2007 SUBARU FORESTER Owners Manual

Audio 5-23
–
CONTINUED –
In-dash 6 CD auto changer (if equipped) „ Loading and unloading compact discs
(5) (1) (2)
(4) (3)
500222(1) Disc slot
(2) Disc indicators (disc No.1 to 6)
(3) Disc select buttons (disc No.1 to 6)
(4) Eject button
(5) Disc slot indicator

5-24 Audio
TTo insert a disc
1. Press one of the disc select buttons (3) (numbered from 1 to 6) for which the disc
indicator light (2) is “OFF”.
The disc indicator lights are located direct-
ly above the corresponding disc select
buttons.
2. The indicator will begin blinking. The
blinking will last for 15 seconds.
During this period, insert a desired disc,
and the disc will begin to play. (If any disc
is not inserted during this period, the “Disc
slot” (1) door will close. Repeat Step 1.)
Be sure to hold a disc with the label side
(the side where titles are printed) up.
3. To insert another disc, repeat Steps 1
and 2 choosing a different disc select but-
ton. T
To insert six discs at a time
1. Press and hold the disc select button
number 1 until all disc indicators begin
blinking (approximately 1.5 seconds).
2. The indicators will blink for 15 seconds.
During this period, insert desired six discs.
3. When all discs are loaded, the first disc
will begin to play. (If no disc is inserted
within this 15 seconds, the entire disc load
sequence will be canceled.) T To remove a disc
1. Press the desired one of the disc select
buttons (3) (numbered from 1 to 6) for
which the disc indicator light is on.
2. Press the eject button (4). The selected disc will be ejected and the indicator light
will begin blinking.
3. To remove another disc, repeat Steps
1 and 2 choosing a different disc select
button.
(To remove discs when the ignition switch
is in the “Lock” position, press the eject
button, and the first disc will be ejected.
Press the eject button again, and the next
disc will be ejected and so on. At this time,
the disc select buttons are disabled.) T
To remove all discs at one time
1. Press and hold the eject button (4) until
all “Disc” indicators begin blinking (ap-
proximately 1.5 seconds), and the first
disc will be ejected.
2. When the disc is removed, the next
one will be ejected, and so on. T To replace a playing disc with an-
other
Simply press the desired one of disc se-
lect buttons (3) (numbered from 1 to 6) or
press the disc select button on the radio
unit to select the desired disc, and the disc
will begin to play. T Disc indicators
Lit: when the corresponding storage tray
is occupied by a disc.
Blinking: Disc player is either in loading,
eject or changing mode.
y
Do not attempt to insert two or
more discs into the slot at a time.
Doing so can cause mechanical
damage to the CD changer.
y Use only music CDs identified by
a mark.
y Do not use CDs listed in the fol-
lowing which could cause dam-
age to the CD player.
– 3 inch (8 cm) compact disc
– Any disc with a peel-off or seal
on it
–Bent disc
– Cleaning disc
– CD accessory (E.g., 3 inch (8 cm) disc adapter)
y Do not insert or remove any disc
when the automatic transmission
selector lever is in the park posi-
tion; the selector lever in that po-
sition can interfere with disc in-
sertion or removal, causing
scratches on the disc surface (for
AT vehicles).

Audio 5-25
– CONTINUED –
OFF: No disc is loaded or the ignition
switch is in the “LOCK” position. V
Open/Closed disc slot indicator
When the disc slot is open, the disc indica-
tors on both sides of the slot illuminate. T Function control
Refer to CD changer control operating in-
structions described in the “Type A audio
set (if equipped)” section. Precautions to observe when
handling a compact disc
Use only compact discs (CDs) that have
the mark shown in the following illustra-
tion.
You may also use compact discs (CD-Rs
and CD-RWs) that have the following
marks, but you may not use some discs if
they were produced using writing methods
not compatible with your vehicle’s audio
system.
yYou cannot use a DualDisc in the CD
player. If you insert a DualDisc into the
player, the disc may not come out again,
possibly causing the player to malfunc-
tion. y In cold and/or rainy weather, dew can
500033
500010
TM
DualDisc
500396

5-26 Audio
form inside the CD player, preventing nor-
mal operation. If this happens, eject the
CD and wait for the player to dry out. ySkipping may occur when the CD player
is subjected to severe vibration (for exam-
ple, when the vehicle is driven on a rough
surface). y To remove a disc from the case, press
the center of the case and hold both edg-
es of the disc. If the disc surface is
touched directly, contamination could
cause poor tone quality. Do not touch the
disc surface. y Use a clean disc whenever possible. If
there are deposits, wipe the disc surface
from the center outward with a dry, soft
cloth. Be sure not to use a hard cloth, thin-
ner, benzene, alcohol, etc. y Do not use any disc that is scratched,
deformed, or cracked. Also, do not use
any disc that has a non-standard shape
(for example, a heart shape). Malfunctions
or problems might result. y A disc is vulnerable to heat. Never keep
it either in places exposed to direct sun-
light, near heaters or in vehicles parked in
the sun or on hot days.
500034

6
Interior equipment
Interior lights ...................................................... 6-2Dome light ............................................................... 6-2
Cargo area light ..................................................... 6-2
Map lights ........................................................... 6-3
Sun visors ........................................................... 6-3 Vanity mirror ........................................................... 6-3
Storage compartments ...................................... 6-4 Glove box ................................................................ 6-4
Center console ........................................................ 6-4
Overhead console .................................................. 6-6
Dashboard storage compartment ......................... 6-6
Convenience net ..................................................... 6-6
Pocket (if equipped) ............................................... 6-7
Cup holders ........................................................ 6-7 Front passenger’s cup holder ............................... 6-8
Rear passenger’s cup holder ................................ 6-8
Accessory power outlets ................................... 6-8 Use with a cigarette lighter (Canada only, if equipped) .................................. 6-10
Ashtray (Canada only, if equipped) .................. 6-11
Floor mat ............................................................. 6-12
Coat hook ............................................................ 6-12
Cargo area cover (if equipped) ......................... 6-13 Using the cover ....................................................... 6-13
To remove the cover housing ................................ 6-13
Stowage of the cover ............................................. 6-13
To install the cover housing .................................. 6-13
Shopping bag hook ............................................ 6-14 Cargo tie-down hooks ........................................ 6-14
Cargo area bars .................................................. 6-14
Under-floor storage compartment .................... 6-15

6-2 Interior equipment
Inte rior eq uip me ntInterior lights
When leaving your vehicle, make sure the
light goes out to avoid battery discharge. „Dome light
The dome light switch has three positions:
ON: The light stays on continuously.
DOOR (middle position): The dome light
comes on when any of the doors or the
rear gate is opened. The light remains on
for several seconds and gradually goes
out after all doors and the rear gate are
closed.
NOTE
If a door or the rear gate is left open,
the light flashes and a chime sounds about 30 minutes later and then the
light is turned off automatically.
The light also can be turned on by use of
the keyless entry transmitter. See the “Re-
mote keyless entry system” section in
chapter 2 for detailed information.
OFF:
The light stays off.
„ Cargo area light
The cargo area light switch has three po-
sitions:
ON: The light stays on continuously.
OFF: The light stays off.
DOOR: The light comes on only when the
rear gate is opened.
NOTE
If a door or the rear gate is left open,
the light flashes and a chime sounds
about 30 minutes later and then the
light is turned off automatically.
The light also can be turned on by use of
the keyless entry transmitter. See the “Re-
mote keyless entry system” section in
chapter 2 for detailed information.
ON
DOOR OFF
600078
ON
OFF
DOOR
600079

Interior equipment 6-3
Map lights
To turn on the map light, push the switch.
To turn it off, push the switch again.
When leaving the vehicle, make sure the
light is turned off to avoid battery dis-
charge.Sun visors
To block out glare, swing down the visors.
To use the sun visor at a side window,
swing it down and move it sideways.„
Vanity mirror
To use the vanity mirror, swing down the
sun visor and open the vanity mirror cov- er.
600080600081
600082

6-4 Interior equipment
Storage compartments
„Glove box
1) Lock
2) Unlock
To open the glove box, pull the handle. To close it, push the lid firmly upward.
To lock the glove box, insert the key and
turn it clockwise.
„ Center console
The center console box provides a stor-
age space. In addition, the top of the con-
sole can be used as an armrest and as a
rear passenger’s cup holder.
To use as armrest:
1. Tip the console top forward from its
vertical position. 2. Push the armrest part of the console
top forward to the desired position while
pulling up the knob at the front end of the
armrest and lock it in position by releasing
the knob. Adjust the position of the arm-
rest to suit your driving position. Make
sure the armrest is securely retained.
When you slide the armrest back to its
original position, pull the knob upward as
you do so.
To return the console top to the vertical
position, pull upward the knob at the front
end of the armrest while raising the con-
sole top until it emits a click.
y
Always keep the storage compart-
ment closed while driving to re-
duce the risk of injury in the event
of sudden stops or an accident.
y Do not store spray cans, contain-
ers with flammable or corrosive
liquids or any other dangerous
items in the storage compartment.
1 2
600471
600519
600473
