2007 SUBARU FORESTER Owners Manual

Specifications 12-7
–
CONTINUED –
1530Ay Windshield wiper and washer
1620AyBrake light
1715AyAir conditioner
1815AyBackup light
y Cruise control
1915AyPower outlet (cargo)
2015AyRear window wiper and washer
2115AyIgnition coil (Non-turbo model only)
2215AySeat heater
23Empty
Fuse panelFuse ratingCircuit

12-8 Specifications
„Fuse panel located in the engine compartment
A) FWD socket
B) Main fuse
A 12 4
3 B
5
6 789
10 11 12 13
C00105
14
Fuse panelFuse ratingCircuit
130Ay
Radiator cooling fan (Main)
230AyRadiator cooling fan (Sub)
330AyABS motor
430AyEngine sensor (Non-turbo models only)
520AyRear window defogger
615AyHazard warning flasher
y Horn
715AyTurn signal lights
810AyAutomatic transmission control unit
910AyAlternator
1015AyHeadlight (right side)
1115AyHeadlight (left side)
1220AyLighting switch
1315AyClock
y Interior light
1410AySecondary air combination valve
(Turbo models only)

Specifications 12-9
Bulb chart
Description Wattage Bulb type
Headlight
High beam 12V-60W 9005 (HB3)
Low beamCanada-spec. 2.5XT 12V-35W D2R
All except Canada-
spec. 2.5XT 12V-55W H1
Front fog light 12V-51W 9006 (HB4)
Front turn signal light 12V-21W 1474
Parking light 12V-5W 168
Side marker light (Front) 12V-5W 168
Rear combination light Tail/stop light 12V-21/5W 7443
Turn signal light 12V-21W (Amber) 1474
Tail/stop light 12V-21/5W 7443
Backup light 12V-16W 921
High mount stop light 12V-13W 912
License plate light 12V-5W 168
Cargo area light 12V-15W –
Dome light 12V-8W –
Map light 12V-8W –

12-10 Specifications
Vehicle identification
12
3 4
56
9 8
7
C00112 1) Vehicle identification number
2) Emission control label
3) Vehicle identification number plate
4) Tire inflation pressure plate
5) Certification plate
6) Bar cord label (U.S. only)
7) Model number plate
8) Radio noise label (Canada only)
9) Fuel label

13
Consumer information and Reporting safety defects
Tire information .................................................. 13-2Tire labeling ............................................................. 13-2
Recommended tire inflation pressure .................. 13-5
Glossary of tire terminology .................................. 13-6
Tire care – maintenance and safety practices ..... 13-7
Vehicle load limit – how to determine ................... 13-8
Determining compatibility of tire and vehicle load capacities ...................................................... 13-10
Adverse safety consequences of overloading on handling and stopping and on tires .............. 13-11
Steps for Determining Correct Load Limit ........... 13-11
Uniform tire quality grading standards ............ 13-12 Treadwear ................................................................ 13-12
Traction AA, A, B, C ................................................ 13-12
Temperature A, B, C ............................................... 13-12
Reporting safety defects (USA) ......................... 13-13

13-2 Consumer information and Reporting safety defects
Co nsumer informa tion and Repo rting s afe ty defec tsFor U.S.A.
The following information has been com-
piled according to Code of Federal Regu-
lations “Title 49, Part 575”.Tire information „Tire labeling
Many markings (e.g. Tire size, Tire
Identification Number or TIN) are
placed on the sidewall of a tire by tire
manufacturers. These marking can
provide you with useful information on
the tire. T Tire size
Your vehicle comes equipped with P-
Metric tire size. It is important to un-
derstand the sizing system in select-
ing the proper tire for your vehicles.
Here is a brief review of the tire sizing
system with a breakdown of its indi-
vidual elements. V P Metric
With the P-Metric system, Section
Width is measured in millimeters. To
convert millimeters into inches, divide
by 25.4. The Aspect Ratio (Section
Height divided by Section Width)
helps provide more dimensional infor-
mation about the tire size. Example:
(1) P = Certain tire type used on light
duty vehicles such as passenger cars
(2) Section Width in millimeters
(3) Aspect Ratio (= section height
y
section width).
(4) R = Radial Construction
(5) Rim diameter in inches
V Load and Speed Rating Descrip- tions
The load and speed rating descrip-
tions will appear following the size
designation.
They provide two important facts
about the tire. First, the number des-
ignation is its load index. Second, the
letter designation indicates the tire’s
speed rating.
Example:
(6) Load Index: A numerical code
P 215 / 60 R 16
(1) (2) (3) (4) (5)
P 215 / 60 R 16 94 H
Size designation (6) (7)

Consumer information and Reporting safety defects 13-3
– CONTINUED –
which specifies the maximum load a
tire can carry at the speed indicated
by its speed symbol, at maximum in-
flation pressure.
For example, “94” means 1,477 lbs
(670 kg).
(7) Speed Rating: An alphabetical
system describing a tire’s capability to
travel at established and predeter-
mined speeds.
For example, “H” means 130 mph
(210 km/h)
T
Tire Identification Number (TIN)
Tire Identification Number (TIN) is
marked on the intended outboard
sidewall. The TIN is composed of four
groups. Here is a brief review of the
TIN with a breakdown of its individual
elements. (1) Manufacturer’s Identification
Mark
(2) Tire Size
(3) Tire Type Code
(4) Date of Manufacture
The first two figures identify the week,
starting with “01” to represent the first
full week of the calendar year; the
second two figures represent the
year. For example, 0101 means the
1st week of 2001.
T Other markings
The following makings are also
placed on the sidewall. V Maximum permissible inflation
pressure
The maximum cold inflation pressure
to which this tire may be inflated. For
example, “300 kpa (44 PSI) MAX.
PRESS” V Maximum load rating
The load rating at the maximum per-
missible weight load for this tire. For
example, “MAX. LOAD 670 kg (1477
LBS) @ 300 kpa (44 PSI) MAX.
PRESS.”
Load indices apply only to the
tire, not to the vehicle. Putting a
load rated tire on any vehicle
does not mean the vehicle can
be loaded up to the tire’s rated
load.
y Speed ratings apply only to
the tire, not to the vehicle. Put-
ting a speed rated tire on any
vehicle does not mean the ve-
hicle can be operated at the
tire’s rated speed.
yThe speed rating is void if the
tires are worn out, damaged,
repaired, retreaded, or other-
wise altered from their original
condition. If tires are repaired,
retreaded, or otherwise al-
tered, they may not be suitable
for original equipment tire de-
signed loads and speeds.
DOT XX XX XXX XXXX
(1) (2) (3)(4)

13-4 Consumer information and Reporting safety defects
VConstruction type
Applicable construction of this tire.
For example, “TUBELESS STEEL
BELTED RADIAL” V Construction
The generic name of each cord mate-
rial used in the plies (both sidewall
and tread area) of this tire.
For example, “PLIES: SIDEWALL
POLYESTER 1 TREAD POLYES-
TER 1 + STEEL 2 + NYLON 1” V Uniform Tire Quality Grading (UTQG)
For details, refer to “Uniform tire qual-
ity grading standards” in this chapter.
Maximum load rating applies
only to the tire, not to the vehi-
cle. Putting a load rated tire on
any vehicle does not mean the
vehicle can be loaded up to the
tire’s rated load.
