AUTOMATIC TRANSMISSION
SIEMENS TA2005
Vdiag No.: 14-18
Fault finding - Introduction 23A - 2
Fault finding - System operation 23A - 7
Fault finding - Replacement of components 23A - 12
Fault finding - Configurations and programming 23A - 13
Fault finding - Fault summary table 23A - 14
Fault finding - Interpretation of faults 23A - 16
Fault finding - Conformity check 23A - 73
Fault finding - Status summary table 23A - 88
Fault finding - Interpretation of statuses 23A - 89
Fault finding - Parameter summary table 23A - 108
Fault finding - Interpretation of parameters 23A - 109
Fault finding - Dealing with command modes 23A - 125
Fault finding - Interpretation of commands 23A - 126
Fault finding - Customer complaints 23A - 127
Fault finding - Fault Finding Chart 23A - 128
Fault finding - Tests 23A - 137

AUTOMATIC TRANSMISSION
Fault finding - Introduction
23A
23A - 2V5 MR-372-J84-23A100$058.mif
123A
SIEMENS TA2005
Vdiag No.: 14-18AUTOMATIC TRANSMISSION
Fault finding - Introduction
1. SCOPE OF THIS DOCUMENT
This document presents the fault finding procedure applicable to all computers with the following specifications:
2. PREREQUISITES FOR FAULT FINDING
Documentation type
Fault finding procedures (this manual):
–Assisted fault finding (integrated into the diagnostic tool), Dialogys.
Wiring Diagrams:
–Visu-Schéma (CD-ROM), paper.
Type of diagnostic tools
–CLIP
Special tooling required
3. RECAP
Procedure
To run fault finding on the vehicle computers, switch on the ignition.
Proceed as follows:
–Connect the diagnostic tool and perform the required operations. Vehicle(s): MEGANE II and SCENIC II
Function concerned: Automatic transmissionName of computer: Siemens TA 2005
Vdiag No.: 14-18
Special tooling required
Multimeter
Elé. 1681Universal bornier
WARNING
Computer supply for the fault finding procedure:
To run fault finding on the vehicle computers, proceed as follows:
–Place the vehicle's card in the card reader (keyless vehicle scenario 1 (entry level, not hands-free) and
scenario 2 (top of the range, hands-free),
–Press and hold the Start button (more than 5 seconds) outside start-up conditions,
–Then connect the diagnostic tool and perform the required operations.
DP0TA2005_V14_PRELI/DP0TA2005_V18_PRELI
MR-372-J84-23A100$058.mif

AUTOMATIC TRANSMISSION
Fault finding - Introduction
23A
23A - 3V5 MR-372-J84-23A100$058.mif
SIEMENS TA2005
Vdiag No.: 14-18
Faults
Faults are declared either present or stored (depending on whether they appeared in a certain context and
disappeared since, or whether they remain present but have not been diagnosed within the current context).
The present or stored status of faults should be taken into consideration when the diagnostic tool is switched on
after the + after ignition feed (without any system components being active).
For a present fault, apply the procedure described in the Interpretation of faults section.
For a stored fault, note the faults displayed and apply the instructions in the Notes section.
If the fault is confirmed when the instructions in the Notes section are applied, the fault is present. Deal with the
fault.
If the fault is not confirmed, check:
–the electrical lines which correspond to the fault,
–the connectors for these lines (for oxidation, bent pins, etc.),
–the resistance of the component detected as faulty,
–the condition of the wires (melted or split insulation, wear).
Conformity check
The aim of the conformity check is to check data that does not produce a fault on the diagnostic tool because the
data is inconsistent. Therefore, this stage is used to:
–carry out fault finding on faults that do not have a fault display, and which may correspond to a customer
complaint,
–check that the system is operating correctly and that there is no risk of a fault recurring after repairs.
This section gives the fault finding procedures for statuses and parameters and the conditions for checking them.
If a status is not behaving normally or a parameter is outside the permitted tolerance values, consult the
corresponding fault finding page.
Customer complaints - Fault finding chart
If the test with the diagnostic tool is OK but the customer complaint is still present, the fault should be processed by
customer complaint.
A synopsis of the general procedure to follow is provided on the following page in
the form of a flow chart.

AUTOMATIC TRANSMISSION
Fault finding - Introduction
23A
23A - 4V5 MR-372-J84-23A100$058.mif
SIEMENS TA2005
Vdiag No.: 14-18
4. FAULT FINDING PROCEDURE
Perform a pre-diagnostic on the
system
Print the system fault finding log
(available on CLIP and in the
Workshop Repair Manual or
Technical Note)
Connect CLIP
no
Dialogue with
computer?
yes
Read the faults
no
Faults
present
yes
Deal with present faults
Deal with stored faults
no
The cause is
still presentFault
solved
yes
Refer to ALP No. 1
Conformity check
no
The cause is
still presentFault
solved
yes
Use fault finding charts
(ALPs)
no
The cause is
still presentFault
solved
yes
Contact the Techline with the
completed fault finding log

AUTOMATIC TRANSMISSION
Fault finding - Introduction
23A
23A - 5V5 MR-372-J84-23A100$058.mif
SIEMENS TA2005
Vdiag No.: 14-18
4. FAULT FINDING PROCEDURE (continued)
Wiring check
Fault finding problems
Disconnecting the connectors and/or manipulating the wiring harness may temporarily remove the cause of a fault.
Electrical measurements of the voltage, resistance and insulation are generally correct, especially if the fault is not
present when analysing (stored fault).
Visual inspection
Look for damage under the bonnet and in the passenger compartment.
Carefully check the fuses, insulators and wiring harness routing.
Look for signs of oxidation.
Tactile inspection
While manipulating the wiring harness, use the diagnostic tool to note any change in fault status from stored or
present.
Check that the connectors are correctly locked.
Apply light pressure to the connectors.
Twist the wiring harness.
If there is a change in status, try to locate the source of the fault.
Inspection of each component
Disconnect the connectors and check the appearance of the clips and tabs, as well as the crimping (no crimping on
the insulating section).
Check that the clips and tabs are correctly locked in the sockets.
Make sure that no clips or tabs have been dislodged during connection.
Check the clip contact pressure using an appropriate model of tab.
Check the continuity/insulation
Check the continuity of entire lines, then section by section.
Look for a short circuit to earth, to + 12 V or to another wire.
If a fault is detected, repair or replace the wiring harness.

AUTOMATIC TRANSMISSION
Fault finding - Introduction
23A
23A - 6V5 MR-372-J84-23A100$058.mif
SIEMENS TA2005
Vdiag No.: 14-18
5. FAULT FINDING LOG
You will always be asked for this log:
–when requesting technical assistance from Techline,
–for approval requests when replacing parts for which approval is mandatory,
–to be attached to monitored parts for which reimbursement is requested. The log is needed for warranty
reimbursement, and enables better analysis of the parts removed.
6. SAFETY ADVICE
Safety rules must be observed during any work on a component to prevent any damage or injury:
–check the battery voltage to avoid incorrect operation of computer functions,
–use the appropriate tools,
–immobilise the vehicle for all tests in the workshop on the automatic transmission with the engine running. IMPORTANTIMPORTANT
Any fault on a complex system requires thorough fault finding with the appropriate tools. The
FAULT FINDING LOG, which should be completed during the procedure, enables you to keep
track of the procedure which is carried out. It is an essential document when consulting the
manufacturer.
IT IS THEREFORE MANDATORY TO FILL OUT A FAULT FINDING LOG EACH TIME FAULT FINDING IS
CARRIED OUT.

Fault finding - System operation23A
23A - 7V5 MR-372-J84-23A100$116.mif
SIEMENS TA2005
Vdiag No.: 14-18AUTOMATIC TRANSMISSION
Fault finding - System operation
GENERAL OPERATION
The automatic transmission on this model is a DP0, which is also found on other Renault vehicles including the
Clio II, Kangoo or Mégane.
The automatic transmission computer controls gear-shifting based on several parameters, among them engine
torque and the type of driving adopted by the driver.
All signals travel to the computer by wire, except for those from the injection computer, which use the multiplex
network.
Fault finding on the computer is carried out via the multiplex network (multiplex line).
SYSTEM OPERATION
Multifunction switch (CMF) statuses:
Note:
On this vehicle, contact S1 of the multifunction switch depends on status ET128 Upper sequential lever switch.
Lever positionMultifunction switch contact
P/N S2 S3 S4
PCLOSEDOPENCLOSED CLOSED
RCLOSEDOPEN OPEN OPEN
NCLOSED CLOSEDOPENCLOSED
DCLOSED CLOSED CLOSEDOPEN
M CLOSED CLOSED CLOSEDOPEN
+CLOSED CLOSED CLOSEDOPEN
-CLOSED CLOSED CLOSEDOPEN
MR-372-J84-23A100$116.mif

AUTOMATIC TRANSMISSION
Fault finding - System operation
23A
23A - 8V5 MR-372-J84-23A100$116.mif
SIEMENS TA2005
Vdiag No.: 14-18
Sequential lever switch statuses:
Note:
The vehicle does not have a 3
rd gear hold (D3).
Lever position Upper sequential lever switch Lower sequential lever switch
PACTIVE ACTIVE
RACTIVE ACTIVE
NACTIVE ACTIVE
DACTIVE ACTIVE
M INACTIVE INACTIVE
+INACTIVEACTIVE
-ACTIVEINACTIVE
