2006 MITSUBISHI COLT gas type

GENERAL INFORMATION
HEATER, AIR CONDITIONER AND VENTILATION55-2
GENERAL INFORMATION
M2551000100759
For the heater and A/C system, the heater, the
blower and the cooling unit are integrated as one unit
to reduce weight and size. For A/C system, the man
-
ual A/C has been adopted.
FEATURES
IMPROVEMENTS IN COMFORT
•Adoption of low noise, large air volume heater
and A/C system
•Adoption of smaller air intake box for larger pas-
senger leg space.
•Optimising the areas of the outside air induction
hole and the air outlet improves ventilation per
-
formance as well as the quietness of the room
•Adoption of clean air filter with deodorant function
for cleaner air in the compartment.
IMPROVEMENTS IN OPERATION
PERFORMANCE
•Inside/outside air selection switch has been
changed to a pushbutton switch.
•Improved operation ability by the enlarged tab on
the dial knob
•Air amount and temperature only are controlled
automatically for easier operation. automatic A/C>
RELIABLE VISUAL FIELD
(IMPROVEMENT IN SAFETY)
•Current type defroster nozzle has been adopted
to improve defogging performance (Shortens
windshield fogging time).
•Defroster vents have been integrated to secure
better defogging pattern.
•Black coin drop prevention ribs are used on the
defroster to prevent its reflection on the wind
-
shield, providing sufficient field of vision for safety
IMPROVEMENTS IN FUEL ECONOMY
•Wider condenser area reduces load to the A/C
and improves fuel consumption.
•Energy conservation control using outside air
temperature sensor is adopted for vehicles with
manual A/C as well.
•A small-size, highly-efficient compressor has
been adopted.
•Simpler wiring and weight reduction are achieved
by installation of CAN communication system
GLOBAL ENVIRONMENT PROTECTION
Adoption of HFC134a for refrigerant.
IMPROVEMENTS IN SERVICE QUALITY
•Reduction of refrigerant gas leakage and
improvement in serviceability by incorporating
condenser and receiver
•The layout of refrigerant line for better workability
is adopted.
RESPONSIBILITY IMPROVEMENT
Reliable information transmission is achieved by
connecting A/C-ECU and each ECU via CAN com
-
munication.

GENERAL INFORMATION
ENGINE MECHANICAL <4G1>11B-2
GENERAL INFORMATION
M2112000101010
The 4G15-MIVEC-T/C engine employed in the Colt
is designed to provide higher performance and
higher output by using a turbocharger to the
4G15-MIVEC engine employed in the conventional
Colt. The main changes in the conventional
4G15-MIVEC engine are as follows:•Cylinder head gasket changed
•Oil jet added
•Strength improved in piston and piston pin
MAJOR SPECIFICATIONS
Item4G15-MIVEC-T/C
Total displacement mL1,468
Bore × Stro ke mm75 × 82.0
Compression ratio9.0
Compression chamberPentroof-type
Va l v e t i m i n gIntake openingBTDC 34° − AT D C 6°
Intake closingABDC 30° − ABDC 70°
Exhaust openingBBDC 50°
Exhaust closingATDC 10°
Maximum output kW (PS)/rpm113 (154)/6,000
Maximum torque N⋅m (kg⋅m)/rpm210 (21.4)/3,500
Fuel systemElectronically controlled multipoint fuel injection
Ignition systemElectronic-controlled 4-coil

SYSTEM CONSTRUCTION
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)52B-11
CURTAIN AIR BAG MODULE
M2521000500088
AC401546
AC207337AC207332
AC207338
Split hole
Burst disk 2Squib
Propellant
Burst disk 1
Curtain air bag moduleInflator
AB
High-pressure gas
The curt ain air b ag module co nsist s o f an a i r ba g, an
infla
t or , an d the f i xing ge ar rela ting to those p a rt s,
and is in
st alled in the roo f side sections (from t he
driver's an
d the p a sse nger's front p illars to the re ar
pill
ars).
The air bag is made f r om nylon with th e inside
coate
d with silico n, and housed in the roo f side sec
-
tions, folded up comp actly .
The inflato r is of a hybrid type filled wit h hig h -pres-
sure ga s (majo r compone nt: argo n). Whe n curr ent
p
a ss es t h ro ug h t h e sq ui b t o ig ni te th e ig n i t e r po wde r ,
burst
disk 1 b u rst s . T hen, th e co mbustion of the
i
gni ter powder increases the pres sure of the filler gas
to burst disk 2
, lett ing th e gas out o f the split hole.
CURTAIN AIR BAG DEPLOYMENT
IGNITION
AC304629
if an imp a ct in a side collision is de tecte d b y the rear
side
imp a ct senso r inst a lled inside a inn e r quart e r
p
a n e l an d by the side-a i rbag safing G-sen s or inte
-
grated in the SRS-ECU, the SRS-ECU se nds a n igni-
tion signal to th e squib o f th e re levant curt ain a i r bag
mo
du le. Wh en t h is ig nition sign al p a sses t h r o u g h t h e
squib, the
inflator ge nerates gas.
INFLATING
AC304630
The air bag st art s to a ppear p u shing away a he adlin-
ing.
COMPLETION OF INFLATION
AC304631
The air bag fu lly in flates to p r otect the he ads of the
occup
ant s in the fro n t and rear seat s.

EMISSION CONTROL
ENGINE AND EMISSION CONTROL17-3
EMISSION CONTROL
GENERAL INFORMATION <4A9>M2171000100838
Although the emission control systems are basically
the same as those of the 4G1-Non-Turbo engine
used in the COLT, the following improvements have
been added.•The adoption of the catalytic converter just
beneath exhaust manifold realizes the earlier
activation.
•The adoption of the dual oxygen sensor has
increased reliability air/fuel ratio control.
•
SystemRemarks
Crank case ventilaton systemClosed type
Evaporative emission control systemElectronic control type with duty signal
Exhaust gas recirculation (EGR) system Electronic control (stepper motor) type
Air/fuel ratio closed loop controlOxygen sensor signal used
Catalytic converterThree-way catalytic converter
The abolition of the EGR system .
EMISSION CONTROL SYSTEM DIAGRAM
AK402829
Oxygen sensor (front)
Oxygen sensor (rear)
Air
inlet
EGR valve
(stepper motor)
Canister
Purge control
solenoid valve
Injector
PCV valve
ACCatalytic converter From
fuel pump
