2006 Hyundai Accent Owner's Manual

1CONTROLS AND EQUIPMENT
50
B400B03A-E
MPG = Total Cruise Distance(Miles) Total Fuel Consumption (G)
3. Average Fuel Consumption
(MPG)
HLC2057
Distance to empty symbolDistance to empty
o This mode calculates the average fuel consumption from the total fuel used and the distance since the last average consumption reset.
o The total fuel used is calculated from the fuel consumption input.
o The meter's working range is from 0.0 to 99.9 MPG (miles per gallon)
o Calculation Method NOTE: The average fuel consumption is calculated by the US gallon. A US gallon is equal to 3.875 litres. And animperial gallon, used in Britain, is equal to 4.546 litres.
4. Distance to empty (miles)
NOTE:
o If the distance to empty is less than 30 miles, it displays "----".
o The distance to empty can differ from the actual tripmeter accord- ing to driving conditions.
o The distance to empty can vary according to the driving condi-tions, driving pattern or vehicle speed.
o This mode provides the estimated distance to empty from the currentfuel level in the fuel tank.
o When refueling with more than 6
litres, the trip computer will recog-nize refueling.
o When the battery has been rein-
stalled after being discharged or dis-connected, drive more than 20 miles for an accurate distance to empty.

51
1
CONTROLS AND EQUIPMENT
MULTI FUNCTION SWITCH
SB220A1-E Turn Signal Operation To signal an intention to turn right, the switch lever should be pressed down.To signal an intention to turn left, the switch lever should be pushed upwards. In both instances, the turn signal lightson one side of the car will flash and the warning light located in the instrument cluster will flash in sympathy. Uponcompletion of the manoeuvre, the lever will, under normal circumstances, re- turn to the "Off" position. However, ifthe manoeuvre involved only a small movement of the steering wheel, the signal may need to be cancelled manu-ally. If either turn signal indicator flashes more rapidly than normal or refuses to flash at all, a malfunction of the turnsignal system may exist. SB220B1-E Lane Change Signal To indicate an intention to change lanes, moving the lever slightly towards thedirection of the relevant turn signal will cause the turn signal lights to flash. When the lever is released, it will returnto the "off" position.
HLC2072-D
HLC2069-D
B340C03FC-EAT LIGHTING SWITCH The vehicle sidelights and headlights are operated by rotating the end of theturn signal switch barrel. To operate the side lights, rotating the switch to the first detent with ignition switch at the"OFF" position will cause the lights to illuminate. To operate the headlights, the turn signal switch barrel should berotated to the second detent. The head- lights will only operate when the ignition switch is at the "On" position. If theignition switch is turned to the "Off" position, only the side lights will func- tion.

1CONTROLS AND EQUIPMENT
52WINDSCREEN WIPER/ WASHER SWITCH
SB230A1-E The windscreen wiper switch, depen- dent upon model, has three operating positions.
1. Intermittent wiper operation.
2. Low speed operation.
3. High speed operation. NOTE: To prevent damage to the wiper sys- tem, do not attempt to wipe away heavy accumulations of snow or ice.Accumulated snow and ice should be removed manually. If there is only a light layer of snow or ice, operatethe heater in the defrost mode to melt the snow or ice before using the wiper.
NOTE: The ignition must be in the "ON" position to turn on the headlights. Side light auto cut (Not all models) If you do not turn the side light "OFF" after driving, the side light will automati- cally shut "OFF" when the driver's door is opened.To turn them "ON" again you must simply turn the ignition key to the "ON" position.
SB220D1-E HIGH AND LOW BEAM To turn on the headlight high beams, push the lever forward (away from you).For low beams, pull the lever back (toward you). The appropriate headlight beam indicator light will come on at thesame time. SB220E1-E HEADLIGHT FLASH The headlights may be flashed by pull- ing the turn signal switch lever towards the steering wheel. The headlights will be extinguished when the switch isreleased.
B340F01A-EAT Daytime Running Lights (Not all models) Your Hyundai is equipped with daytime running lights. The daytime runninglights are used to improve visibility for oncoming traffic. Your vehicle daytime running lights are designed to remain oncontinuously when the engine is operat- ing even though the headlight switch is in the "OFF" position. However, thedaytime running lights will be off whilst the parking brake is applied.
HLC2071-DB350A01A-D

53
1
CONTROLS AND EQUIPMENT
NOTE:
o Do not operate the washer more
than 15 seconds at a time or when the fluid reservoir is empty.
o In icy or freezing weather, be sure the wiper blades are not frozen tothe glass prior to operating thewipers.
o In areas where water freezes in
winter, use windscreen washerantifreeze.
Mist Wiper Operation
To use the windscreen washer, pull thewiper/washer lever toward the steeringwheel. When the washer lever is oper- ated, the wipers automatically make two passes across the windscreen.The washer continues to operate until the lever is released. B350B01O-EAT Windscreen Washer Operation
If a single wipe is desired in mist, push the windscreen wiper and washer con-trol lever upwards.
B350B01A-D
B350B02A-DB350C01O-DAT Adjustable Intermittent Wiper Operation To use the intermittent wiper feature, place the wiper switch in the "INT" position. With the switch in this posi-tion, the interval between wipes can be varied from approximately 1 to 18 sec- onds by turning the interval adjusterbarrel. This is also varied automatically depending on your road speed.
B350C01A-D

1CONTROLS AND EQUIPMENT
54
3. When the " " position is depre-
ssed, the interval between wipes operates every five seconds inter- mittently.
Do not operate the washer continuouslyfor more than 15 seconds or when the fluid reservoir is empty; this could dam-age the system. Do not operate the wiper when the window is dry; this can result in scratch-ing as well as premature wiper blade wear. For the reason stated above,do notoperate the washer when the washer fluid reservoir is empty.B390A02A-EAT REAR WINDOW WIPER AND WASHER (Not all models)
B390A01A-E
The rear window wiper and washer are turned on by depressing the button. Washer fluid is sprayed onto the glass
as long as the " " is depressed.
1. When the " " position is depre- ssed, the rear window wiper starts to operate continuously.
2. When the " " position is depr- essed, the rear window wiper startsto operate three times after the washer fluid sprays onto the rearwindow.
HEADLIGHT LEVELING DEVICE SYSTEM
B340G01S-EAT
To adjust the headlight beam level ac- cording to the number of the passen- gers and the loading weight in the lug- gage area, turn the beam leveling switch.The higher the number of the switch position, the lower the headlight beam level. Always keep the headlight beamat the proper leveling position, or head- lights may dazzle other road users. Listed below are the examples of rec-ommended switch settings. For loading conditions other than those listed be- low, adjust the switch position so thatthe beam level may be the nearest as the condition obtained according to the list. B340G01A-E

55
1
CONTROLS AND EQUIPMENT
HEATED REAR WINDOWHAZARD WARNING SYSTEM
SB250A1-E (Not all models) To operate the heated rear window de- press the switch shown. The heated rear window will automatically turn off after 20 minutes or when the ignition isturned off. The system may be turned off manually by depressing the switch again. B370A01A-D
SB240A1-E The hazard warning system should be used whenever it becomes necessary to stop the car in a hazardous location. The hazard warning system is operatedby depressing the switch at which time all turn signal lights will flash simulta- neously and the turn signal warninglights located within the instrument clus- ter will flash simultaneously. The hazard warning system may beturned off by depressing the switch again.
B370B01A-D
Loading condition
Switch
position
Driver only Driver + front passengerFull passengers (including driver) Full passengers(including driver) + full boot loading (or light trailer loading) Driver + full boot loading(or maximum trailer loading) 0
1 2
3 0

1CONTROLS AND EQUIPMENT
56
B360A01Y-GAT Rear Fog Light Switch To turn on the rear fog lights, push the switch. They will come on when theheadlight switch is in the second posi- tion and the key is in the "ON" position. B360A01A-D
CAUTION:
The inside of the rear windscreen should never be cleaned with a hard or sharp implement since damage to the heating element may occur. Theglass should only be cleaned with a soft cloth or chamois leather with the use only of a mild detergent or pro-prietary glass cleaner where neces- sary. Only horizontal movement of the cloth should be made when clean-ing the glass and care should be exercised to ensure that the heating elements are not damaged by ringsor jewellery whilst the glass is being cleaned. NOTE: The ignition must be in the "ON" position for the heated rear window to operate.
!
FOG LIGHT SWITCH
B360B01FC-EAT Front Fog Light Switch (Not all models) To turn on the front fog lights, push the switch in the "ON" position. They will come on when the headlight switch is inthe first or second position. B360B01A-D

57
1
CONTROLS AND EQUIPMENT
CIGAR LIGHTER
!
CAUTION:
Do not use electric accessories or equipment other than the Hyundaigenuine parts in the socket.
B420A02A-EAT
For the cigar lighter to work, the keymust be in the "ACC" or the "ON" position. To use the cigar lighter, push the lighterall the way into its socket. When the element is heated, the lighter will pop out into the "ready" position.Do not hold the cigar lighter at the depressed position which may result in damage to the vehicle wiring or anelectrical fire. If it is necessary to replace the cigarette lighter, use only a genuine Hyundaireplacement part.
B400A01A-EAT
HLC2100
There are three control buttons for thedigital clock. Their functions are: HOUR - Push "H" to advance the hour
indicated.
MIN - Push "M" to advance the
minute indicated.
RESET - Push "R" to reset minutes to
":00" to facilitate resetting the clock to the correct time. When this is done:
Pressing "R" between 10 : 30 and 11 :29 changes the readout to 11 : 00.Pressing "R" between 11 : 30 and 12 : 29 changes the readout to 12 : 00. HLC2104-D
DIGLTAL CLOCK
