2007 CHEVROLET COLORADO Owners Manual

Ashtray(s) and Cigarette Lighter
Your vehicle may have a removable ashtray
and cigarette lighter.
The ashtray is located in the center console
area. The ashtray can be removed for cleaning.
When the ashtray is removed, this area can
also be used as a cupholder.
Notice:If you put papers, pins, or other
ammable items in the ashtray, hot cigarettes
or other smoking materials could ignite
them and possibly damage your vehicle.
Never put ammable items in the ashtray.
To use the lighter, press it in all the way, and let
go. When it is ready, it will pop back out by itself.
Notice:Holding a cigarette lighter in while
it is heating does not let the lighter back
away from the heating element when it is hot.
Damage from overheating can occur to the
lighter or heating element, or a fuse could
be blown. Do not hold a cigarette lighter
in while it is heating.
Climate Controls
Climate Control System
With this system you can control the heating,
cooling, and ventilation for your vehicle.
177

Temperature Knob
The left knob on the control panel is used to
adjust the temperature of the air in the vehicle.
Turn the knob clockwise or counterclockwise
to increase or decrease the temperature.
Fan Knob
9
(Fan):The center knob on the control panel
is used to control the fan speed. Turn the knob
clockwise or counterclockwise to increase or
decrease the fan speed.
If the knob is set on “0” (zero), some outside air
will still enter the vehicle and will be directed
according to the position of the mode knob.
Mode Knob
The right knob on the control panel is used to
direct the airow inside your vehicle. Turn the
knob to select one of the following modes:
H(Vent):Select this mode to direct air to
the instrument panel outlets.
\(Bi-Level):Select this mode to direct
approximately half of the air to the instrument
panel outlets, and the remaining air to the
oor outlets and the defroster and side window
outlets. Cooler air is directed to the upper outlets
and warmer air to the oor outlets.
[(Floor):Select this mode to direct air to the
oor outlets. Recirculation is disabled in this mode
because interior window could fog under some
conditions. If this occurs, see “Defogging and
Defrosting” following.
Mode Buttons
@
(Recirculation):This mode recirculates air
inside the cabin, and prevents outside air from
coming in the vehicle. It can be used to prevent
outside odors from entering your vehicle and
cool the air inside your vehicle more quickly. Press
this button to turn the recirculation mode on or
off. An indicator light on the button will come on to
let you know the recirculation mode is activated.
178

Recirculation is only available in the bi-level and
vent modes. It should only be used while in bi-level
and vent modes. Recirculation is not available,
and the light will not come on or ash while in heat,
oor, oor/defog, or defrost modes.
#(Air Conditioning):Press this button to turn
the air conditioning system on or off. An indicator
light on the button will come on to let you know
the air conditioning is activated. When the system
is on, this setting cools and dehumidies the
air entering your vehicle.
The air conditioning will not function if the fan is
turned off.
You may notice a slight change in engine
performance when the air conditioning compressor
shuts off and turns on again. This is normal.
The system is designed to make adjustments to
help with fuel economy while still maintaining
the selected temperature.The air conditioning system removes moisture
from the air, so you may sometimes notice a
small amount of water dripping underneath
your vehicle while idling or after turning off the
engine. This is normal.Defogging and Defrosting
Fog on the inside of windows is a result of high
humidity (moisture) condensing on the cool
window glass. This can be minimized if the
climate control system is used properly. There
are two modes to clear fog or frost from your
windshield and side windows. Use the defog
mode to clear the windows of fog or moisture and
warm the passengers. Use the defrost mode to
remove fog or frost from the windshield more
quickly. For best results, clear all snow and
ice from the windshield before defrosting.
179

Turn the mode knob on the climate control panel
clockwise to select the defog or defrost modes.
/(Floor/Defog):This mode directs the air to the
windshield, the side window outlets, and to the oor
outlets. When you select this mode, the system
runs the air conditioning compressor unless the
outside temperature is near freezing or below.
Recirculation is not available in this mode.
0(Defrost):This mode directs most of the
air to the windshield, and the side window outlets.
When you select this mode, the system runs
the air conditioning compressor unless the
outside temperature is near, or below freezing.
Recirculation is not available in this mode.
Do not drive the vehicle until all the windows
are clear.
Outlet Adjustment
Use the thumbwheel on the outlets to change the
direction of the air ow.
Lift up or push down on the thumbwheel located
in the center of the outlet to direct the air up
or down, or slide the thumbwheel to the left or
right to direct the airow from side-to-side.
Operation Tips

Clear away any ice, snow or leaves from the
air inlets at the base of the windshield that
may block the ow of air into your vehicle.
Use of non-GM approved hood deectors may
adversely affect the performance of the system.
Keep the path under the front seats clear of
objects to help circulate the air inside of your
vehicle more effectively.
180

Warning Lights, Gages,
and Indicators
This part describes the warning lights and
gages on your vehicle. The pictures help to
locate them.
Warning lights and gages can signal that
something is wrong before it becomes serious
enough to cause an expensive repair or
replacement. Paying attention to the warning
lights and gages could also save you or others
from injury.
Warning lights come on when there may be or
is a problem with one of your vehicle’s functions.
As the details show on the next few pages,
some warning lights come on briey when you
start the engine just to let you know they are
working. If you are familiar with this section, you
should not be alarmed when this happens.Gages can indicate when there may be or is a
problem with one of your vehicle’s functions.
Often gages and warning lights work together
to let you know when there is a problem with
your vehicle.
When one of the warning lights comes on and
stays on as you are driving, or when one of
the gages shows there may be a problem, check
the section that tells you what to do about it.
Please follow this manual’s advice. Waiting to
do repairs can be costly and even dangerous.
So please get to know your vehicle’s warning
lights and gages. They can be a big help.
Your vehicle may also have a Driver Information
Center (DIC) that works along with the warning
lights and gages. SeeDriver Information
Center (DIC) on page 198for more information.
181

Instrument Panel Cluster
Your instrument panel cluster is designed to let you know at a glance how your vehicle is running.
You will know how fast you are going, about how much fuel you have used, and many other things
you will need to know to drive safely and economically.
United States automatic transmission version shown, Canada similar
182

Speedometer and Odometer
Your speedometer lets you see your speed in
both miles per hour (mph) and kilometers
per hour (km/h).
Your odometer shows how far your vehicle
has been driven, in either miles (used in the
United States) or kilometers (used in Canada).
The odometer mileage can be checked without the
vehicle running. Simply press the trip information
stem. See “Odometer” underDIC Controls
and Displays on page 198for more information.
You may wonder what happens if your vehicle
needs a new odometer installed. If the new one
can be set to the mileage total of the old odometer,
then it must be. But if it cannot, then it is set at
zero, and a label must be put on the driver’s door
to show the old mileage reading when the new
odometer was installed.
Trip Odometer
Your vehicle has a trip odometer that can tell
you how far your vehicle has been driven since
you last set the trip odometer to zero.
See “Trip Odometer” underDIC Controls and
Displays on page 198for more information.
Tachometer
The tachometer displays the engine speed in
revolutions per minute (rpm).
Notice:If you operate the engine with the
tachometer in the shaded warning area, your
vehicle could be damaged, and the damages
would not be covered by your warranty.
Do not operate the engine with the tachometer
in the shaded warning area.
183

Safety Belt Reminder Light
When the key is turned to ON or START, a chime
will be provided for several seconds to remind
people to buckle their safety belts. The driver
safety belt light will also be provided and stay
on for several seconds, then it will ash for
several more. You should buckle your seat belt.
This chime and light
will be repeated if
the driver remains
unbuckled and the
vehicle is in motion.
If the driver’s belt is buckled, neither the chime
nor the light will be provided.
Passenger Safety Belt
Reminder Light
Several seconds after the key is turned to ON or
START, a chime will sound for several seconds
to remind the front passenger to buckle their
safety belt. This would only occur if the passenger
airbag is enabled. SeePassenger Sensing
System on page 88for more information. The
passenger safety belt light will also come on and
stay on for several seconds, then it will ash
for several more.
This chime and light
are repeated if the
passenger remains
unbuckled and
the vehicle is
in motion.
If the passenger’s safety belt is buckled,
neither the chime nor the light will come on.
184
