2007 HONDA RIDGELINE Owners Manual

Forbettertractiononallsurfaces,
accelerate slowly and gradually build
up speed. If you try to start too fast
on wet soil, mud, snow, or ice, you
might not have enough traction to
get underway, and you may dig
yourself a hole. Starting with the
shif t lever in second (2) gear will
help you have a smoother start on
snow or ice.
Keep in mind that you will usually
need more time and distance to
brake to a stop on unpaved surf aces.
Avoid hard braking. Do not ‘‘pump’’
the brakes; let the anti-lock braking
system pump them f or you.Your vehicle is not equipped with
undercarriage guards to protect key
components, so take care to avoid
rocks, tree stumps, and other
obstacles in your path.
Because your vehicle has a higher
center of gravity than a conventional
passenger vehicle, driving a wheel
over a tall object, or allowing a wheel
to drop into a deep hole, can cause
your vehicle to tip or roll over.
If you can’t clearly see all conditions
or obstacles on a slope, walk the
slope bef ore you drive on it. If you
have any doubt whether or not you
can saf ely drive on the slope, don’t
do it. Find another route.
If you are driving up a hill and f ind
that you cannot continue,
. Your vehicle could roll
over. Slowly back down the hill,
f ollowing the same route you took up
the hill.
do not try to
turn around
A ccelerating and Braking A voiding ObstaclesDriving on Slopes
Of f -Highway Driving Guidelines
Driving
229

The banks and surface under the
water provide good traction. The
water may hide hazards such as
rocks, holes, or mud.
Before
driving through water, stop,
get out if necessary, and make sure
that:
If you decide it is safe to drive
through water, choose a suitable
speed, and proceed without shifting,
changing speed s, stopping, or
shutting off the engine.
Do not try to cross water at high
speeds, as this may cause severe
damage to the cooling system or
result in loss of control.
After driving through water, test
your brakes. If they got wet, gently
‘‘pump’’ them while driving slowly
until they operate normally.
If the water is deeper than the wheel
hubs, some additional service may
be required. This service is not
covered by your warranties.
The
water is not flowing too fast.
Deep rushing water can sweep you
downstream. Even very shallow
rushingwatercanwashthe
ground from under your tires and
cause you to lose traction and
possibly roll over.
The
ban ks are sloped so you can
drive out.
The
water is not deep enough to
cover your wheel hubs, axles, or
exhaust pipe. You could stall and
not be able to restart your engine.
The water can also damage
important vehicle components. If
you get stuck, and cannot get
unstuck with the VTM-4 system,
engage the VTM-4 Lock (see page
), and carefully try to go in the
direction (forward or reverse) that
you think will get you unstuck. Do
notspinthetiresathighspeeds.It
will not help you get out and may
cause damage to the transmission or
VTM-4 system.
If you are still unable to free yourself,
your vehicle is equipped with front
and rear tow hooks designed f or this
purpose (see page ). 297
203
If You Get Stuck
Crossing a Stream
Of f -Highway Driving Guidelines
230

Use a nylon strap to attach your
vehicle to the recovery vehicle, and
carefully take out the slack in the
strap. Once the strap is tight, the
recovery vehicle should apply force.
Re me mber that the recovery vehicle
needs good traction to avoid
becoming stuck, too.
You should never use a jack to try to
get unstuck. Your vehicle could
easily slip off the jack and hurt you
or someone else. You
may safely tow a trailer off-road
if you follow these guidelines:
Do not exceed the trailer weight
or tongue limits (see page ).
Stay on smooth, level dirt roads,
and avoid driving in hilly terrain.
Allow extra room f or starting,
stopping, and turning.
Slow down if you encounter bumps
or other obstacles. 214
Towing a Trailer Off-Road
Of f -Highway Driving Guidelines
Driving
231

This section explains why it is
important to keep your vehicle well
maintained and how to follow basic
maintenance safety precautions.
If you have the skills and tools to
perform more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer. This section also includes
instructions on how to read the
maintenance minder messages on
the information display, a
maintenance record, and instructions
for simple maintenance tasks you
may want to take care of yourself. ......................
Maintenance Saf ety .234
....................
Maintenance Minder .235
....................
Maintenance Record .243
..............................
Fluid Locations .245
........................
Adding Engine Oil .246
Changing the Engine Oil and
...........................................
Filter .247
..............................
Engine Coolant .249
....................
Windshield Washers .250
....
Automatic Transmission Fluid .251
.................
Rear Dif f erential Fluid .252
.............
Transf er Assembly Fluid .253
....................................
Brake Fluid .253
....................
Power Steering Fluid .254
....................................
Timing Belt .254
.............................................
Lights .255
................
Cleaning the Seat Belts .261
.....................................
Floor Mats .261
..................
Dust and Pollen Filter .262
.................................
Wiper Blades .262
...........................................
Wheels .264
...............................................
Tires .265
...................
Checking the Battery .270
.............................
Vehicle Storage .272
315
Maintenance
Maint enance
233

To eliminate potential hazards, read
the instructions bef ore you begin,
and make sure you have the tools
and skills required. All service items not detailed in this
section should be perf ormed by a
certif ied technician or other qualif ied
mechanic.Make sure your vehicle is parked
on level ground, the parking brake
is set, and the engine is of f .
To clean parts, use a commercially
available degreaser or parts
cleaner, not gasoline.
To reduce the possibility of f ire or
explosion, keep cigarettes, sparks,
and flames away from the battery
and all f uel-related parts.
Wear eye protection and
protective clothing when working
with the battery or compressed air. Be sure there is
adequate ventilation whenever you
operate the engine. Some of the most important saf ety
precautions are given here. However,
we cannot warn you of every
conceivable hazard that can arise in
perf orming maintenance. Only you
can decide whether or not you
should perf orm a given task.Do
not run the engine unless
instructed to do so.
Let the
engine and exhaust system cool
down bef ore touching any parts.
Maintenance Saf ety
Important Saf ety Precautions
Carbon Monoxide poison f rom
engine exhaust.
Potential Vehicle Hazards Injury f rom moving parts.
Burns f rom hot parts.
234
Improperly maintaining this
vehicle, or failing to correct a
problem before driving can
cause a crash in which you can
be seriously hurt or killed.
Always follow the inspection
and maintenance
recommendations and
schedules in this owner’s
manual. Failure to properly follow
maintenance instructions and
precautions can cause you to
be seriously hurt or killed.
Always follow the procedures
and precautions in this owner’s
manual.

µ
µ
µ
µ
µ
µ
µ
µ
µ
µ µ
µ
CONTINUED
Calculated Engine
Oil Life (%)
100 % 91 %
90 % 81 %
80 % 71 %
70 % 61 %
60 % 51 %
50 % 41 %
40 % 31 %
30 % 21 %
20 % 16 %
15 % 11 %
10 % 6 %
5% 1%
0% Displayed
Engine Oil Life (%)
100 %
90 %
80 %
70 %
60 %
50 %
40 %
30 %
20 %
15 %
10 %
5%
0%
The remaining engine oil life is
displayed on the engine oil life
display according to the table shown
below.
Based on the engine operating
conditions and accumulated engine
revolutions, the onboard computer in
your vehicle calculates the remaining
engine oil life and displays it as a
percentage. Your vehicle displays engine oil life
and maintenance service items on
the information display to show you
when you should have your dealer do
engine oil replacement and indicated
maintenance service.
To see the current engine oil life,
turn the ignition switch to the ON
(II) position, and press the SELECT
button repeatedly until the engine oil
life display appears (see page ). 70
Maintenance Minder
Engine Oil L if e Display
Maint enance
235
MAINTENANCE MINDER
INDICATOR
ENGINE OIL LIFE
DISPLAY

The maintenance item code(s)
indicate the main and sub items
required at the time of the oil change
(see page ).
If the engine oil lif e is 15 percent or
less, you will see ‘‘SERVICE dUE
SOON’’ message in the inf ormation
display every time you turn the
ignition switch to the ON (II)
position. The maintenance minder
indicator will also come on, and the
maintenance item code(s) for other
scheduled maintenance items
needing service will be displayed
below the message. When the remaining engine oil lif e is
less than 5 percent, you will see a
‘‘SERVICE dUE NOW’’ message
along with the same maintenance
item code(s), every time you turn the
ignition switch to the ON (II)
position.
The message changes between
SERVICE and dUE SOON
repeatedly.
The message changes between
SERVICE and dUE NOW repeatedly.
242
Maintenance Minder
236
MAINTENANCE ITEM CODES MAINTENANCE MAIN ITEM
MAINTENANCE SUB ITEMS MAINTENANCE ITEM CODES
MESSAGE
MESSAGE
