2006 MITSUBISHI COLT engine oil

GENERAL INFORMATION
ENGINE MECHANICAL <4G1>11B-2
GENERAL INFORMATION
M2112000101010
The 4G15-MIVEC-T/C engine employed in the Colt
is designed to provide higher performance and
higher output by using a turbocharger to the
4G15-MIVEC engine employed in the conventional
Colt. The main changes in the conventional
4G15-MIVEC engine are as follows:•Cylinder head gasket changed
•Oil jet added
•Strength improved in piston and piston pin
MAJOR SPECIFICATIONS
Item4G15-MIVEC-T/C
Total displacement mL1,468
Bore × Stro ke mm75 × 82.0
Compression ratio9.0
Compression chamberPentroof-type
Va l v e t i m i n gIntake openingBTDC 34° − AT D C 6°
Intake closingABDC 30° − ABDC 70°
Exhaust openingBBDC 50°
Exhaust closingATDC 10°
Maximum output kW (PS)/rpm113 (154)/6,000
Maximum torque N⋅m (kg⋅m)/rpm210 (21.4)/3,500
Fuel systemElectronically controlled multipoint fuel injection
Ignition systemElectronic-controlled 4-coil

BASE ENGINE
ENGINE MECHANICAL <4G1>11B-3
BASE ENGINE
M2112001000886
CYLINDER HEAD GASKET
AK402138
A
AC
AA-A
To co rrespo nd wi th the imp r ove d o u t put pe rfo r ma nce
by emplo
y in g the t u rbocharger , a three layer me t a l
gasket is used.
CYLINDER BLOCK
AK402048AC
Oil jet
The cylinder bl ock has the oil jet fitted o n the main
bearin
g among th e cylin ders in ord e r to make the
pist
on cool. T he oil is injecte d from the o il g r oove of
the main b
earin g when th e oil pressure is 2kg/ cm
2 or
more.

GENERAL INFORMATION
ENGINE MECHANICAL <4A9>11A-2
GENERAL INFORMATION
M2112000100697
The newly developed 1.5L 4A91 engine features
4-cylinder, 16-valve, and double overhead camshafts
(DOHC).
The engine has the following features.
•Aluminum cylinder block
•MIVEC (Mitsubishi Innovative Valve timing Elec-
tronic Control system)
•Selective valve tappet of direct acting valve sys-
tem for valve clearance adjustment
•Timing chain
MAJOR SPECIFICATIONS
Item4A91
Total displacement mL1,499
Bore × Stro ke mm75 × 84.8
Compression ratio10.0
Compression chamberPentroof-type
Va l v e t i m i n gIntake openingBTDC 31° − AT D C 1 9°
Intake closingABDC 21° − ABDC 71°
Exhaust openingBBDC 39°
Exhaust closingATDC 5°
Maximum output kW (PS)/rpm77 (104)/6,000
Maximum torque N⋅m (kg⋅m)/rpm141 (14.4)/4,000
Fuel systemElectronically controlled multipoint fuel injection
Ignition systemElectronic-controlled 4-coil

BASE ENGINE
ENGINE MECHANICAL <4A9>11A-4
VA LV E G U I D E
AK305053
d
AB
Dh
The in
t a ke an d exhaust valves use the same -design
valve gu
ide.
ItemIntake
D (Outer diameter) mm10.5
d (Inner diameter) mm4.5
h (height) mm34.5
CYLINDER HEAD GASKET
AK305054AB
Water hole
Oil hole
Water hole
Th e met a l g a sket having he at resist ance, sea l ability
and low cost is use
d for th e cylin der hea d gasket .
CYLINDER HEAD COVER
AK402398AC
Cylinder head cover
A resin cylin der hea d co ver is used fo r the cylinder head.

BASE ENGINE
ENGINE MECHANICAL <4A9>11A-5
CYLINDER BLOCK
AK402339AC
Front view
Right side view
Under view
Top view
Rear view
Left side view
Thermostat case installation positionOil filter bracket installation position Front
Front Front Front
Nipple
The cylinder b
l ock is ma de of ligh twe i ght aluminum
allo
y .
The crankshaf t jo urnal is supp orted b y 5 b earing s .
The crankshaf
t thru st load is supporte d by No . 4
bearin
g.
The water jacket is of a full-siamese de sig n .
A nipple is p r ovid ed at the fr o n t of the block to su pply
engin
e oil onto the timin g ch ain.
ItemDimension
Overall height mm280
Overall length mm375.1
Top face to crankshaft
center mm205
Crankshaft center to
bottom face mm75
Bore mm75
Bore pitch mm83
Stroke mm84.8

BASE ENGINE
ENGINE MECHANICAL <4A9>11A-6
REAR OIL SEAL CASE
AK305061AB
AA A-A
The rea
r oil seal ca se is a sheet -met al wor k . The
case is
inst alled with sealant ap plie d onto th e mou n t
-
ing face to prevent oil leaka ge.
PISTON
AK403222
AB
Front mark
Piston pin offset
The pisto n is made of spec ial a l uminu m all o y . W e ig ht
reduction
is a c hieved by minimizin g the o v erall
heigh
t while maximizing th e recess on bo th end s of
the piston
pin.
The center o f the p i sto n pin hole is of fset by 0.5 mm
from t
he ce nter of the piston towards the th rust side .
The piston skirt ha s a streak finish to enha nce oil
retention an
d anti-seizin g prope rty .
ItemDimension
Base diameter mm75
Pin diameter mm18
Overall height mm46.04
PISTON PIN
AK305064
d
AB
D
h
The piston pin is o f a semi-floating type, p r ess-fitte d
into t
he co nnecting rod small end wh ile cap able of
floating re
lative to the piston .
ItemDimension
D (Outer diameter) mm18
d (Inner diameter) mm11
h (Overall length) mm50

BASE ENGINE
ENGINE MECHANICAL <4A9>11A-7
PISTON RING
AK305365AB
Piston ring No.1
Spacer RailMaker mark
Piston ring No.2
Oil ring Piston ring No.1
Piston ring No.2
Oil ring
Ea ch pisto n is provided with No. 1 and No. 2 com-
pression rings and an oil rin g .
ItemNo. 1 piston ringNo. 2 piston ringOil ring
ShapeBarrelUndercut3-piece
Surface treatment (Contact
face with cylinder)Ion platingParkerizedIon plating
Maker markNo mafking2RNo marking

BASE ENGINE
ENGINE MECHANICAL <4A9>11A-8
CONNECTING ROD
AK305065AB
dD
L
The connecting rod is made of high ly rigid, forged
carb
on stee l. The rod p o rtion h a s an H- sha ped cro s s
section.
The connecting rod big end bearing is lu bricated
thr
oug h an oil p a ssage ru nn in g f r om the main jo urn a l
to the cranksha
f t p i n.
ItemDimension
d (Small end inner
diameter) mm18
D (Large end inner
diameter) mm43
L (Center distance) mm135.6
CONNECTING ROD BEARING
AK305309AB
H A
Identification
color
The up
per and lower conne ctin g rod b earin g halves
are id
entical.
The connecting rod be aring is e quip ped wit h back
met
a l. While the b earin g it se lf is ma de of a l uminum
allo
y , the back met a l is no rmally mad e of ste e l shee t.
The connecting rod be aring is n a rrower tha n the
bearin
g ca p, this is to minimize wear .
ItemDimension
H (Width) mm13.5
A (Thickness) mm1.5
