2005 NISSAN X-TRAIL steering

TROUBLE DIAGNOSIS
BRC-109
[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC

Inspection 15 CAN Communication Circuit, ESP/TCS/ABS Control Unit and
Steering Angle Sensor
EFS005WK
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn ignition switch OFF, disconnect the ESP/TCS/ABS control unit connector, and check the terminal for
deformation, disconnection, looseness, and so on. If there is a malfunction, repair or replace the terminal.
2. Reconnect connector to perform self-diagnosis.
Is
“CAN COMM CIRCUIT” or “ST ANG SEN COM CIR” displayed in the self-diagnosis display items?
YES >> Print out the self-diagnostic results, and refer to BRC-56, "CAN COMMUNICATION" .
NO >> Connector terminal connection is loose, damaged, open, or shorted.
Component CheckEFS005WL
ESP OFF SWITCH

Disconnect the ESP OFF switch connector. Check for continuity
between the terminal No. 1 and No. 2.
ESP RELAY BOX
Disconnect the relay box connectors. Check for continuity, resis-
tance value, and insulation between any pair of terminals in the relay
box. 1 - 2 : Pressing the switch will make a continu-
ity, and releasing it will stop the continuity.
SFIA1822E
SFIA1823E

BRC-122
[ESP/TCS/ABS]
STEERING ANGLE SENSOR

STEERING ANGLE SENSORPFP:25554
Removal and InstallationEFS004HA
REMOVAL
1. Remove spiral cable assembly. Refer to SRS-33, "SPIRAL CABLE" .
2. Remove steering angle sensor from spiral cable assembly.
INSTALLATION
Install in the reverse order of removal.
NOTE:
After work, make sure to adjust neutral position of steering angle sensor. Refer to BRC-52, "
Adjustment of
Steering Angle Sensor Neutral Position" .
SFIA1404E

HEATER & COOLING UNIT ASSEMBLY
ATC-131
C
D
E
F
G
H
I
K
L
MA
B
AT C

HEATER & COOLING UNIT ASSEMBLYPFP:27110
Removal and InstallationEJS000UT
REMOVAL
1. Use a refrigerant collecting equipment (for HFC-134a) to discharge refrigerant.
2. Drain coolant from cooling system. Refer to CO-9, "
Changing Engine Coolant" for QR engine or CO-32,
"Changing Engine Coolant" for YD engine.
3. Disconnect two heater hoses from heater core pipe.
4. Remove mounting bolt from low-pressure flexible hose.
CAUTION:
Cap or wrap the joint of the pipe with suitable material such
as vinyl tape to avoid the entry of air.
5. Remove the blower unit. Refer to ATC-125, "
BLOWER UNIT" .
6. Remove clips of vehicle harness from steering member.
7. Remove mounting nuts, and then remove instrument stay.
8. Remove mounting bolts from heater & cooling unit.
RJIA0060E
RJIA0061E
RJIA2444E

ATC-132
HEATER & COOLING UNIT ASSEMBLY

9. Remove steering member.
10. Remove heater & cooling unit.
CAUTION:
Cap or wrap the joint of the pipe with suitable material such as vinyl tape to avoid the entry of air.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:

Replace the O-ring of the low-pressure flexible hose and the high-pressure pipe with a new one,
and then apply compressor oil to it when installing it.

When recharging refrigerant, check for leaks.
NOTE:
When filling radiator with coolant, refer to CO-9, "
Changing Engine Coolant" for QR engine or CO-32, "Chang-
ing Engine Coolant" for YD engine.
Disassembly and AssemblyEJS000UU
NOTE:
This illustration is for RHD models. The layout for LHD models is symmetrically opposite.
RJIA2404E

AV-1
AUDIO VISUAL, NAVIGATION & TELEPHONE SYS-
TEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION AV
A
B
AV

AUDIO VISUAL, NAVIGATION & TELEPHONE SYSTEM
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Wiring Diagrams and Trouble Diagnosis .................. 3
AUDIO ......................................................................... 4
System Description .................................................. 4
WITH CASSETTE DECK ...................................... 4
WITHOUT CASSETTE DECK .............................. 6
Component Parts Location ....................................... 8
Wiring Diagram —AUDIO— (With Cassette Deck) ..... 9
LHD MODELS ....................................................... 9
RHD MODELS ..................................................... 11
Schematic (Without Cassette Deck) ...................... 13
LHD MODELS ..................................................... 13
RHD MODELS .................................................... 14
Wiring Diagram —AUDIO— (Without Cassette
Deck) ...................................................................... 15
LHD MODELS WITH NAVIGATION .................... 15
LHD MODELS WITHOUT NAVIGATION ............ 18
RHD MODELS WITH NAVIGATION ................... 21
RHD MODELS WITHOUT NAVIGATION ............ 24
Terminals and Reference Value for Audio Unit With
Cassette Deck ........................................................ 27
Terminals and Reference Value for Audio Unit With-
out Cassette Deck .................................................. 28
Audio Steering Wheel Switch Resistance Check ... 29
Trouble Diagnoses ................................................. 30
AUDIO UNIT ....................................................... 30
Inspection ............................................................... 30
AUDIO UNIT ....................................................... 30
ANTENNA ........................................................... 30
Audio Steering Wheel Switch Does Not Operate
(With Cassette Deck) ............................................. 31
Audio Steering Wheel Switch Does Not Operate
(Without Cassette Deck) ........................................ 31
Speed Sensitive Volume System Does Not Work
(With Cassette Deck) ............................................. 33
Removal and Installation of Audio Unit (With Cas-
sette Deck) ............................................................. 34REMOVAL ........................................................... 34
INSTALLATION ................................................... 34
Removal and Installation of Audio Unit (Without
Cassette Deck) ....................................................... 35
REMOVAL ........................................................... 35
INSTALLATION ................................................... 35
Removal and Installation of Speakers .................... 35
REMOVAL ........................................................... 35
INSTALLATION ................................................... 35
Removal and Installation of Tweeters ..................... 35
REMOVAL ........................................................... 35
INSTALLATION ................................................... 36
AUDIO ANTENNA .................................................... 37
Antenna Route ........................................................ 37
Removal and Installation of Roof Antenna ............. 37
NAVIGATION SYSTEM ............................................. 38
System Description ................................................. 38
NAVIGATION SYSTEM ....................................... 38
Component Description .......................................... 41
NAVI CONTROL UNIT ........................................ 41
GPS ANTENNA ................................................... 41
DISPLAY .............................................................. 42
NAVI SWITCH ..................................................... 42
TRANSFER UNIT ................................................ 43
VOICE CHANGE RELAY .................................... 43
TMC TUNER ....................................................... 43
System Operation Description ................................ 44
NAVIGATION SYSTEM ....................................... 44
MAP VIEWING STYLE ........................................ 44
MAP DISPLAY ..................................................... 45
FUNCTION OF NAVI SWITCH ............................ 46
Precautions for NAVI Control Unit Replacement .... 49
Component Parts And Harness Connector Location
... 50
Schematic ............................................................... 51
Wiring Diagram — NAVI — .................................... 52
LHD MODELS ..................................................... 52
RHD MODELS .................................................... 57
Terminals and Reference Value for NAVI Control
Unit ......................................................................... 62

AV-4
AUDIO

AUDIOPFP:28111
System DescriptionEKS00INI
WITH CASSETTE DECK
Refer to Owner's Manual for audio system operating instructions.
Power is supplied at all times

through 15A fuse [No. 32, located in the fuse and fusible link box]

to audio unit terminal 6.
With the ignition switch in the ACC or ON position, power is supplied

through 10A fuse [No. 4, located in the fuse block (J/B)]

to audio unit terminal 10.
When audio switch is pushed, audio signals are supplied

through audio unit terminals 1, 2, 3, 4, 13, 14, 15, and 16

to terminals 1 and 2 of front door speaker LH and RH

to terminals 1 and 2 of rear speaker LH and RH

to terminals 1 and 2 of tweeter LH and RH.
When one of audio steering wheel switches is pushed to volume up, seek up, or source, resistance in steering
switch circuit changes depending on which button is pushed. This will change voltage. Power is supplied

from audio unit terminal 26

through combination switch (spiral cable) terminal 4 and 15

to audio steering wheel switch terminal 1.
Ground is supplied

from audio steering wheel switch terminal 2

through combination switch (spiral cable) terminal 17 and 7

to audio unit terminal 29.
When one of audio steering wheel switches is pushed to volume down, seek down, or special, resistance in
steering switch circuit changes depending on which button is pushed. This will change voltage. Power is sup-
plied

from audio unit terminal 27

through combination switch (spiral cable) terminal 5 and 16

to audio steering wheel switch terminal 3.
Ground is supplied

from audio steering wheel switch terminal 2

through combination switch (spiral cable) terminal 17 and 7

to audio unit terminal 29.
Speed Sensitive Volume System
Volume level of this system gone up and down automatically in proportion to the vehicle speed. And the con-
trol level can be selected by the customer.

AV-6
AUDIO

Personal Audio Setting
Description

The radio is designed to store several settings (volume, bass, treble, preset stations) with every NATS
ignition key used. Up to a maximum of 4 NATS keys can be registered. During the communication men-
tioned under “Anti-Theft System”, the radio will recognize the used ignition key and select the accompany-
ing settings.
WITHOUT CASSETTE DECK
Refer to Owner's Manual for audio system operating instructions.
Power is supplied at all times

through 15A fuse [No. 32, located in the fuse and fusible link box]

to audio unit terminal 9.
With the ignition switch in the ACC or ON position, power is supplied

through 10A fuse [No. 4, located in the fuse block (J/B)]

to audio unit terminal 3.
When audio switch is pushed, audio signals are supplied

through audio unit terminals 7, 10, 11, 12, 13, 14, 15, and 16

to terminals 1 and 2 of front door speaker LH and RH

to terminals 1 and 2 of rear speaker LH and RH

to terminals 1 and 2 of tweeter LH and RH.
When one of audio steering wheel switches is pushed to volume up, seek up, or source, resistance in steering
switch circuit changes depending on which button is pushed. This will change voltage. Power is supplied

from audio unit terminal 20

through combination switch (spiral cable) terminal 4 and 15

to audio steering wheel switch terminal 1.
Ground is supplied

from audio steering wheel switch terminal 2

through combination switch (spiral cable) terminal 17 and 7

to audio unit terminal 22.
When one of audio steering wheel switches is pushed to volume down, seek down, or special, resistance in
steering switch circuit changes depending on which button is pushed. This will change voltage. Power is sup-
plied

from audio unit terminal 21

through combination switch (spiral cable) terminal 5 and 16

to audio steering wheel switch terminal 3.
Ground is supplied

from audio steering wheel switch terminal 2

through combination switch (spiral cable) terminal 17 and 7

to audio unit terminal 22.

AV-28
AUDIO

Terminals and Reference Value for Audio Unit Without Cassette Deck EKS00EHT
26
(L/B)GroundRemote con-
trol AInput ONPress SOURCE
switchApprox. 0V
Steering wheel audio
controls do not func-
tion. Press SEEK UP
switchApprox. 1.7V
Press VOL UP
switchApprox. 3.3V
Except for above Approx. 5V
27
(L/R)GroundRemote con-
trol BInput ONPress SPECIAL
switchApprox. 0V
Steering wheel audio
controls do not func-
tion. Press SEEK
DOWN switchApprox. 1.7V
Press VOL
DOWN switchApprox. 3.3V
Except for above Approx. 5V
29
(B)GroundRemote con-
trol ground– ON – Approx. 0V – Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference value Example of symptom
(+) (–)Ignition
switchOperation
Te r m i n a l
(Wire color)
ItemSignal
input/
outputCondition
Reference valueExample of
symptom
(+) (–)Ignition
switchOperation
1
(R/L)GroundLighting
switch signalInput ONLighting switch
ON (1st position)Approx. 12VAudio unit illumi-
nation does not
function when
lighting switch is
ON (position 1). Lighting switch
OFFApprox. 0V
3
(GY/L)Ground ACC power Input ACC – Battery voltageSystem does not
work properly.
5
(PU)– immobilizer – – – – –
6
(Y/R)GroundAntenna
signalOutput ON – More than approx. 10VReceiving status
of radio broadcast
becomes bad.
9
(Y/G)Ground Battery power Input OFF – Battery voltage System does not
work properly.
11
(SB)
*1
(L)*2
10
(GY)*1
(B/W)*2
Audio sound
signal front
LH Output ONReceive audio
signalNo sound from
front door speaker
or tweeter LH.
12
(LG)13
(B/Y)Audio sound
signal rear
LH Output ONReceive audio
signalNo sound from
rear door speaker
LH.
SKIA0177E
SKIA0177E
