STARTING AND DRIVING
364
2Cancelling the cruise control
CANCELLING THE CRUISE CONTROL
The cruise control may be temporarily cancelled by the driver
or by the system itself under certain circumstances.
Temporary cancellation allows the set cruising speed to remain
in memory.
The cruise control can be temporarily cancelled by doing the
following:
 Pulling the lever in the “CANCEL” direction and releasing it
 Depressing the brake pedal
Under certain circumstances, the cruise control is temporarily
cancelled:
 When vehicle speed falls below 40 km/h (25 mph)
 When vehicle stability control is activated
When vehicle speed drops 16 km/h (10 mph) below the set
speed, the cruise control is cancelled and the set speed is
erased from memory.
The “CRUISE” indicator light remains on to indicate that the
system is still in operation.
To turn the cruise control off, press the “ON−OFF” button.
Make sure the “CRUISE” indicator light is off.
If the cruise control automatically cancels out other than for the
above cases, have your vehicle checked by your Lexus dealer
at the earliest opportunity.3Resuming the cruise control
If the cruise control is temporarily cancelled, the cruising speed
can be resumed by pushing the lever up in the “+ RES”
direction.
Vehicle speed must be above 40 km/h (25 mph).
4Resetting to a faster speed
Push the control lever upward in the “+ RES” direction and hold
it. Release the lever when the desired speed is attained. While
the lever is held upward, the vehicle will gradually gain speed.
When the difference between the actual vehicle speed and the
set speed is less than 5 km/h (3 mph), the set speed can be
increased 1.6 km/h (1 mph) each time by pushing the control
lever upward in the “+ RES” direction quickly.
However, a quicker way to reset is to accelerate the vehicle and
then push the control lever downward in the “− SET” direction.

STARTING AND DRIVING
365
5Resetting to a slower speed
Push the control lever downward in the “ − SET” direction and
hold it. Release the lever when the desired speed is attained.
While the lever is held downward, the vehicle speed will
gradually decrease.
When the difference between the actual vehicle speed and the
set speed is less than 5 km/h (3 mph), the set speed can be
lowered 1.6 km/h (1 mph) each time by pushing the control
lever downward in the “ − SET” direction quickly.
However, a quicker way to reset is to depress the brake pedal
and then push the control lever downward in the “ − SET”
direction.
Even if you downshift the transmission from the “D” position to
“4” position with the cruise control on, engine braking will not
be applied because the cruise control is not cancelled. To
decrease the vehicle speed, reset to a slower speed with the
cruise control lever or depress the brake pedal. If you use the
brake pedal, cruise control is cancelled.Cruise control failure warning
If the “CRUISE” indicator light flashes when using the cruise
control, press the “ON− OFF” button to turn the system off and
then press it again to turn it on.
If any of the following conditions then occurs, there is some
trouble in the cruise control system.
 The indicator light does not come on.
 The indicator light flashes again.
 The indicator light goes out after it comes on.
If this is the case, contact your Lexus dealer and have your
Lexus inspected.

STARTING AND DRIVING
366
REAR HEIGHT CONTROL AIRSUSPENSION
This rear height control air suspension controls the
vehicle height depending on the vehicle driving condition.
Select your desired height among the “HI” (high), “N”
(normal) and “LO” (low) modes with the height select
switch.
(a) Vehicle height modes
“N” (normal) mode: The vehicle height in this mode is
standard. Regardless of the number of occupants or the
luggage loading condition, the vehicle height is always
automatically adjusted to a fixed height in any mode while the
engine is running.
This mode is suitable for ordinary driving. “HI”
(high) mode: The vehicle height is about 40 mm (1.6 in.)
higher at the rear than the “N” mode height.
This mode is suitable when driving on the bumpy roads and
through water.
However, when the vehicle speed exceeds about 30 km/h (19
mph) or over in the “HI” mode, the “N” mode is automaticall\
y
selected.
CAUTION
The “HI” mode should be used for severe offroad
driving condition only. As the vehicle’s center of gravity
is higher in this setting, the vehicle may become
unstable when turning abruptly resulting in accident.
“LO” (low) mode: The vehicle height is about 20 mm (0.8 in.)
lower at the rear than the “N” mode height.
This mode allows you easy access to the vehicle (getting in and
out) and easy loading and unloading operation.
This mode is available when the vehicle speed is under about
12 km/h (7 mph).

STARTING AND DRIVING
367
NOTICE
Use the “LO” mode when the vehicle is stopped.
Otherwise, when the vehicle speed exceeds about 12
km/h (7 mph), “N” mode is selected automatically. So
be careful when you drive in any place where the
overhead height is limited.
(b) Vehicle height mode changing condition
To change the vehicle height, it is necessary to meet the
following conditions.
The engine should be running.
 The height control “OFF” indicator light should go off.
 When selecting a mode, there is a vehicle speed limit. Refer
to the following table.
Yes = The mode can be selected.
No = The mode cannot be selected.
“LO”
mode“N”
mode“HI”
mode
Under about
12 km/h (7 mph)Ye sYe sYe s
Under about
30 km/h (19 mph)NoYe sYe s
About 30 km/h
(19 mph) or overNoYe sNo
In the following cases, the rear height control suspension
will not operate.
 The underbody of the vehicle has touched the surface on
bumpy roads.
 The area around the rear suspension is coated with ice.
If the vehicle is moved to its usual location or the ice is removed
and the height select switch is pressed, the vehicle height
control cannot be operated. In this case, turn off and restart the
engine, then push the control switches.
(c) Vehicle height adjustment
1Higher2Lower
To change the mode, push the height select switch on
either side of “ ” (higher) or “
” (lower).

STARTING AND DRIVING
368The height control indicator light indicates which mode is
selected. (See “(e) Height control indicator light” described
below.)

Selecting the “HI” mode
Push the height select switch on the “ ” side when the vehicle
speed is under about 30 km/h (19 mph).
To change the “N” mode to “HI”: Push the switch once.
To change the “LO” mode to “HI”: Push the switch twice. It
takes about 30 seconds until the “LO” mode changes to the “HI”
mode.
 Selecting the “N” mode
To change the “HI” mode to “N”: Push the height select
switch on the “
” side once.
To change the “LO” mode to “N”: Push the height select
switch on the “ ” side once.
 Selecting the “LO” mode
Push the height select switch on the “
” side while the vehicle
is stopped.
To change the “N” mode to “LO”: Push the switch once.
To change the “HI” mode to “LO”: Push the switch twice.
Even if the engine is stopped while the vehicle height is being
lowered, the operation continues for up to 25 seconds. If within
this 25 seconds, any of the side doors or the back door is
opened, operation will continue for a further 15 seconds.
NOTICE
 If the vehicle height is changed frequently when the
vehicle is heavily loaded, the compressor may
overheat causing the vehicle height adjustment
operation to stop.
 Before you lower the vehicle height with the height
select switch, check under the vehicle to make sure
nothing to damage the vehicle or no one to be injured
is there and that the underbody of the vehicle does
not touch the ground.
 After unloading, the height of a vehicl e equipped with
the rear height control air suspension becomes
slightly higher than the normal vehicle height. Take
sufficient care where the overhead height is
restricted.
 Do not select the “LO” mode in the bumpy roads. If
the underbody of the vehicle touches the rugged
road surface, the vehicle may be damaged.

STARTING AND DRIVING
369
(d) Turning off the rear height control airsuspension
To turn off the rear height control air suspension with the
vehicle stopped, push the “HEIGHT CONTROL OFF”
switch. The height control “OFF” indicator light comes on
and the vehicle height is fixed in the same mode as the
height control switch is pushed.
This status is memorized in the system even after the engine
is stopped.
If you push the switch again, the height control “OFF” indicator
light goes out and the rear height control air suspension is
turned on.
Even after the rear height control air suspension is turned off
with the “HEIGHT CONTROL OFF” switch, if the vehicle speed
exceeds 30 km/h (19 mph), the rear height control air
suspension automatically selects the “N” mode.
CAUTION
If you drive through deep water over about 700 mm (28
in.) in depth, put the vehicle height in the “HI” mode with
the height select switch and then turn off the rear height
control air suspension by pushing the “HEIGHT
CONTROL OFF” switch.
NOTICE
 When jacking up or installing tire chains, be sure to
turn off the rear height control air suspension with
the “HEIGHT CONTROL OFF” switch and stop the
engine. Otherwise, the vehicle height may change
because of the automatic leveling function resulting
in accident.
 If your vehicle must be towed, put the vehicle height
in the “N” mode and turn off the rear height control air
suspension. Otherwise, the vehicle height may
change because of the automatic leveling function
resulting in accident.
 If your vehicle gets ditched, turn off the rear height
control air suspension with the “HEIGHT CONTROL
OFF” switch. Otherwise, the vehicle height may
change because of the automatic leveling function
resulting in accident.

STARTING AND DRIVING
370
(e) Height control indicator lights
1Height control indicator lights
2Height control “OFF” indicator light
When the ignition switch is turned on, all the indicator lights
come on. Only the indicator light showing the present mode
remains on and all other lights go off after a few seconds. This
means the system operates correctly.
When you change the vehicle height mode, the indicator lights
change as follows:
When changing the vehicle height from the “N” mode to
“HI”:
1. The “N” mode indicator light goes off and the “HI” mode
indicator light blinks.
2. After the vehicle height control reaches the “HI” mode, the
“HI” mode indicator light remains on. If the underbody of the vehicle has touched the surface on
bumpy roads or the area around the rear suspension is
coated with ice, the height control suspension will not
operate and the indicator lights change as follows:
1. The present mode indicator light goes off and the selected
mode indicator light blinks.
2. The selected mode indicator light goes off. (The vehicle
height does not change.) The present mode indicator light
comes on again.
Height control “OFF” indicator light:
When the ignition
switch is turned on, this light comes on. If it goes out after a few
seconds, the rear height control air suspension operates
correctly. If you push the “HEIGHT CONTROL OFF” switch,
the rear height control air suspension is turned off. The height
control “OFF” indicator light comes on.
In the following cases, there is a problem somewhere in the
rear height control air suspension. Although there is no
problem to continue normal driving, have the rear height
control air suspension checked by your Lexus dealer as soon
as possible.
 The height control “OFF” indicator light does not come on
when the ignition switch is turned on.
 The height control “OFF” indicator light blinks.

STARTING AND DRIVING
371
(f) Parking and stopping tips
If you immediately stop the engine to park the vehicle after
off−road driving, the vehicle height is lowered slightly as the
vehicle becomes cool. When parking, make sure there is
nothing that will be in contact with the underbody of the vehicle.
When you start the engine, the vehicle returns to the previous
height.
If you park the vehicle for a long time, the vehicle height may
be gradually lowered. When parking for a long time, make sure
there is nothing that will be in contact with the underbody of the
vehicle. When you start the engine, the vehicle returns to the
previous height.
If you stop the engine, the vehicle height may change in
accordance with the change in the temperature. When you
start the engine, the vehicle returns to the previous height.
(g) Rear height control failure warning
If there is a problem somewhere in the rear height control air
suspension, the “N” mode is automatically selected. If this
occurs, the height control “OFF” indicator light blinks and the
vehicle height control cannot be activated until the malfunction
is corrected. If this is the case, bring your vehicle to your Lexus
dealer as soon as possible and have it checked.
ELECTRONIC MODULATED SUSPENSION
This electronic modulated suspension adjusts the
damping effect on the shock absorbers with the control
switch. Select one of the 4 modes which is suited to the
driving conditions with the control switch to provide good
riding comfort and stability.
1For driving on a bumpy road
2For ordinary driving such as in the city traffic
3For moderate high speed driving
4For sporty type driving such as on winding mountain
roads and high speed driving
5Soft
6Firm
