2007 CHEVROLET COLORADO Owners Manual

Your vehicle must have a working electrical
system (including adequate battery power) for
the OnStar
®equipment to operate. There are
other problems OnStar®cannot control that
may prevent OnStar®from providing OnStar®
service to you at any particular time or place.
Some examples are damage to important parts
of your vehicle in an accident, hills, tall buildings,
tunnels, weather or wireless phone network
congestion.
Your Responsibility
You may need to increase the volume of your
radio to hear the OnStar®advisor. If the light
next to the OnStar®buttons is red, this means
that your system is not functioning properly
and should be checked by a dealer. If the light
appears clear (no light is appearing), your
OnStar
®subscription has expired. You can
always press the blue OnStar®button to
conrm that your OnStar®equipment is active.
Storage Areas
Glove Box
To open the glove box, pull on the lever.
Cupholder(s)
Your vehicle may have two cupholders located
on the lower part of the front doors as well as
two cupholders located at the front end of
the console. Vehicles with bench seats may
have cupholders attached to the front of the
center seat.
If your vehicle is an extended cab or crew cab
model, your vehicle also has two rear cupholders.
On crew cab models, the cupholders are located
at the front end of the rear center seat cushion.
On extended cab models, the rear seat cupholders
are located on top of the rear center console.
If you have an ashtray, it will use one of the
cupholders.
153

Front Armrest Storage Area
For vehicles with bench seats, you may have a
center armrest storage area. Lift up on the upper
tab located at the front of the armrest to release
the latch. Lift the lid to open the storage area.
For vehicles with bucket seats or uplevel
packages, your vehicle may have a two-tiered
center armrest storage area. Lift up on the upper
tab located at the front of the armrest to release
the latch. Lift the lid to the top storage area.
A second tab is located below the top one and
allows you to access the bottom storage area.
Lift up on the lower tab to release the latch.
Then, raise the lid of the lower storage area.
The upper storage area will lift up with the lid
of the lower storage area.
To close the storage area(s), lower the lid(s)
until you feel the latch close.
Assist Handles
Your vehicle may have assist handles to be used
when getting out of your vehicle. If your vehicle
has assist handles, they are located above
the doors.
If your vehicle has roof-mounted side impact
air bags, there are assist handles located above
both the driver’s and front passenger’s doors.
Rear Storage Area
If your vehicle is an extended cab model,
it might have storage compartments under
the rear seats.
154

To access the storage compartments, lift the
cushion on the bottom of the rear seats. This
exposes the storage boxes under the seat.
To open a storage box, unhook the bottom and
lift the two latches on each side of the storage box.
155

Lift the lid from the center area to access the
storage box.
Sunroof
Your vehicle may have a sunroof.
The sunroof control
buttons are located
on the headliner.
Q(Open/Vent):Press and hold this button
to vent, and open the sunroof. Release the button
when the desired position is reached.
R(Close):Press and hold this button to close
the sunroof. Release the button when the desired
position is reached.
The sunshade must be opened manually.
156

Instrument Panel Overview........................ 160
Hazard Warning Flashers.......................... 162
Other Warning Devices............................. 162
Horn.......................................................... 162
Tilt Wheel.................................................. 162
Turn Signal/Multifunction Lever.................. 163
Turn and Lane-Change Signals................. 164
Headlamp High/Low-Beam Changer.......... 165
Flash-to-Pass............................................ 165
Windshield Wipers..................................... 165
Windshield Washer.................................... 166
Cruise Control........................................... 166
Exterior Lamps.......................................... 170
Headlamps on Reminder........................... 171
Daytime Running Lamps (DRL)................. 171
Automatic Headlamp System..................... 172
Fog Lamps................................................ 173
Exterior Cargo Lamps................................ 174
Interior Lamps........................................... 174
Instrument Panel Brightness...................... 174
Dome Lamp.............................................. 174Dome Lamp Override................................ 175
Exit Lighting.............................................. 175
Electric Power Management...................... 175
Battery Run-Down Protection..................... 175
Accessory Power Outlet(s)........................ 176
Ashtray(s) and Cigarette Lighter................ 177
Climate Controls......................................... 177
Climate Control System............................. 177
Outlet Adjustment...................................... 180
Warning Lights, Gages, and Indicators..... 181
Instrument Panel Cluster........................... 182
Speedometer and Odometer...................... 183
Trip Odometer........................................... 183
Tachometer............................................... 183
Safety Belt Reminder Light........................ 184
Passenger Safety Belt Reminder Light....... 184
Airbag Readiness Light............................. 185
Passenger Airbag Status Indicator............. 186
Battery Warning Light................................ 188
Up-Shift Light (Manual Transmission)........ 189
Section 3 Instrument Panel
157

Brake System Warning Light..................... 189
Anti-Lock Brake System Warning Light...... 190
Engine Coolant Temperature Gage............ 191
Tire Pressure Light.................................... 191
Malfunction Indicator Lamp........................ 192
Oil Pressure Light..................................... 195
Security Light............................................ 196
Cruise Control Light.................................. 196
Highbeam On Light................................... 196
Daytime Running Lamps (DRL)
Indicator Light........................................ 197
Fuel Gage................................................. 197
Driver Information Center (DIC).................. 198
DIC Controls and Displays........................ 198
DIC Warnings and Messages.................... 202Audio System(s)......................................... 206
Setting the Time........................................ 208
AM-FM Radio............................................ 209
Radio with CD (MP3)................................ 212
Radio with Six-Disc CD............................. 222
Using an MP3........................................... 234
XM Radio Messages................................. 240
Theft-Deterrent Feature............................. 242
Radio Reception........................................ 242
Care of Your CDs..................................... 243
Care of the CD Player.............................. 243
Fixed Mast Antenna.................................. 244
XM™ Satellite Radio Antenna System....... 244
Chime Level Adjustment............................ 244
Section 3 Instrument Panel
158

✍NOTES
159

Instrument Panel Overview
Manual Transmission shown, Automatic Transmission similar
