If the driver’s power window fuse is
removed, the AUTO function of the
driver’s window will be disabled. To
reset the AUTO function, see page
.
If
you cannot drive the vehicle
wi thout fixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
from one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accesso ry
power socket or radio).
If you replace the blown fuse with a
spare fuse that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
fuse with one of the correct rating as
soon as you can.
Look
for a blown wire inside the
fuse.Ifitisblown,replacethefuse
withoneofthesparefusesofthe
same rating or lower. If
the radio fuse is removed, the
audio system will disable itsel f. The
nexttimeyouturnontheradioyou
will see ‘‘CODE’’ in the f requency
display. Use the preset bars to enter
thecode(seepage ). If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem in your vehicle.
Leave the blown fuse in that
circuit and have your vehicle
checked by a qualif ied technician.
5. 6.
106 162
Fuses
T aking Care of t he Unexpect ed
293
BLOWN
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper
rating f or the circuit, install one with
a lower rating.

µ
µ
µ´
µ
µ
Î
Î
Î Î Î
Î
Î
Î
Î
If equipped
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6 13
14
15
16
17
18
19
20
21
22
23
If equipped
7
8
9
10
11
10 A
10 A
15 A
10 A
10 A
7.5 A 15 A
15 A
15 A
7.5 A Horn, Stop
Defroster
Back Up, ACC
Hazard
Option 1
Not Used
Cooling Fan
Condenser Fan
Heater Motor
Seat
Battery
BIGIMain
Power Window
Spare Fuses
20 A
20 A
40 A
15 A
40 A
30 A
30 A
40 A
40 A
120 A 50 A
50 A
(7.5 A) 20 A
40 A
20 A
15 A
(20 A) (20 A)
(7.5 A) (20 A) 7.5 A
(20 A)
Back Light
VSA FSR
VSA MTR
VTM-4
Front Accessory Sockets
Electric Brake Small Lights
Stop/Turn Lights
Charge
TPMS
Moonroof
Left Headlight Low Beam
Not Used
Left Headlight High Beam
Small Lights
Right Headlight High Beam
Right Headlight Low Beam
Back Up
FI ECU (PCM)
DBW
Not Used
Heated Seat
MG Clutch
:
:
No.
No. No.
No.
Amps. Circuits Protected
Amps.
Amps. Amps. Circuits Protected Circuits Protected Circuits Protected
24 28
Fuse Locations
294
PRIMARY UNDER-HOOD FUSE BOX
SECONDARY UNDER-HOOD FUSE BOX

µ
µ
µ
µ
Î
ÎÎ
Î
ÎÎ
ÎÎ
ÎÎ
No. No. Amps.
Amps. Circuits Protected Circuits Protected
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
If equipped 18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
15 A
15 A
7.5 A
7.5 A 10 A
7.5 A 20 A
20 A
20 A
20 A
20 A
7.5 A
7.5 A
7.5 A
(7.5 A)
7.5 A
15 A
(10 A) 15 A
20 A
10 A
7.5 A 20 A
10 A
7.5 A 30 A
(10 A)
(20 A)
(20 A) Bed Lights
IG Coil
Daytime Running Light
LAF
Radio
Interior Lights
Back Up
Door Lock
Rear Accessory Socket
OPDS
IG, Wiper
Not Used
Not Used
Not Used IG ACG
IG Fuel Pump
IG Washer
IG Meter
IG SRS
IGP
Left Rear Window
Right Rear Window
Passenger’s Window
Back Window
Driver’s Window
Not Used
IG HAC
IG VSA/ABS
ACC
Not Used
: :Canadian models
Driver’s Power Seat Lumbar
Driver’s Power Seat Sliding
Driver’s Power Seat Reclining
Fuse Locations
T aking Care of t he Unexpect ed
295
INTERIOR FUSE BOX

If , due to damage, your vehicle must
be towed with all f our wheels on the
ground, do the f ollowing:Release the parking brake.
Start the engine.
Shif t to D f or several seconds,
then to N.
Turn of f the engine. With all f our wheels on the ground,
it is best to tow the vehicle no farther
than 50 miles (80 km), and keep the
speedbelow35mph(55km/h).
If your vehicle needs to be towed,
call a prof essional towing service or
organization. Never tow your vehicle
with just a rope or chain. It is very
dangerous.
The operator will load
your vehicle on the back of a truck.
Any other method of towing will
damage the drive system. When you
contact the towing agency, inf orm
them a f lat-bed is required.
Emergency Towing
The only way you can saf ely tow
your vehicle is with f lat-bed
equipment.
296
Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission or start the
engine, your vehicle must be
transported with the all f our wheels of f
the ground. The steering system can be damaged if
the steering wheel is locked. Leave the
ignition switch in the ACCESSORY (I)
position, and make sure the steering
wheel turns f reely bef ore you begin
towing.
Towing your vehicle with two tires on
the ground will damage parts of the
4WD system. It should be transported
on a f lat-bed truck or trailer. Trying to lif t or tow your vehicle by the
bumpers will cause serious damage.
The bumpers are not designed to
support the vehicle’s weight.

If your vehicle gets stuck in sand,
mud, or snow, call a towing service
to pull it out (see the previous page).
For very short distances, such as
f reeing the vehicle, you can use the
tie down hooks on the lower lef t of
the f ront and rear bumpers.
CONT INUED
If Your Vehicle Gets Stuck
T aking Care of t he Unexpect ed
297
FRONTREAR
TIE DOWN
HOOK TIE DOWN
HOOK
‘‘Rocking’’ your vehicle between
f orward and reverse gear or revving up
the engine and allowing the wheels to
spin f reely at high speeds can damage
the automatic transmission. Use a tow
service to prevent transmission damage.

If Your Vehicle Gets Stuck
298
To avoid damage to your vehicle, use
the tie down hooks f or straight, f lat
ground towing only. Do not tow at an
angle. These hooks should not be used
f or open-road towing.

Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
emissions control systems.................
Identif ication Numbers .300
................................
Specif ications .302
DOT Tire Quality Grading
......................
(U.S. Vehicles) .304
Unif orm Tire Quality ..................................
Grading .304
.................................
Treadwear .304
......................................
Traction .304
.............................
Temperature .305
.................................
Tire Labeling .306 .......................
Emissions Controls . 307
.....................
The Clean Air Act .307
Crankcase Emissions Control
....................................
System .307
Evaporative Emissions Control ....................................
System .307
Onboard Ref ueling Vapor ................................
Recovery .307
...
Exhaust Emissions Controls .308
....................
PGM-FI System .308
Ignition Timing Control
................................
System .308
Exhaust Gas Recirculation ...................
(EGR) System .308
Three Way Catalytic ...........................
Converter .308
....................
Replacement Parts .308
..
Three Way Catalytic Converter .309
..............
State Emissions Testing .310
T echnical Inf ormation
Technical Inf ormation
299

Your vehicle has several identif ying
numbers in various places.
The vehicle identif ication number
(VIN) is the 17-digit number your
dealer uses to register your vehicle
f or warranty purposes. It is also
necessary f or licensing and insuring
your vehicle. The easiest place to
find the VIN is on a plate fastened to
the top of the dashboard. You can
seeitbylookingthroughthe
windshield on the driver’s side. It is
also on the certification label
attached to the driver’s doorjamb,
and is stamped on the engine
compartment bulkhead. The VIN is
also provided in bar code on the
certif ication label.
