EI-20
FENDER PROTECTOR
Revision: 2007 April2007 M35/M45
FENDER PROTECTORPFP:63840
Removal and InstallationNIS0024J
REMOVAL
1. Remove rear end screw of fender protector (rear).
2. Remove clips of fender protector (rear).
3. Remove plastic clamp from wheelhouse arches, and then remove fender protector (rear) from wheel
house.
4. Remove screws of front under cover.
5. Remove front end screw of fender protector (front).
6. Remove front end clip of fender protector (front).
7. Remove fender protector (front) from wheel house.
INSTALLATION
Install in the reverse order of removal.
1. Fender protector (front) 2. Fender protector (rear)
PIIB2940J

FENDER PROTECTOR
EI-21
C
D
E
F
G
H
J
K
L
MA
B
EI
Revision: 2007 April2007 M35/M45
Rear Wheel House ProtectorNIS0024K
REMOVAL AND INSTALLATION
REMOVAL
1. Remove screw of rear portion wheel house protector. (rear bumper side)
2. Remove screw of front portion wheel house protector. (center mud guard side)
3. Remove clips of wheel house protector.
4. Remove resin nuts of arch portion wheel house protector and remove rear wheel house protector.
INSTALLATION
Install in reverse order of removal.
1. Rear wheel house protector
PIIB3602J

EI-22
CENTER MUD GUARD
Revision: 2007 April2007 M35/M45
CENTER MUD GUARDPFP:76850
Removal and InstallationNIS0024L
REMOVAL
1. Remove screw and nuts of wind deflector and remove wind
deflector.
2. Remove screws of mudguard front/rear side.
3. Remove screws of mudguard lower side.
4. Fully open front door and rear door.
5. Remove clips from back of mudguard using clip clamp remover.
6. Remove center mudguard from body side.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
When installing center mud guard, make sure that clips are securely fitted in panel holes on body, and
then press them in.
1. Center mud guard
PIIB2941J
PIIB3973J

EI-24
FLOOR SIDE FAIRING
Revision: 2007 April2007 M35/M45
FRONT UNDER COVER (REAR)
Removal
1. Remove front under cover (rear) mounting bolts.
2. Remove front under cover (rear).
Installation
Install in the reverse order of removal.
FLOOR UNDER COVER
Removal
1. Remove floor under cover mounting bolts, nuts and clips.
2. Remove floor under cover.
Installation
Install in the reverse order of removal.
REAR UNDER COVER
Removal
1. Remove rear under cover mounting bolts.
2. Remove rear under cover.
Installation
Install in the reverse order of removal.
REAR DIFFUSER
Removal
1. Remove rear diffuser mounting bolts, nuts and clips.
2. Remove rear diffuser.
Installation
Install in the reverse order of removal.

ROOF SIDE MOLDING
EI-25
C
D
E
F
G
H
J
K
L
MA
B
EI
Revision: 2007 April2007 M35/M45
ROOF SIDE MOLDINGPFP:73854
Removal and InstallationNIS0024O
REMOVAL
1. Apply protective tape around roof side molding.
2. Disengage clips while pinching molding from rear end of rear
window to front end of front window, and then remove roof side
molding.
CAUTION:
Front and rear ends of roof side molding are placed under
the body side. Pull them out after disengaging plastic clip
joints.
NOTE:

Molding fasteners of front windshield glass and rear window glass are secured with rivet. Remove and
install front windshield glass and rear window glass when replacing the molding fasteners.

Heat adhesive tape interface using a dryer, and then peel roof side molding clips (body side) using long-
nose pliers.
1. Roof side molding 2. Roof outer panel 3. Windshield glass
4. Clip (body side) 5. Molding fastener 6. Rivet
7. Clip (molding side) 8. Body side outer clip
PIIB2753J
PIIB2749J

EI-26
ROOF SIDE MOLDING
Revision: 2007 April2007 M35/M45
INSTALLATION
1. Place roof side molding on roof groove, and then insert the end into front fender.
2. Align roof side molding clips (molding side) (2),(3), and (4) of front pillar with fastener position, and then
insert roof side molding clip (molding side) (1).
3. Insert roof side molding clips (molding side) of front pillar in order of (2) to (4) into molding fastener.
4. Insert body side outer clips of roof in the order of (5) to (9).
5. Insert rear end of roof side molding into trunk lid.
6. Temporarily set roof side molding clips (molding side) of rear pillar on fasteners and insert them in the
order of (10) to (13).
CAUTION:
Be careful not to damage the body.
PIIB4179J

SIDE GUARD MOLDING
EI-31
C
D
E
F
G
H
J
K
L
MA
B
EI
Revision: 2007 April2007 M35/M45
SIDE GUARD MOLDINGPFP:76840
Removal and InstallationNIS0024R
REMOVAL
1. Apply masking tape around outer circumference of side guard molding.
2. Remove double-faced adhesive tapes with (wide) resin spatula. Disengage clips and remove side guard
molding (front / rear).
INSTALLATION
1. Remove double-faced adhesive tape remaining on vehicle.
2. Clean contact surface of vehicle (to side guard molding), and install side guard molding to specified holes.
NOTE:
To re-use side guard molding, follow above steps 1 and 2 as well; clean surface after removing double-
faced adhesive tape, apply new double-faced adhesive tape and then install side guard molding to vehi-
cle.
CAUTION:

Do not let air between contact surfaces when installing.

To secure contact, do not wash vehicle within 24 hours after installation.
1. Side guard molding (front) 2. Side guard molding (rear) 3. Specified holes
PIIB2937J

EI-32
DOOR PARTING SEAL
Revision: 2007 April2007 M35/M45
DOOR PARTING SEALPFP:80838
Removal and InstallationNIS0024S
FRONT DOOR PARTING SEAL
Removal
1. Fully open front door.
2. Remove front door parting seal (front side) mounting plastic clips.
3. Disengage the joint between front door parting seal (front side) and front door panel, and then remove
front door parting seal (front side).
4. Disengage front door parting seal (lower side) mounting plastic clips, and then remove front door parting
seal (lower side).
Installation
Install in the reverse order of removal.
REAR DOOR PARTING SEAL
Removal
1. Fully open rear door.
2. Disengage the joint between rear door parting seal (front side) and rear door panel, and then remove rear
door parting seal (front side).
3. Disengage rear door parting seal (lower side) mounting plastic clips, and then remove rear door parting
seal (lower side).
Installation
Install in the reverse order of removal.
1. Front door parting seal (front side) 2. Front door parting seal (lower side) 3. Rear door parting seal (lower side)
4. Rear door parting seal (front side) 5. Door inner panel
PIIB3974J
