o Modification to SRS components
or wiring, including the addition of any kind of badges to the padcovers or modifications to the body structure, can adversely affect SRS performance and lead to possibleinjury.
o For cleaning the airbag pad cov-
ers, use only a soft, dry cloth orone which has been moistened with plain water. Solvents or clean- ers could adversely affect theairbag covers and proper deploy- ment of the system.
o No objects should be placed over or near the airbag modules on the steering wheel, instrument panel,and the front passenger's panel above the glove box, because any such object could cause harm ifthe vehicle is in a crash severe enough to cause the airbags to inflate.
o If the airbags inflate, they must be replaced by an authorized Hyundaidealer.o Do not tamper with or disconnect
SRS wiring, or other components of the SRS system. Doing so could result in injury, due to accidentalfiring of the airbags or by render- ing the SRS inoperative.
o If components of the airbag sys- tem must be discarded, or if thevehicle must be scrapped, certain safety precautions must be ob-served. Your Hyundai dealer knows these precautions and can give you the necessary informa-tion. Failure to follow these pre- cautions and procedures could increase the risk of personal in-jury.
o If you sell your vehicle, be sure to
inform the new owner of theseimportant points and make cer- tain that this manual is transferred to the new owner.
o If your car was flooded and has soaked carpeting or water on floor-ing, you shouldn't try to start en-gine; have the car towed to autho- rized Hyundai dealer.
Page 330 of 599
1FEATURES OF YOUR HYUNDAI
48
B260B0A03A-GAT Gasoline EngineINSTRUMENT CLUSTER AND INDICATOR LIGHTS
B260A02A-Y
1
23 4 5 6
7 8 91011121314 15161718 19 2
Page 331 of 599
1
FEATURES OF YOUR HYUNDAI
49
1. Tachometer (If Installed)
2. Turn Signal Indicator Light
3. Speedometer
4. Odometer/Trip Odometer /Trip Computer (If Installed)
5. Fuel Gauge
6. Temperature Gauge
7. SRS (Airbag) Warning Light (If Installed)
8. ABS Warning Light (If Installed)
9. Immobilizer Warning Light (If Installed)
10. Overdrive Off Indicator Light (Automatic Transaxle only) 11. High Beam Indicator Light
12. Door Ajar Warning Light
13. Parking Brake/Low Brake Fluid Level Warning Light
14. Charging System Warning Light
15. Seat Belt Warning Light (If Installed)
16. Low Oil Pressure Warning Light
17. Trip Odometer Reset Switch/
Trip Computer Reset Switch (If Installed)
18. Low Fuel Warning Light
19. Malfunction Indicator Light (MIL) (If Installed)
Page 332 of 599
1FEATURES OF YOUR HYUNDAI
50
B260B02A-GAT Diesel Engine
B260B02A-Y
12 3
4 56
789 1 0111 2131 4151 6171 8
2
19
Page 333 of 599
1
FEATURES OF YOUR HYUNDAI
51
1. Tachometer (If Installed)
2. Turn Signal Indicator Light
3. Speedometer
4. Odometer/Trip Odometer /Trip Computer (If Installed)
5. Fuel Gauge
6. Temperature Gauge
7. SRS (Airbag) Warning Light (If Installed)
8. ABS Warning Light (If Installed)
9. Immobilizer Warning Light (If Installed)
10. High Beam Indicator Light 11. Door Ajar Warning Light
12. Parking Brake/Low Brake Fluid Level Warning Light
13. Charging System Warning Light
14. Trip Odometer Reset Switch/
Trip Computer Reset Switch (If Installed)
15. Low Oil Pressure Warning Light
16. Fuel Filter Warning Light
17. Low Fuel Warning Light
18. Diesel Pre-heat Indicator Light
19. Malfunction Indicator Light (MIL)(If Installed)
Page 334 of 599

1FEATURES OF YOUR HYUNDAI
52
!
WARNING AND INDICATOR LIGHTS
B260B01S-GAT SRS (Airbag) Service Reminder Indicator (SRI)(If Installed)
The SRS service reminder indicator (SRI) comes on and flashes for about 6 seconds after the ignition key is turnedto the "ON" position or after the engine is started, after which it will go out. This light also comes on when the SRS is not working properly.If the SRI does not come on, or continuously remainson after flashing for about 6 seconds with a blink when you truned the ignition key to the "ON" position or started theengine, or if it comes on while driving, have the SRS inspected by an autho- rized Hyundai Dealer. B260P02Y-GAT
ABS Service Reminder Indicator (SRI)
(If Installed)
When the key is turned to the "ON" position, the Anti-Lock Brake System SRI will come on and then go off in a fewseconds. If the ABS SRI remains on, comes on while driving, or does not come on when the key is turned to the"ON" position, this indicates that there may be a problem with the ABS. If this occurs, have your vehiclechecked by your Hyundai dealer as soon as possible. The normal braking system will still be operational, butwithout the assistance of the anti-lock brake system. B260C01A-AAT
O/D OFF Indicator (Automatic transaxleonly)
When the overdrive switch is turned on, the overdrive off indicator will go out. This amber indicator will be illuminatedwhen the overdrive switch is turned off. WARNING:
If both ABS SRI and Parking Brake/Brake fluid level warning lights re- main "ON" or come on while driving, there may be a problem with E.B.D(Electronic Brake Force Distribution). If this occurs, avoid sudden stops and have your vehicle checked byyour Hyundai dealer as soon as pos- sible.
Page 335 of 599

1
FEATURES OF YOUR HYUNDAI
53
!
B260F01A-AAT
High Beam Indicator Light
The high beam indicator light comes on whenever the headlights are switched to the high beam or flash position. B260H03A-AAT
Parking Brake/Low Brake
Fluid Level WarningLight
B260G01A-AATLow Oil Pressure Warning Light
!CAUTION:
If the oil pressure warning light stays on while the engine is running, seri- ous engine damage may result. Theoil pressure warning light comes on whenever there is insufficient oil pres- sure. In normal operation, it shouldcome on when the ignition switch is turned on, then go out when the en- gine is started. If the oil pressurewarning light stays on while the en- gine is running, there may be a seri- ous malfunction.If this happens, stop the car as soon as it is safe to do so, turn off the
engine and check the oil level. If the oil level is low, fill the engine oil to the proper level and start the engine again. If the light stays on with theengine running, turn the engine off immediately. In any instance where the oil light stays on when the engineis running, the engine should be checked by an authorized Hyundai dealer before the car is driven again. WARNING:
If you suspect brake trouble, haveyour brakes checked by a Hyundaidealer as soon as possible. Driving your car with a problem in either the brake electrical system or brake hy-draulic system is dangerous, and could result in a serious injury or death.
B260D01A-AAT
Turn Signal Indicator Lights
The blinking green arrows on the instru- ment panel show the direction indicated by the turn signals. If the arrow comeson but does not blink, blinks more rapidly than normal, or does not illumi- nate at all, a malfunction in the turnsignal system is indicated. Your dealer should be consulted for repairs.
Warning Light Operation The parking brake/brake fluid level warn- ing light should come on when the parking brake is applied and the ignitionswitch is turned to "ON" or "START". After the engine is started, the light should go out when the parking brake isreleased. If the parking brake is not applied, the warning light should come on when theignition switch is turned to "ON" or "START", then go out when the engine
Page 336 of 599

1FEATURES OF YOUR HYUNDAI
54
B260J01S-GATCharging System Warning Light
The charging system warning light should come on when the ignition isturned on, then go out when the engine is running. If the light stays on while the engine is running, there is a malfunctionin the electrical charging system. If the light comes on while you are driving, stop, turn off the engine and checkunder the hood. First, make certain the generator drive belt is in place. If it is, check the tension of the belt.And then, have the system checked by your Hyundai dealer.
starts. If the light comes on at any other time, you should slow the vehicle andbring it to a complete stop in a safe location off the roadway. The brake fluid level warning light indi-cates that the brake fluid level in the brake master cylinder is low and hy- draulic brake fluid conforming to DOT 3or DOT 4 specifications should be added. After adding fluid, if no other trouble is found, the car should be immediatelyand carefully driven to a Hyundai dealer for inspection. If further trouble is expe- rienced, the vehicle should not be drivenat all but taken to a dealer by a professional towing service or some other safe method.Your Hyundai is equipped with dual- diagonal braking systems. This means you still have braking on two wheelseven if one of the dual systems should fail. With only one of the dual systems working, more than normal pedal traveland greater pedal pressure are required to stop the car. Also, the car will not stop in as short a distance with only halfof the brake system working. If the brakes fail while you are driving, shift to a lower gear for additional engine brak-ing and stop the car as soon as it is safe to do so.
CAUTION:
If the drive belt (generator belt) is loosen, broken, or mission while the vehicle is driving, there may be a serious malfunction, engine couldoverheat because this belt also drives the water pump.! B260M01A-AAT
Low Fuel Level Warning Light
The low fuel level warning light comes on when the fuel tank is approachingempty. When it comes on, you should add fuel as soon as possible. Driving with the fuel level warning light on orwith the fuel level below "E" can cause the engine to misfire and damage the catalytic converter.
B260L02HP-GAT Door Ajar Warning Light and Chime (If Installed)
The door ajar warning light warns you that a door is not completely closed and the chime warns you that the key is inthe ignition switch. NOTE : The warning chime only sounds whenever the key is in the ignition switch and the driver's side frontdoor is open simultaneously. The chime sounds until the key is re- moved from the ignition switch or the driver's side front door is closed.
