2006 Lexus GX470 Basic Functions In Frequent Use / LEXUS 2006 GX470 OWNER'S MANUAL (OM60B99U)

AUDIO
284(b) Manual program selection
“Program” button: Push the “” or “” (DISC/CH/PROG)
button to select the other side of a cassette tape. The screen
indicates which side is currently selected. (“
” indicates the
top side, “” indicates the bottom side.)
“Rewind” button: Push the “” (TUNE/TRACK) button to
rewind a tape. “REW” appears on the display.
To stop rewinding, push the same button.
“Fast forward” button: Push the “
” (TUNE/TRACK) button
to fast forward a cassette tape. “FF” appears on the display.
To stop fast forwarding, push the same button.

AUDIO
285
(c) Automatic program selection
“Automatic program selection” button:
The automatic
program selection feature allows you to program your cassette
player to skip forward or backward to locate the song you want
to hear. You can skip up to 9 programs at a time.
Push the “
” (TUNE/TRACK) button to skip forward. “FF” and
the number will appear on the display. Push the button until the
number you want to skip appears on the display. After that, the
player will automatically skip forward.
When the end of the tape is reached, the player automatically
reverses sides and resumes normal play. Push the “
” (TINE/TRACK) button to skip backward. Push
the button until “REW” and the number you want to skip appear
on the display.
 If you set “REW 1”, the player will rewind to the beginning
of the current program.
 When counting the number of programs you want to rewind,
remember to count the current program as well. For
example, if you want to rewind to a song that is two before
the song you are listening to, push this button until “REW
3” appears on the display.
When the beginning of the tape is reached, the player
automatically resumes normal play.
There must be at least 3 seconds of blank space between
programs for this feature to work correctly.
This feature may not work well with some spoken word, live or
classical recordings.

AUDIO
286
CD player operation
(a) Playing a CD
Using joy stick and the “ENT” button to select the CD
mode.
“CD” appears on the display.
The CDs set in the player are played continuously, starting with
the last CD you inserted. The CD number of the CD currently
being played, the track number and the time from the beginning
of the program appear on the display.
When play of one CD ends, the first track of the following CD
starts. When play of the final CD ends, play of the first CD
starts again.
The player will skip any empty CD trays. (b) Selecting a desired CD
Searching for a desired CD:
Push the “” and “”
(DISC/CH/PROG) button to select the CD number.
Push the button several times until the desired CD number
appears on the display. When you release the button, the
player will start playing the selected CD from the first track.

AUDIO
287
(c) Selecting a desired track
To select a desired track: Push the “” or “”
(TUNE/TRACK) button until the number of the track you want
to listen to appears on the screen. If you want to return to the
beginning of the current track, quickly push the “
”
(TUNE/TRACK) button one time.
“Fast forward” button: Push the “
” (TUNE/TRACK) button
and hold it to fast forward the CD. When you release the
button, the CD player will resume playing from that position.
“Reverse” button: Push the “
” (TUNE/TRACK) button and
hold it to reverse the CD. When you release the button, the CD
player will resume playing.
Replacing remote control battery
For replacement, use a CR2025 lithium battery or equivalent.
CAUTION
Special care should be taken that small children do not
swallow the removed battery or components.
NOTICE
 When replacing the battery, be ca reful not to lose the
components.
 Replace only with the same or equivalent type of
battery recommended by a Lexus dealer.
 Dispose of used batteries according to the local laws.

AUDIO
288
1. Pull the case out while pushing the lock release button to the
side.
2. Remove the discharged battery.
3. Put in a new battery with the positive (+) side up.
4. Put it in the case securely.
NOTICE
 Be sure that the positive side of the remote control
battery is facing correctly.
 Do not replace the battery with wet hands. Water may
cause rust.
 Do not touch or move any components inside of the
remote control, or it may interfere with proper
operation.
 Be careful not to bend the electrode of the remote
control battery insertion and that dust or oil does not
adhere to the transmitter case.
 Close the battery case securely.
After replacing the battery, check that the remote control
operates properly. If the remote control still does not operate
properly, contact your Lexus dealer.

AUDIO
289
DVD player operation
The DVD player can play audio CDs, DVD video discs, CD
texts, dtsCDs, DVD audio discs and video CDs.
For appropriate discs for this player, see “Audio/video system
operating hints” on page 333.
The DVD player works when the ignition key is in the “ACC” or
“ON” position.
To turn on the DVD player, a disc must be loaded in the player.
To turn off the player, eject the disc.
(a) Inserting the disc
1. Push the center of the rear console box lid.
2. Push this button to open the cover.
3. Pull the lid forward.

AUDIO
290
4. Insert a disc with the label side backward and close the
lid.
The player is intended for the use with 12 cm (4.7 in.) discs only.
If the label faces forward, the disc cannot be played. In this
case, “DISC CHECK” appears on the screen.
If a disc which is not playable is inserted, “DISC CHECK” will
also appear on the screen. For appropriate discs for this
player, see “Audio/video system operating hints” on page 333.The indicator light turns on while the disc is loaded.
The player will play the track or chapter, and it will play from the
beginning of the track or chapter again after it reaches the end.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the console box closed
while driving.
NOTICE
Never try to disassemble or oil any part of the DVD
player. Do not insert anything other than a disc into the
slot.
5. Close the cover and console box.

AUDIO
291
(b) Ejecting the disc
Pull
the lid forward to open the DVD player. Push the disc
eject button to eject a disc.NOTICE
Do not place anything on the opened cover. It could
damage the cover.
