2005 SUBARU FORESTER Owners Manual

1-24
Seat, seatbelt and SRS airbags
0
Rear center seatbelt is stowed in the recess of the ceil-
ing.
1. Remove the connector (tongue) plate from the
holder located at the front of the recess by pulling the
connector (tongue) plate rearward.
2. Pull out the seatbelt slowly from the overhead re-tractor.
HS1065CAHS1057BA

1-25
Seat, seatbelt and SRS airbags
– CONTINUED –
A) Seatbelt comfort guide
3. Pass the seatbelt through the seatbelt comfort
guide located beside the head restraint. 4. After confirming that the webbing is not twisted, in-
sert the connector (tongue) attached at the webbing
end into the buckle on the right hand side until a click
is heard.
If the belt stops before reaching the buckle, return the
belt slightly and pull it out more slowly. If the belt still
cannot be unlocked, let the belt retract slightly after
giving it a strong pull, then pull it out slowly again.
A
HS1058BCHS1059BA

1-26
Seat, seatbelt and SRS airbags
5. Insert the center seatbelt tongue plate in the center
seatbelt buckle marked “CENTER” on the left hand
side until it clicks.
6. To make the lap part tight, pull up on the shoulder
belt.
7. Place the lap belt as low as possible on your hips,
not on your waist.
HS1060BA
6
7
HS1061BC

1-27
Seat, seatbelt and SRS airbags
– CONTINUED –
VUnfastening the seatbelt
Push the release button of the center seatbelt buckle
(on the left hand side) to unfasten the seatbelt.
NOTE
When the seatback is folded down for greater car-
go area, it is necessary to disconnect the connec- tor.
0
1. Insert a key or other hard pointed object into the
HS1062BA
HS1063BA
HS1064BA

1-28
Seat, seatbelt and SRS airbags
slot in the connector (buckle) on the right hand side
and push it in, and the connector (tongue) plate will
disconnect from the buckle.
2. Allow the retractor to roll up the belt. You should
hold the webbing end and guide it back into the retrac-
tor while it is rolling up. Neatly store the tongue plates
in the recess in the retractor and then insert the con-
nector (tongue) plate into the slot located at the front
of the recess.
y
Do not allow the retractor to roll up the seat-
belt too quickly. Otherwise, the metal tongue
plates may hit against the trim, resulting in
damaged trim. y Have the seatbelt fully rolled up so that the
tongue plates are neatly stored. A hanging
tongue plate can swing and hit against the trim
during driving, causing damage to the trim.
HS1065BA
HS1066BA

1-29
Seat, seatbelt and SRS airbags
– CONTINUED –
„Seatbelt maintenance
To clean the seatbelts, use a mild soap and lukewarm
water. Never bleach or dye the belts because this
could seriously affect their strength.
Inspect the seatbelts and attachments including the
webbing and all hardware periodically for cracks, cuts,
gashes, tears, damage, loose bolts or worn areas. Re-
place the seatbelts even if only minor damage is
found.
y Keep the belts free of polishes, oils, chemi-
cals and particularly battery acid. y Never attempt to make modifications or
changes that will prevent the seatbelt from op-
erating properly.
Seatbelt extender
If the front seatbelts are not long enough to permit the
tongue plate to engage with the seatbelt buckle, an
optional seatbelt extender is available from your
SUBARU dealer. When ordering an extender, only or-
der one particularly designed for your vehicle. Several
different types of extenders are available to match var-
ious varieties of front seatbelt designs. See your
SUBARU dealer for assistance.
The extender adds approximately 8 inches (200 mm)
of length and it can be used for either the driver or front
passenger seating position.
Be sure to observe the following when using
the seatbelt extender.
Failure to follow these instructions and warn-
ings could reduce the effectiveness of the seat-
belt and result in more serious injury in the
event of a collision.y Never use the extender when the belt itself is
long enough to permit it to be buckled properly.
If removal of heavy clothing is all that is needed
to permit the seatbelt to be buckled properly,
remove the heavy clothing and do not use the

1-30
Seat, seatbelt and SRS airbags
extender. y
Do not use the extender if the buckle of the
extender rests over the abdomen. y Do not let someone else use the extender.
Use of an extender when it is not needed could
reduce the effectiveness of the seatbelt and re-
sult in more serious injury in the event of a col-
lision.y Use the extender only for the front seatbelts
and only for the model for which it was original-
ly provided. Never use the extender for the rear
seatbelts or for a different model.
NOTE
When the seatbelt extender is used by a pregnant
passenger, consult a doctor to get approval in ad-
vance. To connect the extender to the seatbelt, insert the
tongue plate into the seatbelt buckle so that the “PRESS” signs on the buckle-release buttons of the
extender and the seatbelt are both facing outward as
shown in the diagram. You will hear a click when the
tongue plate locks into the buckle.
When releasing the seatbelt, press on the buckle-re-
lease button on the extender, not on the seatbelt. This
helps to prevent damage to the vehicle interior and ex-
tender itself.
For the safety of others, the extender should be re-
moved after each use, especially if the next person us-
ing the seatbelt does not need one.
US1110BA

1-31
Seat, seatbelt and SRS airbags
– CONTINUED –
Front seatbelt pretensioners
The driver’s and front passenger’s seatbelts have a
seatbelt pretensioner. The seatbelt pretensioners are
designed to be activated in the event of an accident in-
volving a moderate to severe frontal collision.
Also, the seatbelt pretensioners are designed to be
activated in the event of an accident involving a mod-
erate to severe side impact collision.
The pretensioner sensor also serves as the frontal and
side SRS airbag sensors. If the sensors detect a cer-
tain predetermined amount of force during a frontal
collision or a side impact collision, the front seatbelt is quickly drawn back in by the retractor to take up the
slack so that the belt more effectively restrains the
front seat occupant.
When a seatbelt pretensioner is activated, an operat-
ing noise will be heard and a small amount of smoke
will be released. These occurrences are normal and
not harmful. This smoke does not indicate a fire in the
vehicle.
Once the seatbelt pretensioner has been activated,
the seatbelt retractor remains locked. Consequently,
the seatbelt can not be pulled out and retracted and
therefore must be replaced.
NOTE y
Seatbelt pretensioners are not designed to acti-
vate in minor frontal impacts, in minor side im-
pacts or in rear impacts or in roll-over accidents. y The driver’s seat and passenger’s seat preten-
sioners and frontal SRS airbag operate simulta-
neously. y The driver’s and passenger’s seatbelt preten-
sioners and the SRS side airbag operate simulta-
neously. y Pretensioners are designed to function on a
one-time-only basis. In the event that a preten- sioner is activated, both the driver’s and front pas-
senger’s seatbelt retractor assemblies must be re-HS1067BA
