2007 SATURN RELAY Owners Manual

Front Seats
Manual Seats
Use the lever located on
the front of the seat to
adjust the seat
forward or rearward.
Pull up on the lever to
unlock the seat.
Slide the seat to where
you want it and
release the lever.
{CAUTION:
You can lose control of the vehicle if you
try to adjust a manual driver’s seat while
the vehicle is moving. The sudden
movement could startle and confuse you,
or make you push a pedal when you do
not want to. Adjust the driver’s seat only
when the vehicle is not moving.
To make sure the seat is locked into place, try to
move the seat back and forth with your body.
9
ProCarManuals.com

Power Seats
If the vehicle has power
seats, the controls used
to operate them are
located on the outboard
side of the seats.
To adjust the seat, do any of the following:
Move the seat forward or rearward by sliding
the control forward or rearward.
Raise or lower the front part of the seat
cushion by moving the front of the control up
or down.
Raise or lower the rear part of the seat
cushion by moving the rear of the control up
or down.
Heated Seats
Your vehicle may have this feature. If it does, the
heated seat buttons are located on the climate
control panel.
This feature will heat the lower cushions of the
driver’s and front passenger’s seats.
Press this button once
to turn the heated seat
on to the high setting.
Driver’s Side Button
shown, Passenger’s
Side similar
10
ProCarManuals.com

Both indicator lights next to the heated seat
symbol will be lit to indicate that it is on the high
setting. Press the button a second time to go to the
low setting. One indicator will be lit. Press the
button a third time to turn the heated seat off.
This feature will turn off automatically when
the ignition is turned off.
Reclining Seatbacks
{CAUTION:
You can lose control of the vehicle if you
try to adjust a manual driver’s seat while
the vehicle is moving. The sudden
movement could startle and confuse you,
or make you push a pedal when you do
not want to. Adjust the driver’s seat only
when the vehicle is not moving.
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on the
seatback to be sure it is locked.
Your seats have manual reclining seatbacks. The
lever used to operate them is located on the
outboard side of the seats.
11
ProCarManuals.com

1. Lift the recline lever.
2. Move the seatback to the desired position,
then release the lever to lock the seatback
in place.
3. Push and pull on the seatback to make sure it
is locked.To return the seatback to an upright position, do
the following:
1. Lift the lever fully without applying pressure to
the seatback and the seatback will return to
the upright position.
2. Push and pull on the seatback to make sure it
is locked.
12
ProCarManuals.com

{CAUTION:
Sitting in a reclined position when your
vehicle is in motion can be dangerous.
Even if you buckle up, your safety belts
cannot do their job when you are reclined
like this.
The shoulder belt cannot do its job
because it will not be against your body.
Instead, it will be in front of you. In a
crash, you could go into it, receiving neck
or other injuries.
The lap belt cannot do its job either. In a
crash, the belt could go up over your
abdomen. The belt forces would be there,
not at your pelvic bones. This could cause
serious internal injuries.
For proper protection when the vehicle is
in motion, have the seatback upright.
Then sit well back in the seat and wear
your safety belt properly.
Do not have a seatback reclined if your vehicle is
moving.
Head Restraints
Adjust the head restraint so that the top of the
restraint is at the same height as the top of
the occupant’s head. This position reduces the
chance of a neck injury in a crash.
13
ProCarManuals.com

The height of the head restraints can be adjusted
on the rst and second row seats. Pull the
head restraint up or push it down to adjust it.
The head restraints on the third row seat cannot
be adjusted.
Rear Seats
Rear Seat Operation
The rear seats in your vehicle have levers and
straps used to adjust, remove, and reinstall
the seats. By using the levers and straps in the
correct order, you can easily remove the seats
from the vehicle. If your vehicle has second row
captain chairs with airbags, the seats cannot
be removed.
When reinstalling the seats, make sure the seats
are in the proper positions.
If your vehicle has a second row center console, it
can be removed. SeeSecond Row Center
Console on page 171. Do not put a seat in the
center position because the safety belt cannot be
worn properly in this position. SeeSafety Belts:
They Are for Everyone on page 32.
Bucket Seats
Your vehicle may have bucket seats in the second
row. These seats can be adjusted several
different ways.
Fold and Tumble Feature
{CAUTION:
Using the third row seating position while
the second row is folded, or folded and
tumbled, could cause injury in a sudden
stop or crash. Be sure to return the seat
to the passenger seating position. Push
and pull on the seat to make sure it is
locked into place.
The second row bucket seats can be folded and
tumbled forward. Use this feature for exiting and
entering third row seats, if the vehicle has them.
1. Make sure the adjustable head restraints are
in the fully lowered position.
14
ProCarManuals.com

Notice:Folding a rear seat with the safety
belts still fastened may cause damage to the
seat or the safety belts. Always unbuckle
the safety belts and return them to their normal
stowed position before folding a rear seat.
2. Fold the seatback
at on the seat.
You can do this by either pulling on the nylon
strap, located on the rear right hand side
of the seat, or by lifting the recline lever,
located on the front right hand side of the
seatback.
3. Slide the seat all the way back in this position.4. Release the rear set
of seat hooks from
the oor pins by
pulling the nylon
strap, located at the
base of the seat. Use
the strap to guide the
seat forward.
To return the seat to the original position, do the
following:
1. Align the seat so that the rear hooks on the
seat are over the rear oor pins. Push down
rmly on the rear of the seat so that the
rear hooks attach to the rear oor pins.
2. Try to raise the seat to check that it is locked
to the oor.
15
ProCarManuals.com

3. Pull the nylon strap, located on the rear right
hand side of the seat, or lift the recline lever,
located on the front right hand side of the
seatback, to raise the seatback to the upright
position.
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on the
seatback to be sure it is locked.
4. Push and pull on the seatback to check that it
is locked.
Adjusting the Bucket Seats Forward
and Rearward
There are two adjustment levers on the second
row bucket seats that enable them to move
forward or rearward.
One is located below the front of the seat.
16
