2005 TOYOTA AVENSIS diagnostic

05CDW±01
A53766
E13E12E11E10E9
05±318
±
DIAGNOSTICS SFI SYSTEM (1AZ±FSE)
AVENSIS REPAIR MANUAL (RM1018E)
TERMINALS OF ECM
Symbols (Terminal No.)Wiring ColorConditionSTD Voltage (V)
BATT (E9±3) ± E1 (E11±1)B±Y ± BRAlways9 to 14
+BM (E10±6) ± E1 (E11±1)G±Y ± BRAlways9 to 14
IGSW (E9±9) ± E1 (E11±1)B±W ± BRIG switch ON9 to 14
+B (E9±1) ± E1 (E11±1)B±R ± BRIG switch ON9 to 14
+B2 (E9±2) ± E1 (E11±1)B±R ± BRIG switch ON9 to 14
MREL (E9±8) ± E1 (E11±1)GR ± BRIG switch ON9 to 14
IREL (E10±35) ± E1 (E11±1)V ± BRIG switch ON9 to 14
VC (E13±18) ± E2 (E13±28)R±W ± BRIG switch ON4.5 to 5.5
VTA1 (E13 21) E2 (E13 28)LW BRIG switch ON, Accelerator pedal fully released0.4 to 1.0VTA1 (E13±21) ± E2 (E13±28)L±W ± BRIG switch ON, Accelerator pedal fully depressed3.2 to 4.8
VTA2 (E13 31) E2 (E13 28)BR BRIG switch ON, Accelerator pedal fully released2.1 to 3.1VTA2 (E13±31) ± E2 (E13±28)B±R ± BRIG switch ON, Accelerator pedal fully depressed4.5 to 5.5
VPA (E9 22) EPA (E9 28)GYIG switch ON, Accelerator pedal fully released0.5 to 1.1VPA (E9±22) ± EPA (E9±28)G ± YIG switch ON, Accelerator pedal fully depressed2.5 to 4.6
VPA2 (E9 23) EPA2 (E9 29)WYIG switch ON, Accelerator pedal fully released1.5 to 2.9VPA2 (E9±23) ± EPA2 (E9±29)W ± YIG switch ON, Accelerator pedal fully depressed3.5 to 5.5
VCPA (E9±26) ± EPA (E9±28)B ± YIG switch ON4.5 to 5.5
VCP2 (E9±27) ± EPA2 (E9±29)B ± YIG switch ON4.5 to 5.5
VG (E13±30) ± EVG (E13±29)L±Y ± GIdling, P or N position, A/C switch OFF0.5 to 3.0
THA (E13±20) ± E2 (E13±28)GR ± BRIdling, Intake air temperature 20 C (68 F)0.5 to 3.4
THW (E13±19) ± E2 (E13±28)B±W ± BRIdling, Coolant temperature 80   \b0.2 to 1.0
#1 (E13±1) ± E01 (E13±7)
#2 (E13 2) E01 (E13 7)
G±W ± W±B
WR WBIG switch ON9 to 14#2 (E13±2) ± E01 (E13±7)
#3 (E13±3) ± E01 (E13±7)
#4 (E13±4) ± E01 (E13±7)W±R ± W±B
R±W ± W±B
W±L ± W±B
IdlingPulse generation
(See page 05±415)
IJF1 (E13±25) ± E01 (E13±7)R±B ± W±BIdlingPulse generation
(See page 05±415)
IGT1 (E13±8) ± E1 (E11±1)
IGT2 (E13±9) ± E1 (E11±1)
IGT3 (E13±10) ± E1 (E11±1)
IGT4 (E13±11) ± E1 (E11±1)R±W ± BR P ± BR
LG±B ± BR
L±Y ± BR
IdlingPulse generation
(See page 05±439)
IG switch ON4.5 to 5.5
IGF1 (E13±24) ± E1 (E11±1)W±R ± BRIdlingPulse generation
(See page 05±439)
G2+ (E11±27) ± NE± (E11±24)W ± RIdlingPulse generation
(See page 05±436)
NE+ (E11±25) ± NE± (E11±24)G ± RIdlingPulse generation
(See page 05±433)
FC (E9±10) ± E1 (E11±1)G±Y ± BRIG switch ON9 to 14
M+ (E11±3) ± E01 (E13±7)
M± (E11±2) ± E01 (E13±7)B ± W±B
W ± W±BIdlingPulse generation

±
DIAGNOSTICS SFI SYSTEM(1AZ±FSE)
05±319
AVENSIS REPAIR MANUAL (RM1018E)Symbols (Terminal No.)
STD Voltage (V)
Condition
Wiring Color
OX1A (E12±22) ± E2 (E13±28)B ±BR
OX1B (E12±21)
± O1B± (E11±26)B ±WMaintain engine speed at 2,500 rpm for 2 minutes after warmingPulse generation
OX2A (E12±23) ± E2 (E13±28)R ±BR
Maintain engine seed at 2,500 rm for 2 minutes after warming
up
Pulse generation
(See page 05±363)
OX2B (E12±29)
± O2B± (E11±31)R ± G
(g )
HT1A (E12±5) ± E03 (E11±7)
HT1B (E12±25) ± E03 (E11±7)Y ± W±B
P ± W±BIdlingBelow 3.0()()
HT2A (E12±4) ± E03 (E11±7)
HT2B (E12±33) ± E03 (E11±7)L ± W±B
L±B
±W±BIG switch ON9 to 14
KNK1 (E12±1) ± EKNK (E12±2)B ± WMaintain engine speed at 4,000 rpm after warming upPulse generation
(See page 05±429)
OC1+ (E11±16) ± OC1± (E11±15)W±G ± Y±BIG switch ONPulse generation
(See page 05±322)
EVP1 (E13±34) ± E01 (E13±7)W±G ± W±BIG switch ON9 to 14
SCV (E13±5) ± E1 (E11±1)L±B ± BRIG switch ON9 to 14
PIM (E13 33) E2 (E13 28)GW BRIG switch ON3.3 to 3.9PIM (E13±33) ± E2 (E13±28)G±W ± BRApply vacuum 26.7 kPa (200 mmHg, 7.9 in.Hg)2.6 to 3.0
PB (E13 26) E2 (E13 28)YBRIG switch ON3.3 to 3.9PB (E13±26) ± E2 (E13±28)Y ± BRApply vacuum 26.7 kPa (200 mmHg, 7.9 in.Hg)2.6 to 3.0
PR (E13±23) ± E2 (E13±28)Y±G ± BRIdling2.1 to 3.2
FP+ (E12±6) ± E1 (E11±1)R ± BRIdlingPulse generation FP+ (E12 6) E1 (E11 1)
FP± (E12±3) ± E1 (E11±1)
R BR
G ± BRIdlingPulse generation
(See page 05±477)
STA (E13±17) ± E1 (E11±1)B±Y ± BRShift position in neutral, IG switch START6.0 or more
STP (E10 19) E1 (E11 1)GW BRBrake pedal is depressed9 to 14STP (E10±19) ± E1 (E11±1)G±W ± BRBrake pedal is releasedBelow 1.5
ST1 (E10 12) E1 (E11 1)GW BRIG switch ON, Brake pedal is depressedBelow 1.5ST1± (E10±12) ± E1 (E11±1)G±W ± BRIG switch ON, Brake pedal is released7.5 to 14
W (E9 11) E01 (E13 7)WWBIdling9 to 14W (E9±11) ± E01 (E13±7)W ± W±BIG switch ONBelow 3.0
ELS (E9 12) E1 (E11 1)GBRTaillight switch ON, Defogger switch ON7.5 to 14ELS (E9±12) ± E1 (E11±1)G ± BRTaillight switch OFF, Defogger switch OFF0 to 1.5
TACH (E9±5) ± E1 (E11±1)GR±R ± BRIdlingPulse generation
SPD (E10±17) ± E01 (E13±7)V±W ± W±BIG switch ON4.5 to 5.5
TC (E9±20) ± E1 (E11±1)W±L ± BRIG switch ON9 to 14
SIL (E9±18) ± E1 (E11±1)W±G ± BRDuring charge of gearsPulse generation
PSW (E11±10) ± E1 (E11±1)G ± BRWhile turning the steering wheelBelow 1.5
F/PS (E9±14) ± E1 (E11±1)LG±B ± BRIG switch ONBelow 1.5

A76903
NE+ G2+
NE±ECM ConnectorE11
A59781
± DIAGNOSTICSSFI SYSTEM (1AZ±FSE)
05±433
AVENSIS REPAIR MANUAL (RM1018E)
DTC P0335 CRANKSHAFT POSITION SENSOR ºAº
CIRCUIT
DTC P0339 CRANKSHAFT POSITION SENSOR ºAº
CIRCUIT INTERMITTENT
CIRCUIT DESCRIPTION
The crankshaft position sensor (NE signal) consists of a magnet, iron core and pick up coil.
The NE signal plate (crankshaft position sensor plate No. 1) has 34 teeth and is installed on the crankshaft.
The NE signal sensor generates 34 signals at every engine revolution. The ECM detects the crankshaft
angle and the engine revolution based on the NE signal, and the cylinder and the angle of the VVT based
on the combination of the G2 and NE signal.
DTC No.DTC Detection ConditionTrouble Area
P0335
No crankshaft position sensor (NE) signal to ECM during
cranking for 3 sec. or more (2 trip detection logic).
P0335No crankshaft position sensor (NE) signal to ECM with engine
speed 600 rpm or more (2 trip detection logic).
Open or short in crankshaft position sensor circuit
P0339
In condition (a), (b) and (c), when no crankshaft position sen-
sor (NE) signal is input for 0.05 sec. or more
(1 trip detection logic):
(a) Engine revolution 1,000 rpm or more
(b) STA signal is OFF
(c) 3 sec. or more has been lapsed after STA signal is switched
from ON to OFF.
Open or short in crankshaft position sensor circuit

Crankshaft position sensor

Signal plate (crankshaft position sensor plate No. 1)

ECM
Reference: Inspection using the oscilloscope.
(1) During cranking or idling, check the waveform be-
tween the terminals of the ECM connector.
ItemDetails
TerminalCH1: G2+ ± NE±
CH2: NE+ ± NE±
Equipment Setting5 V/Division, 20 ms/Division
ConditionDuring Cranking or idling
HINT:
The correct waveforms are as shown in the left.
05CKJ±01

A76874
C1
Camshaft Position Sensor
C6
Crankshaft Position SensorR W
2 1
EE BR
G J12
J/CE1127ECM
G2+
NE+
NE± (Shielded)
R
BRE11
E1125
24
2 1
(Shielded)E E
E
R R
Crankshaft
Position
Sensor
Plate No. 1Camshaft
Timing
Pulley LH
A64984Crankshaft Position Sensor Component Side
C6
05±434
± DIAGNOSTICSSFI SYSTEM (1AZ±FSE)
AVENSIS REPAIR MANUAL (RM1018E)
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:

Perform troubleshooting of DTC P0335 first. If no trouble is found, troubleshoot the engine mechanical
system.

Read freeze frame data using the hand±held tester. Freeze frame data records the engine conditions
when a malfunction is detected. When troubleshooting, it is useful for determining whether the vehicle
was running or stopped, the engine was warmed up or not, the air±fuel ratio was lean or rich, etc. at
the time of the malfunction.
1 INSPECT CRANKSHAFT POSITION SENSOR(RESISTANCE)
(a) Disconnect the C6 crankshaft position sensor connector.
(b) Measure the resistance between the terminals of the
crankshaft position sensor.
Resistance:
985 to 1,600 at cold
1,265 to 1,890 at hot
NOTICE:
ºColdº and ºHotº shown above mean the temperature of
the coils themselves. ºColdº is from ±10C (14F) to 50C
(122F) and ºHotº is from 50C (122F) to 100C (212F).
NG REPLACE CRANKSHAFT POSITION SENSOR
OK


NE+NE±
A52871
Crankshaft Position Sensor Connector
Wire Harness Side
C6
A81698
NE+ NE±
ECM Connector E11
±
DIAGNOSTICS SFI SYSTEM(1AZ±FSE)
05±435
AVENSIS REPAIR MANUAL (RM1018E)
2CHECK HARNESS AND CONNECTOR(ECM ± CRANKSHAFT POSITION SENSOR)
(a)Disconnect the C6 crankshaft position sensor connector.
(b)Disconnect the E11 ECM connector.
(c)Check for continuity between the wire harness side con-
nectors.
Standard (Check for open):
Symbols (Terminal No.)Specified condition
Crankshaft position sensor (C6±1) ± NE+ (E11±25)ContinuityCrankshaft position sensor (C6±2) ± NE± (E11±24)Continuity
Standard (Check for short):
Symbols (Terminal No.)Specified condition
Crankshaft position sensor (C6±1)or NE+ (E11±25)
± Body ground
NocontinuityCrankshaft position sensor (C6±2)or NE± (E11±24) ± Body groundNo continuity
NGREPAIR OR REPLACE HARNESS ORCONNECTOR
OK
3CHECK SENSOR INSTALLATION(CRANKSHAFT POSITION SENSOR)
(a)Check the crankshaft position sensor installation. NGTIGHTEN SENSOR
OK
4INSPECT CRANKSHAFT POSITION SENSOR PLATE NO.1(TEETH OF SIGNAL PLATE)
(a)Remove the crankshaft position sensor plate No. 1 (See page 14±222).
(b)Check the teeth of the signal plate.
NGREPLACE CRANKSHAFT POSITION SENSORPLATE NO.1
OK
CHECK AND REPLACE ECM (See page 01±32)

A83343
KNK Signal Waveform
± DIAGNOSTICSSFI SYSTEM (1AZ±FSE)
05±429
AVENSIS REPAIR MANUAL (RM1018E)
DTC P0325 KNOCK SENSOR 1 CIRCUIT (BANK 1 OR
SINGLE SENSOR)
DTC P0327 KNOCK SENSOR 1 CIRCUIT LOW INPUT
(BANK 1 OR SINGLE SENSOR)
DTC P0328 KNOCK SENSOR 1 CIRCUIT HIGH INPUT
(BANK 1 OR SINGLE SENSOR)
CIRCUIT DESCRIPTION
A flat type knock sensor (non±resonant type) has a structure that can detect vibrations in a wide frequency
range, from about 6 kHz to 15 kHz, and has the following features.
Knock sensor is fitted on the cylinder block to detect the engine knocking.
The knock sensor contains a piezoelectric element which generates a voltage when it becomes deformed.
This occurs when the cylinder block vibrates due to knocking. If engine knocking occurs, the ignition timing
is retarded to suppress it.
DTC No.DTC Detection ConditionTrouble Area
P0325Output voltage of the knock sensor decreases beyond a
threshold. (Threshold varies according to an engine speed.)
Knock sensor

Knock sensor (under±torqued or loose)

ECM
P0327Output voltage of the knock sensor is 0.5 V or less.

Short in knock sensor circuit

Knock sensor

ECM
P0328Output voltage of the knock sensor is 4.5 V or more.

Open in knock sensor circuit

Knock sensor

ECM
HINT:
If the ECM detects above diagnosis conditions, it operates the fail safe function in which the corrective retard
angle value is set to the maximum value.
Reference:
The correct waveform is shown in the diagram on the left.
ItemDetails
TerminalKNK1 ± EKNK
Equipment Settings0.01 to 10 V/ Division,
0.01 to 10 msec./ Division
ConditionAfter warming up the engine,
keep the engine speed at 4,000 rpm.
05CKI±01

A76872
K1
Knock SensorECM
KNK1
E12
(Shielded)
1 BR D
E
J13 J12 1
B B
J/C EKNK
E12 2
W
2
EEJ12
J13
D
E
BR BR 5 V
05±430
±
DIAGNOSTICS SFI SYSTEM(1AZ±FSE)
AVENSIS REPAIR MANUAL (RM1018E)
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
Read freeze frame data using the hand±held tester. Freeze frame data records the engine conditions when
a malfunction is detected. When troubleshooting, it is useful for determi\
ning whether the vehicle was running
or stopped, the engine was warmed up or not, the air±fuel ratio was lea\
n or rich, etc. at the time of the mal-
function.
1READ OUTPUT DTC
(a)Clear the DTC (See page 05±294).
(b) Warm up the engine.
(c) Run the engine at 3,000 rpm for 10 seconds or more.
(d)Read the DTC (See page 05±294). Result :
Display (DTC output)Proceed to
Only ºP0325º is output againA
ºP0325, P0327 and/or P0328º are output againB
ºP0325, P0327 and/or P0328º are not output againC
B Go to step 3
C CHECK FOR INTERMITTENT PROBLEMS
A

A79596
A81695
KNK1
E12
ECM Connector
EKNK
A76969
KNK1 (+)EKNK (±)
E12
ECM Connector
±
DIAGNOSTICS SFI SYSTEM(1AZ±FSE)
05±431
AVENSIS REPAIR MANUAL (RM1018E)
2CHECK KNOCK SENSOR
(a)Check the knock sensor installation.
Torque: 20 N
m (204 kgf
cm, 15 ft
lbf)
NGTIGHTEN SENSOR
OK
REPLACE KNOCK SENSOR
3CHECK HARNESS AND CONNECTOR(ECM ± KNOCK SENSOR)
(a)Disconnect the E12 ECM connector.
(b)Measure the resistance between terminals KNK1 (E12±1) and EKNK (E12±2) of the ECM connector.
Resistance: 120 to 280 k
at 20
C (68
F)
NGGo to step 5
OK
4INSPECT ECM(KNK1 VOLTAGE)
(a)Disconnect the E12 ECM connector.
(b)Turn the ignition switch ON.
(c)Measure the voltage between terminals KNK1 (E12±1) and EKNK (E12±2) of the ECM terminals.
Voltage: 4.5 to 5.5 V
NGREPLACE ECM (See page 10±65)
OK
CHECK FOR INTERMITTENT PROBLEMS
NOTICE:
Fault may be intermittent. Check harness and connectors carefully and re\
sult.
