Compass zone adjustment
Compass calibration zones
1. The zone setting is factory preset to
Zone 8. Refer to the “Compass calibration
zone” map shown above or one attached
to the end of this manual to verify that the
compass zone setting is correct for your
geographical location.
2. Press and hold the right button for 3
seconds then release, and the word
“ZONE” will briefly appear and then the
zone number will be displayed.
3. Press the right-hand button repeatedly
to cycle the display through all possible
zone settings. Stop cycling when the cor-
rect zone setting for your location is dis-
played.
4. Releasing the button for 3 seconds will exit the zone setting mode.
„ Outside mirrors
T Convex mirror (passenger side)
T Remote control mirror switch
1) Selection switch
2) Direction control switch
The remote control mirrors operate only
when the ignition switch is in the “ON” or
“ACC” position.
1. Press either end of the selection
switch, “L” for the left, “R” for the right.
2. Move the direction control switch in the
direction you want to move the mirror.
3. Return the selection switch to the neu-
tral position to prevent unintentional oper-
ation.
The mirrors can also be adjusted manual-
ly.
10
9
8
7
6
5
4
3
1112
13
300580
Objects look smaller in a convex
mirror and farther away than when
viewed in a flat mirror. Do not use
the convex mirror to judge the dis-
tance of vehicles behind you when
changing lanes. Use the inside mir-
ror (or glance backwards) to deter-
mine the actual size and distance of
objects that you view in convex mir- ror.
300146
1
2
300581

3-28 Instruments and controls
TOutside mirror defogger (if
equipped)
1) Outside mirror defogger button (if
equipped)
2) Outside mirror defogger and windshield wiper deicer button (if equipped)
The outside mirror defogger operates only
when the ignition switch is in the “ON” po-
sition.
To turn on the outside mirror defogger,
push the button. To turn it off, push the button again. The indicator light located
on the button lights up while the outside
mirror defogger is operating.
The defogger will automatically shut off af-
ter approximately 15 minutes. If the mirror
clears before that time, push the button to
turn it off. It also turns off when the ignition
switch is turned to the “ACC” or “LOCK”
position. If defrosting or defogging is de-
sired when you restart your vehicle, you
have to push the button to turn it on again.
NOTE
On vehicles equipped with a wind-
shield wiper deicer, the windshield
wiper deicer switch is also used to op-
erate the outside mirror defogger.
Tilt steering wheel
1. Adjust the seat position. Refer to the
“Front seats” section (chapter 1).
2. Push the tilt lock lever down.
3. Move the steering wheel to the desired
level.
4. Pull the lever up to lock the steering
wheel in place.
5. Make sure that the steering wheel is
securely locked by moving it up and down.
To prevent the battery from being
discharged, do not operate the de-
fogger continuously for any longer
than necessary.
12
300582
Do not adjust the steering wheel tilt
position while driving. This may
cause loss of vehicle control and re-
sult in personal injury.
300149

Instruments and controls 3-29
Horn
To sound the horn, push the horn pad.
300150

4
Climate control
Ventilator ............................................................. 4-2Air flow selection .................................................... 4-2
Center and side ventilators .................................... 4-3
Manual climate control system (if equipped) .. 4-3 Control panel .......................................................... 4-3
Heater operation ..................................................... 4-5
Air conditioner operation ....................................... 4-7
Automatic climate control system (if equipped) .................................................... 4-8Control panel .......................................................... 4-8
To use as full-automatic climate control system ................................................................... 4-8
To use as semi-automatic climate control
system ................................................................... 4-8
Fan speed control dial ........................................... 4-9
Temperature control dial ........................................ 4-9
Air flow control dial ................................................ 4-9
Air inlet selection button ........................................ 4-10
Air conditioner button ............................................ 4-10
Temperature sensors ............................................. 4-11
Operating tips for heater and air conditioner ...................................................... 4-11Cleaning ventilation grille ...................................... 4-11
Efficient cooling after parking in direct sunlight ................................................................. 4-11
Lubrication oil circulation in the refrigerant circuit .................................................................... 4-12
Checking air conditioning system before summer season .................................................... 4-12 Cooling and dehumidifying in high humidity and
low temperature weather conditions .................. 4-12
Air conditioner compressor shut-off when engine is heavily loaded ...................................... 4-12
Refrigerant for your climate control system ........ 4-12
Air filtration system (if equipped) ..................... 4-12 Replacing an air filter ............................................. 4-13

4-2 Climate control
Climate contro lVentilator „Air flow selection
