Passenger Compartment Air Filter
Passenger compartment air, both outside and
recirculated air, is routed through a passenger
compartment lter. The lter removes most
particles from the air, including dust particles.
Reductions in airow, which may occur more
quickly in dusty areas, indicate that the lter needs
to be replaced early. For how often to change
the air lter, seeScheduled Maintenance on
page 522.The access panel for the passenger compartment
air lter is located in the back of the glove box.
To replace the lter, do the following:
1. Pull the tab located on the outer access panel
up and out.
217
ProCarManuals.com

2. Then push the tab, located on the left of the
inner access panel, to the right.3. The rst air lter will pull straight out. To
remove the second, reach in and slide it
toward the opening. Pull the second lter out.
4. Replace the lters by reversing Step 3. Make
sure the lters are inserted so that the sealing
foam is angled in the same direction on
both lters. For the type of lter to use, see
Normal Maintenance Replacement Parts
on page 532.
5. Close the inner access door, while squeezing
the tab. Be sure it is tightly closed.
6. Snap the outer access panel into the back of
the glove box.
218
ProCarManuals.com

Warning Lights, Gages, and
Indicators
This part describes the warning lights and gages
that may be on your vehicle. The pictures will
help you locate them.
Warning lights and gages can signal that
something is wrong before it becomes serious
enough to cause an expensive repair or
replacement. Paying attention to your warning
lights and gages could also save you or others
from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle’s functions. As
you will see in the details on the next few pages,
some warning lights come on briey when you
start the engine just to let you know they’re
working. If you are familiar with this section, you
should not be alarmed when this happens.Gages can indicate when there may be or is a
problem with one of your vehicle’s functions. Often
gages and warning lights work together to let
you know when there’s a problem with your
vehicle.
When one of the warning lights comes on and
stays on when you are driving, or when one of the
gages shows there may be a problem, check
the section that tells you what to do about
it. Please follow this manual’s advice. Waiting to
do repairs can be costly — and even dangerous.
So please get to know your warning lights and
gages. They’re a big help.
219
ProCarManuals.com

Instrument Panel Cluster
Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You will
know how fast you are going, how much fuel you are using, and many other things you will need to drive
safely and economically. The indicator warning lights and gages are explained on the following pages.
United States version shown, Canada similar
220
ProCarManuals.com

Speedometer and Odometer
Your speedometer lets you see your speed in both
miles per hour (mph) and kilometers per hour
(km/h). Your odometer shows how far your vehicle
has been driven, in either miles (used in the
United States) or kilometers (used in Canada).
Your vehicle has a tamper-resistant odometer.
You may wonder what happens if your vehicle
needs a new odometer installed. The new one can
be set to the mileage total of the old odometer.
Trip Odometer
The trip odometer can display how far you have
driven since you last reset it.
For more information seeDIC Operation and
Displays on page 235.
Tachometer
The tachometer displays
the engine speed in
revolutions per
minute (rpm).
221
ProCarManuals.com

Safety Belt Reminder Light
When the key is turned to RUN or START, a
chime will come on for several seconds to remind
people to fasten their safety belts.
The safety belt light will
also come on and stay
on for several seconds,
then it will ash for
several more.
If the driver remains unbuckled when the ignition
is on and the vehicle is in motion, the chime
and safety belt light will be repeated. You should
buckle your seat belt. If the driver’s belt is
already buckled, neither the chime nor the light
will come on.
Passenger Safety Belt Reminder
Light
Several seconds after the key is turned to RUN or
START, a chime will come on for several seconds
to remind the front passenger to buckle their safety
belt. This would only occur if a passenger is
detected by the passenger sensing system. See
Passenger Sensing System on page 93for more
information. The passenger safety belt light will also
come on and stay on for several seconds, then it
will ash for several more.
You should have the
passenger buckle their
safety belt.
This light and chime reminder will be repeated if
the ignition is on, the vehicle is in motion, the
passenger is still unbuckled and the passenger
airbag is enabled.
If the passenger’s safety belt is buckled, neither
the chime nor the light will come on.
222
ProCarManuals.com

Airbag Readiness Light
There is an airbag readiness light on the
instrument panel, which shows the airbag symbol.
The system checks the airbag’s electrical
system for malfunctions. The light comes on if
there is an electrical problem. The system check
includes the airbag sensor, the airbag modules,
the wiring and the diagnostic module. For
more information on the airbag system, seeAirbag
System on page 83.
This light will come on
when you start your
vehicle, and it will ash
for a few seconds.
Then the light should go
out. This means the
system is ready.
If the airbag readiness light stays on after you
start the vehicle or comes on when you are driving,
your airbag system may not work properly.
Have your vehicle serviced right away.{CAUTION:
If the airbag readiness light stays on after
you start your vehicle, it means the airbag
system may not be working properly. The
airbags in your vehicle may not inate in
a crash, or they could even inate without
a crash. To help avoid injury to yourself
or others, have your vehicle serviced right
away if the airbag readiness light stays on
after you start your vehicle.
The airbag readiness light should ash for a
few seconds when you turn the ignition key
to RUN. If the light doesn’t come on then, have it
xed so it will be ready to warn you if there is
a problem.
223
ProCarManuals.com

Passenger Airbag Status Indicator
Your vehicle has the passenger sensing system.
Your instrument panel has a passenger airbag
status indicator.
When the ignition key is turned to RUN or START,
the passenger airbag status indicator will light
ON and OFF, or the symbol for on and off,
for several seconds as a system check. Then,
after several more seconds, the status indicator
will light either ON or OFF, or either the on
or off symbol to let you know the status of the
right front passenger’s frontal airbag and
side impact airbag (if equipped).If the word ON or the on symbol is lit on the
passenger airbag status indicator, it means that
the right front passenger’s airbag or airbags
are enabled (may inate).
{CAUTION:
If the on indicator comes on when you have
a rear-facing child restraint installed in the
right front passenger’s seat, it means that
the passenger sensing system has not
turned off the passenger’s frontal airbag
and seat-mounted side impact airbag
(if equipped). A child in a rear-facing child
restraint can be seriously injured or killed if
the right front passenger’s airbag inates.
This is because the back of the rear-facing
child restraint would be very close to the
inating airbag. Do not use a rear-facing
child restraint in the right front passenger’s
seat if the airbag is turned on.
Passenger
Airbag Status
Indicator – United StatesPassenger Airbag
Status
Indicator – Canada
