Maintenance and service
Guideline of coolant quantity (including coolant in reservoir tank):
Non-turbo models: MT. 7.3 US qt (6.9 liters, 6.1 Imp qt)
AT. 7.2 US qt (6.8 liters, 6.0 Imp qt)
Turbo models: MT. 7.8 US qt (7.4 liters, 6.5 Imp qt)
AT. 7.7 US qt (7.3 liters, 6.4 Imp qt)
A) “FULL” level mark
B) “LOW” level mark
6. Pour the coolant and fill to the reservoir tank’s
“FULL” level mark.
y Be careful not to spill engine coolant when
adding it. If coolant touches the exhaust pipe, it
may cause a bad smell, smoke, and/or a fire. y Do not splash the engine coolant over paint-
ed parts. The alcohol contained in the engine
coolant may damage the paint surface.
A) Rubber gaskets
7. Put the radiator cap back on and tighten firmly. At
this time, make sure that the rubber gasket in the radi-
HSB018CC
A
B
A
HSB026BC

11 -2 1
Maintenance and service
– CONTINUED –
ator cap is correctly in place.
8. Start and run the engine for more than five minutes
at 2,000 to 3,000 rpm.
9. Stop the engine and wait until the coolant cools
down (122 to 140 °F [50 to 60 °C]). If there is any loss
of coolant, add coolant to the radiator’s filler neck and
to the reserve tank’s “FULL” level.
10.Put the radiator cap and reservoir cap back on and
tighten firmly.Air cleaner element
The air cleaner element functions as a filter screen.
When the element is perforated or removed, engine
wear will be excessive and engine life shortened.
The air cleaner element is a viscous type. It is unnec-
essary to clean or wash the element.
Do not operate the engine with the air cleaner
element removed. The air cleaner element not
only filters intake air but also stops flames if the
engine backfires. If the air cleaner element is
not installed when the engine backfires, you
could be burned.
„ Replacing the air cleaner element
Replace the air cleaner element according to the
maintenance schedule in the “Warranty and Mainte-
nance Booklet”. Under extremely dusty conditions, re-
place it more frequently. It is recommended that you
always use genuine SUBARU parts.

11 - 2 2
Maintenance and service
T
Non-turbo models
1. Unsnap the two clamps holding the air cleaner case cover. 2. Push the air cleaner case cover in the direction of
the arrow shown in the drawing.
UGB092BA
UGB104BA

11 -2 3
Maintenance and service
– CONTINUED –
A) Air cleaner case cover
B) Air cleaner element
3. Open the air cleaner case cover and remove the air
cleaner element.
4. Clean the inside of the air cleaner cover and case
with a damp cloth and install a new air cleaner ele- ment. 5. To install the air cleaner case cover, insert the
three projections on the air cleaner case into the slits
on the air cleaner case cover and then snap the two
clamps on the air cleaner case cover.
A
B
UGB093BCUGB094BA

11 - 2 4
Maintenance and service
T
Turbo models
1. Unsnap the two clamps holding the air cleaner case cover. A) Air cleaner case cover
B) Air cleaner element
2. Open the air cleaner case cover and remove the air
cleaner element.
3. Clean the inside of the air cleaner cover and case
with a damp cloth and install a new air cleaner ele- ment.
USB521BA
B A
USB522BC

11 -2 5
Maintenance and service
– CONTINUED –
4. To install the air cleaner case cover, insert the two
projections on the air cleaner case cover into the slits
on the air cleaner case and then snap the two clamps
on the air cleaner case cover.
Spark plugs
It may be difficult to replace the spark plugs. It is rec-
ommended that you have the spark plugs replaced by
your SUBARU dealer.
The spark plugs should be replaced according to the
maintenance schedule in the “Warranty and Mainte-
nance Booklet”.
yWhen disconnecting the spark plug cables,
always grasp the spark plug cap, not the ca-
USB523BA
HSB032BA

11 - 2 6
Maintenance and service
bles. y
Make sure the cables are replaced in the cor-
rect order.
„ Recommended spark plugs
Non-turbo models:
FR5AP-11 (NGK)
Turbo models:
ILFR6B (NGK)
Drive belts
A) Power steering pump pulley
B) Air conditioner compressor pulley
C) Crank pulley
The alternator, power steering pump, and air condi-
tioner compressor depend on drive belts. Satisfactory
performance requires that belt tension be correct.
To check belt tension, place a straightedge (ruler)
across two adjacent pulleys and apply a force of 22 lbs
(98 N, 10 kg) midway between the pulleys by using a
spring scale. Belt deflection should be the amount
specified. If a belt is loose, cracked, or worn, contact
B
C a
b
A
HSB033BC

11 -2 7
Maintenance and service
– CONTINUED –
your SUBARU dealer.
in (mm)Manual transmission oil „Checking the oil level
Non-turbo models:
A) Yellow handle
Deflection
New belt Used belt
a 0.28 – 0.35 (7.0 – 9.0) 0.35 – 0.43 (9.0 – 11.0)
b 0.30 – 0.33 (7.5 – 8.5) 0.35 – 0.40 (9.0 – 10.0)
HSB018DC
A
