stop Lamp".
2. Remove screw and remove washer nozzle from high-mounted stop lamp.
INSTALLATION
Installation is the reverse order of removal. Adjust nozzle spray location. Refer to WW-43, "Washer Nozzle
Adjustment".
Check ValveINFOID:0000000001328595
Blow check valve. Confirm that the air ventilates. Also confirm that
inhalation is impossible.
CAUTION:
A check valve is provided in the w asher fluid line. Be careful not
to connect check valve to washer tube in the wrong direction.
Inspection of Front Wiper and Washer Switch CircuitINFOID:0000000001328596
Refer to LT-104, "Combination Switch Inspection".
Removal and Installation of Re ar Wiper and Washer SwitchINFOID:0000000001328597
Refer to WW-28, "Removal and Installation of Front Wiper and Washer Switch".
Removal and Installation of Washer TankINFOID:0000000001328598
Refer to WW-28, "Removal and Installation of Washer Tank".
Removal and Installation of Front and Rear Washer pumpINFOID:0000000001328599
Refer to WW-29, "Removal and Installation of Front and Rear Washer Pump".
PKIB6132E
SEL411H
