2005 VOLVO XC90 Owners Manual

2005 VOLVO XC90

12 volt socket
This 12 volt socket can be used to plug in certain accessories such as c\
ellular telephones, etc. The
ignition key must be in position 1 (or higher) for the auxiliary socke\
t to function.
NOTE: The auxiliary sockets can also be used for cigarette lighters, which ar\
e available as accessories
at your Volvo retailer.
pg. 33 Instruments and controls
Lighting panel
A - Headlights and parking lights
All lighting off.
Models with daytime running lights:
Low beam headlights will automatically come on if the ignition key is in\
position II. Front and rear
parking lights, tail lights, side marker lights, and license plate light\
s will also be on. Volvo recommends
the use of daytime running lights. If, however, you would prefer to have\
these lights turned off (USA
only), please consult your Volvo retailer. Please note that the use of \
daytime running lights is mandatory
in Canada.
NOTE: Bi-Xenon headlights (option): Turn the headlight switch to position 0\
to activate a daylight
sensor, which automatically switches the low beams on or off, depending \
on ambient light conditions.
When driving in daylight, the headlights will switch off and the daytime\
running lights will come on. In
darkness, the daytime running lights will switch off and the Bi-Xenon he\
adlights will switch on.
Parking lights on. The parking lights should be switched off when you leave the vehicle to \
help avoid battery drain.
Headlights, parking lights, license plate lights and instrument panel il\
lumination are on if the
ignition key is in position II.
The headlight switch must be in this position before the high beams will\
function (this also applies on
file:///K|/ownersdocs/2005/2005_XC90/05xc90_02a.htm (11 of 17)12/30/20\
06 4:42:27 PM

2005 VOLVO XC90
models equipped with the optional Bi-Xenon headlights).
Switch from high to low beams and vice versa by pulling the turn signal \
switch lever on the left side of
steering column toward you.
B - Instrument lighting
Move the thumb wheel up to increase brightness or down to decrease brigh\
tness. There is also an
instrument panel illumination sensor (see illustration on
page 50) which automatically adjusts the level
of illumination. The symbols have maximum illumination in daylight (onl\
y the background lighting can
be adjusted). At night, both the symbol light and background lighting c\
an be adjusted.
C - Unlocking the fuel filler door
Press this button when the vehicle is at a standstill to unlock the fuel\
filler door. Please note that the fuel
filler door will remain unlocked until the vehicle begins to move forwar\
d. An audible click will be heard
when the fuel filler door relocks. See also
page 88.
NOTE: If the fuel filler door does not unlock after the button has been press\
ed, please see
page 34 for
information on manually unlocking this door.
D - Front fog lights
The front fog lights will function only in combination with the low beam\
headlights. The fog lights turn
off when the ignition is switched off.
A light in the switch indicates when the front fog lights are on.
pg. 34 Instruments and controls
Lighting panel, Manually unlocking the fuel filler door
file:///K|/ownersdocs/2005/2005_XC90/05xc90_02a.htm (12 of 17)12/30/20\
06 4:42:27 PM

2005 VOLVO XC90
E - Rear fog light
By design, there is one rear fog light only, located in the driver's sid\
e tail light cluster.
The rear fog light is considerably brighter than the normal tail lights \
and should be used only when
conditions such as fog, rain, snow, smoke or dust reduce visibility for \
other vehicles to less than 500 ft
(150 meters).
A light in the switch indicates when the rear fog light is on.
The rear fog light will only function in combination with the high/low b\
eam headlights.

Panel on passenger's side of cargo area
Manually unlocking the fuel filler door
1. Open the upper and lower sections of the tailgate, and fold up the re\
ar section of the cargo area floor.
2. If the vehicle is equipped with the optional grocery bag holder, deta\
ch the holder's bands.
3. Remove the corner panel (1) from the floor of the cargo area.
file:///K|/ownersdocs/2005/2005_XC90/05xc90_02a.htm (13 of 17)12/30/20\
06 4:42:27 PM

2005 VOLVO XC90
4. Open the cover (2) in the side panel by pulling the tab (3) upwar\
d/outward.
5. Pull down the insulating material (4) to access the fuel filler doo\
r motor (5).
6. Move the catch (6) rearward to unlock the fuel filler door lock, or\
move it forward to lock the filler
door.
pg. 35 Instruments and controls
Turn signals, Steering wheel adjustment
1. Lane change position
In maneuvers such as lane changing, the driver can flash the turn signal\
s by moving the turn signal lever
to the first stop and holding it there. The lever will return to the neu\
tral position when released.
2. Signal lever engaged for normal turns
3. High/low beam switch (headlights on).
file:///K|/ownersdocs/2005/2005_XC90/05xc90_02a.htm (14 of 17)12/30/20\
06 4:42:27 PM

2005 VOLVO XC90
Move the lever towards the steering wheel and release it.
Headlight flasher (headlights off).
Move the lever towards the steering wheel. The headlight high beam will \
be on until the lever is
released.
NOTE: If the turn signal indicator flashes faster than normal, check for a bur\
ned-out turn signal bulb.
4. Exterior courtesy lights.
Home safe lighting
When you leave your vehicle at night, you can make use of the courtesy l\
ighting function:
l Remove the key from the ignition switch.
l Pull the turn signal lever towards the steering wheel (as when using th\
e headlight flasher function).
l Exit the vehicle and lock the doors.
The headlights, parking lights, license plate lights and the lights in t\
he sideview mirrors will now come
on and remain on for 30, 60 or 90 seconds (the time interval is at your\
discretion and can be changed by
an authorized Volvo retailer).
Approach lighting
When approaching the vehicle at night, press the yellow button in the ce\
ntral locking remote control (see
illustration on
page 77). This lights up the interior courtesy lights, parking lights, license\
plate lights and
the lights in the sideview mirrors.
Steering wheel adjustment
Both the height and the reach of the steering wheel can be adjusted to a\
comfortable position for the
driver. Pull down the lever on the left of the steering column. Adjust t\
he steering wheel to a suitable
position and press the lever back into place to lock the steering wheel \
in the new position. Check that the
steering wheel is locked in the new position.
file:///K|/ownersdocs/2005/2005_XC90/05xc90_02a.htm (15 of 17)12/30/20\
06 4:42:27 PM

2005 VOLVO XC90
WARNING!
The Never adjust the steering wheel while
driving.
pg. 36 Instruments and controls
Windshield wipers
Windshield wipers off
If the lever is in the 0 position and you move it upwards, the wipers wi\
ll sweep one stroke at a time for
as long as you hold the lever up.
"Single sweep" position
Move the lever slightly upward from the 0 position for one sweep of the \
wipers. The lever return
automatically to 0 when released.
Intermittent wiper function
With the lever in this position, you can set the wiper interval by twist\
ing ring (1) upward to increase
wiper speed or downward to decrease the speed.
Rain sensor (option)
The rain sensor automatically regulates wiper speed according to the amo\
unt of water on the windshield.
The sensitivity of the sensor can be adjusted by twisting ring 1 up (th\
e wipers will sweep the windshield
more frequently) or down (the wipers will sweep the windshield less fr\
equently).
Activating the rain sensor :
file:///K|/ownersdocs/2005/2005_XC90/05xc90_02a.htm (16 of 17)12/30/20\
06 4:42:27 PM

2005 VOLVO XC90
1. Turn the ignition key to at least position I and put the windshield w\
iper lever in position 0.
2. Press button 2. An LED in the button will light up to indicate that t\
he rain sensor is active.
Deactivating the rain sensor:
l Press button 2. or
l Move the windshield wiper lever down to another position. Moving the lev\
er up will not deactivate
the rain sensor. Doing so will cause the wipers to sweep the windshield \
until the lever is released, at
which time the wipers return to rain sensor mode.
The rain sensor is also deactivated when the key is removed from the ign\
ition.
CAUTION
The rain sensor should be deactivated when washing the car in an automat\
ic car wash, etc. If the rain
sensor function is left on, the wipers will start inadvertently in the c\
ar wash and could be damaged.
Wipers operate at "normal" speed
Wipers operate at "high" speed
3 - Windshield washer/headlight washer (certain models)
Pull the lever toward you and release it. High pressure jets mounted in \
the bumper will spray the
headlights.
NOTE:
l To conserve washer fluid in driving conditions where the windshield wash\
ers are used frequently, the
headlights will only be washed once for every five times the windshield \
is washed within a 10- minute
period.
l When approximately 1 US quart (1 liter) remains in the washer fluid re\
servoir, the rear window and
headlights will not be washed when the lever is pulled to conserve washe\
r fluid for the windshield.



Contents | Top of Page
file:///K|/ownersdocs/2005/2005_XC90/05xc90_02a.htm (17 of 17)12/30/20\
06 4:42:27 PM

2005 VOLVO XC90
pg. 37 Instruments and controls
Tailgate wiper/washer, Water repellant glass
Tailgate wiper/washer
A - Intermittent wiping
B - Normal wiping
Move the lever forward to start the tailgate washer.
Tailgate wiper and reverse gear
If the front wipers are on and the car is put into reverse gear, then th\
e tailgate wiper will go into
intermittent wiping function*.
If the tailgate wiper is already in normal wiping function, the normal w\
iping function will continue.
* Consult your Volvo retailer if you would like to have this function de\
activated.
Water repellent glass (sideview mirrors) - option
The sideview mirrors may be treated with a water repellent coating. This\
improves vision by causing
water to run off quickly. See
page 131 for information on cleaning this type of glass.
CAUTION:
- Use only suitable plastic scrapers to remove ice or snow from the mirr\
ors. Using a metal ice scraper
could damage the water repellent coating.
- Use the heating function to remove ice, snow, or mist from the mirrors\
