BRC-32
[ABS]
TROUBLE DIAGNOSIS

ACTIVE TEST
CAUTION:

Do not perform active test while driving.

Make sure to completely bleed air from the brake system.

Active test can not be performed with ABS warning lamp on.
Operation Procedure
1. Touch “ABS”, “ACTIVE TEST” in order on the CONSULT-II screen.
2. The test item selection screen is displayed.
3. Touch necessary test item.
4. With the “MAIN SIGNALS” display shown in reverse, touch “START”.
5. The Active Test screen will be displayed, so conduct the following test.
NOTE:

When the active test is conducted while depressing pedal, pedal depression amount will change, but
this is normal.

Approximately 10 seconds after the operation is begun, “TEST STOP” will be displayed.

To conduct a retest after “TEST STOP” is displayed, touch “BACK” and conduct the from the step 3.
Test Item
Solenoid valve
CAUTION:
The example shown is for the front right wheel. The procedure for the other wheels is the same as
given below.
1. For ABS solenoid valve, touch “UP”, “KEEP”, and “DOWN”.Then
use screen monitor to check that solenoid valve operates as
shown in Solenoid Valve Operation Chart. Refer to “Solenoid
Valve Operation Chart”.
*: ON for 1 to 2 seconds after the touch, and then OFF
PBR976C
SFIA0678E
OperationABS solenoid valve
UP KEEP DOWN
FR RH SOLFR RH IN SOL OFF ON ON
FR RH OUT SOL OFF OFF ON*

BRC-34
[ABS]
TROUBLE DIAGNOSIS

Correct and Quick DiagnosisEFS004GC
DIAGNOSIS PRECAUTIONS

Before performing the trouble diagnosis, always read the general information (GI) to confirm the general
precautions. Refer to GI-4, "
General Precautions" .

After completing service, always erase the self-diagnosis results. Refer to BRC-28, "Operation Proce-
dure" .

When inspection of the continuity or voltage between units is performed, check connector terminals for
disconnection, looseness, bend, or collapse. If any non-standard condition is detected, repair or replace
applicable part.

Intermittent malfunctions may be caused by a poor connection in the harness, connector, or terminal.
Move harnesses, harness connectors, or terminals by hand to make sure all connections are solid and
undamaged.

If a circuit tester is used for the check, be careful not to forcibly extend any connector terminal.

While a phenomena like those shown in the following table may occur, this is not malfunction because the
system is working normally.
ON and OFF Timing for ABS Warning Lamp
×: ON –: OFF Symptom Symptom description Result
Motor operation noiseThis is the sound of the motor operating inside ABS actuator, and there
may be some low sounds while the ABS is operating.
Normal
Just after the engine starts, the motor operating noise may be heard.
This is a normal status of the system operation check.
System operation check
noiseWhen the engine is started, you may barely be able to hear a slight
thudding sound from the engine room, but this sound is made by the
system operation check and is normal.Normal
ABS operation (longer stop-
ping distance)Stopping distance may be longer for vehicles with ABS when the vehicle
drives on rough or snow-covered roads. Use lower speeds when driving
on these kinds of roads.Normal
Condition ABS warning lamp Remarks
Ignition switch OFF – —
For approximately “1” second after igni-
tion switch ON×—
After approximately “1” second after igni-
tion switch ON. (When system is normal)– Turns off 1 second after engine start
ABS malfunction×When there is an ABS actuator and elec-
tric unit malfunction (power or ground
malfunction)
EBD malfunction×–

TROUBLE DIAGNOSIS
BRC-35
[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC

Basic InspectionEFS004GD
BASIC INSPECTION 1 BRAKE FLUID AMOUNT, LEAKS, AND BRAKE PADS INSPECTION
1. Check fluid level in the brake reservoir tank. If fluid level is low, refill the brake fluid.
2. Check the brake piping and around the ABS actuator for leaks. If there is leaking or oozing fluid, check the
following items.

If ABS actuator and electric unit (control unit) connection is loose, tighten the piping to the specified
torque and re-conduct the leak inspection to make sure there are no leaks.

If there is damage to the connection flare nut or ABS actuator and electric unit (control unit) screw,
replace the damaged part and re-conduct the leak inspection to make sure there are no leaks.

When there is fluid leaking or oozing from a part other than ABS actuator and electric unit (control unit)
connection, if the fluid is just oozing out, use a clean cloth to wipe off the oozing fluid and re-check for
leaks. If fluid is still oozing out, replace the damaged part.
CAUTION:
ABS actuator and electric unit (control unit) cannot be disassembled.
3. Check the brake pad degree of wear. Refer to BR-27, "
PA D T H I C K N E S S" in “Front Disc Brake” and BR-
32, "PAD WEAR INSPECTION" in “Rear Disc Brake”.
BASIC INSPECTION 2 POWER SYSTEM TERMINAL LOOSENESS AND BATTERY INSPECTION
Make sure the battery positive cable, negative cable and ground connection are not loose. In addition, check
the battery voltage to make sure it has not dropped.
BASIC INSPECTION 3 ABS WARNING LAMP
1. Make sure that when the ignition switch is turned ON, the ABS warning lamp turns on for approximately 1
second. If they do not turn on, perform CAN communication system diagnosis. Refer to BRC-43, "
Inspec-
tion 7: CAN Communication System" .
2. Check if the ABS warning lamp turns off approximately 1 second after the ignition switch is turned ON, If it
do not turn off, perform self-diagnosis.
3. if ABS warning lamp has not turned off 10 seconds after the engine has been started, perform self-diagno-
sis of the ABS actuator and electric unit (control unit).
4. Always erase the self-diagnostic results after completing self-diagnosis. Refer to BRC-28, "
Operation Pro-
cedure" .

TROUBLE DIAGNOSIS
BRC-43
[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC

OK or NG
OK >> ABS actuator and electric unit (control unit) malfunction. Replace ABS actuator and electric unit
(control unit).
NG >> G sensor malfunction. Replace G sensor.
Inspection 7: CAN Communication SystemEFS004HI
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn ignition switch OFF, disconnect the ABS actuator and electric unit (control unit) connector, and check
the terminal for deformation, disconnection, looseness, and so on. If there is a malfunction, repair or
replace the terminal.
2. Reconnect connector to perform self-diagnosis.
Is
“CAN COMM CIRCUIT” displayed in the self-diagnosis display items?
YES >> Print out the self-diagnostic results, and refer to BRC-8, "CAN COMMUNICATION" .
NO >> Connector terminal connector is loose, damaged, open, or shorted.
Symptom 1: ABS Works FrequentlyEFS004HJ
1. CHECK START
Check longitudinal brake force distribution using a brake tester.
OK or NG
OK >> GO TO 2.
NG >> Check brake system.
2. CHECK FRONT AND REAR AXLE
Check to make sure that there is no excessive play in the front and rear axles. Refer to Front: FAX-7, "
On-
Vehicle Inspection" , Rear: RAX-6, "WHEEL BEARING INSPECTION" (2WD), RAX-10, "REAR WHEEL
BEARING" (4WD).
OK or NG
OK >> GO TO 3.
NG >> Repair.
3. CHECK WHEEL SENSOR AND SENSOR ROTOR
Check wheel sensor and sensor rotor for the following.

Sensor installation for damage

Sensor rotor installation for damage

Sensor connector engagement

Sensor harness
OK or NG
OK >> GO TO 4.
NG >>

Replace wheel sensor or sensor rotor.

Repair harness.
4. CHECK ABS WARNING LAMP DISPLAY
Make sure that the warning lamp turns off approximately 1 second after the key switch is turned on or when
driving.
OK or NG
OK >> Normal
NG >> Perform self-diagnosis. Refer to BRC-28, "
SELF-DIAGNOSIS" .

TROUBLE DIAGNOSIS
BRC-45
[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC

Symptom 4: ABS Does Not WorkEFS004HM
CAUTION:
ABS does not operate when speed is 10 km/h or lower.
1. CHECK ABS WARNING LAMP DISPLAY
Make sure that the warning lamp turns off approximately 1 second after the key switch is turned on or when
driving.
OK or NG
OK >> GO TO 3. Check wheel sensor and sensor rotor in BRC-43, "Symptom 1: ABS Works Frequently"
.
NG >> Perform self-diagnosis. Refer to BRC-28, "
SELF-DIAGNOSIS" .
Symptom 5: Pedal Vibration and ABS Operation NoiseEFS004HN
CAUTION:
Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly
depressed (just place a foot on it). However, this is normal.

When shifting gears

When driving on slippery road

During cornering at high speed

When passing over bumps or grooves (Approx. 50 mm or more)

When pulling away just after starting engine (Approx. 10 km/h or more)
1. SYMPTOM CHECK 1
Check if pedal vibration or operation sounds occur when the engine is started.
OK or NG
OK >> GO TO 2.
NG >> Perform self-diagnosis. Refer to BRC-28, "
SELF-DIAGNOSIS" .
2. SYMPTOM CHECK 2
Check symptoms when electrical component (headlamps, etc.) Switches are operated.
Do symptoms occur?
YES >> Check if there is a radio, antenna, antenna lead wire, or wiring close to the control unit. If there is,
move it farther away.
NG >> GO TO 3. Check wheel sensor and sensor rotor in BRC-43, "
Symptom 1: ABS Works Frequently"
.

BRC-50
[ESP/TCS/ABS]
PRECAUTIONS

[ESP/TCS/ABS]PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EFS004H7
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SRS and SB section of
this Service Manual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Brake SystemEFS0019O

Recommended fluid is brake fluid “DOT 3” or “DOT 4”.

Do not reuse drained brake fluid.

Be careful not to splash brake fluid on painted areas; it may cause paint damage. If brake fluid is splashed
on painted areas, wash it away with water immediately.

Do not use mineral oils such as gasoline or kerosene. They will ruin rubber parts of hydraulic system.

Using a flare nut torque wrench, securely tighten brake tube
flare nuts.

When installing brake piping, be sure to check torque.

Before working, turn the ignition switch OFF and disconnect the
connectors for the ESP/TCS/ABS control unit and control unit or
the battery negative terminal.

Burnish the brake pad contact surfaces after refinishing or
replacing drums or rotors, after replacing pads or linings, or if a
soft pedal occurs at very low mileage. Refer to BR-31, "
BRAKE
BURNISHING PROCEDURE" .
WARNING:
Clean brakes with a vacuum dust collector to minimize risk of health hazard from powder caused
by friction.
Precautions for Brake ControlEFS0019P

During the ESP/TCS/ABS operation, the brake pedal vibrates lightly and its mechanical noise may be
heard. This is a normal condition.

Just after starting the vehicle after ignition switch ON, the brake pedal may vibrate or the motor operating
noise may be heard from the engine compartment. This is a normal status of the operation check.

The stopping distance may be longer than that of vehicles without ABS when the vehicle drives on rough,
gravel, or snowy (fresh deep snow) road.

If a malfunction is indicated by the ABS warning lamp, or other warning lamps, collect the necessary infor-
mation from the customer (what symptoms are present under what conditions) and find out the possible
causes before starting the service. Besides the electrical system inspection, check the booster operation,
brake fluid level, and oil leaks.

If the tyre size and type are used in a improper combination, or the brake pads are not NISSAN genuine
parts, the stopping distance or steering stability may deteriorate.

If there is a radio, antenna, or antenna lead-in wire (including wiring) near the control unit, the ESP/TCS/
ABS function may have a malfunction.

If aftermarket parts (car stereo, CD player, etc.) have been installed, check harnesses for pinches, open,
and improper wiring.
SBR820BA

SYSTEM DESCRIPTION
BRC-53
[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC

SYSTEM DESCRIPTIONPFP:00000
System DiagramEFS0019X
ESP FunctionEFS0019W
1. The Electronic Stability Program is called the ESP for short. ESP is indicated as ESP on CONSULT-II
screen.
2. In addition to the ABS/TCS function, ESP detects a driver's steering operation amount and brake opera-
tion amount from steering angle sensor and pressure sensor. Using the information from yaw rate/side G
sensor and wheel sensors, ESP judges the driving condition (conditions of understeer and oversteer) to
improve the stability by controlling brake on 4 wheels and engine output.
3. During ESP operation, SLIP indicator lamp flashes to inform the driver of the operation.
CAUTION:

During ESP operation, body and the brake pedal lightly vibrate and their mechanical noise may be
heard. This is a normal condition.

If vehicle is rotated on a turn table, or rolled and rocked on a ship, the ABS warning lamp,
ESP OFF indicator lamp, and SLIP indicator lamp may turn on. In this case, start engine on a nor-
mal road again. If the ABS warning lamp, ESP OFF indicator lamp, and SLIP indicator lamp turn
off after the restart, it is normal.

When driving in a steep slope such as a bank, ABS warning lamp, ESP OFF indicator lamp, and
SLIP indicator lamp may turn on. In this case, start the engine on a normal road again. If ABS
warning lamp, ESP OFF indicator lamp, and SLIP indicator lamp turn off after the restart, it is nor-
mal.
TCS FunctionEFS0019V
1. With the wheel sensor signals from 4 wheels, the ESP/TCS/ABS control unit detects a wheel spin. If a
wheel spins, the control unit controls brake fluid pressure to the spinning wheel, and cuts the fuel to the
engine. It also closes the throttle valve to reduce the engine torque. Furthermore, throttle position is con-
trolled to the appropriate engine torque.
2. If a wheel spins, the TCS system works and function by applying brake fluid pressure to the spinning
wheel.
SFIA2012E

BRC-54
[ESP/TCS/ABS]
SYSTEM DESCRIPTION

3. During TCS operation, it informs a driver of system operation by flashing SLIP indicator lamp.
CAUTION:

During TCS operation, body and brake pedal lightly vibrate and the mechanical noise may be
heard. This is a normal condition.

Depending on road circumstances, a driver may have a sluggish feel. This is not malfunction,
because the optimum traction has the highest priority by TCS operation.

When the vehicle is passing through a road where the surface friction coefficient varies, down-
shifting or depressing the accelerator pedal fully may activate TCS temporarily.
ABS FunctionEFS0019U
1. In cases of braking suddenly or braking on slippery road (ice road), ABS functions prevent wheels from
lock, improve the stability in sudden braking, and make efficient avoidance of obstacles with steering
manipulation by detecting wheel speed and controlling brake fluid pressure.
2. EBD is integrated in ESP/TCS/ABS system.
CAUTION:

During ABS operation, brake pedal lightly vibrates and its mechanical noise may be heard. This is
a normal condition.

When starting engine, or just after starting vehicle, brake pedal may vibrate or the motor operating
noise may be heard from engine compartment. This is a normal status of the operation check.

The stopping distance may be longer than that of vehicles without ABS when vehicle drives on
rough, gravel, or snowy (fresh deep snow) road.
EBD FunctionEFS004HO

Electronic Brake Distributor is a function that detects subtle slippages between front and rear wheels dur-
ing braking, and it improves handling stability by electronically controlling the brake fluid pressure which
results in reduced rear wheel slippage.

In case of electrical system break down, the fail-safe function is activated, EBD and ABS becomes inoper-
ative, and ABS warning lamp and brake warning lamp are turned on.

Electrical System Diagnosis by CONSULT-II is available.
Fail-Safe FunctionEFS004HP
ESP/ TCS SYSTEM
In case of throttle control system trouble, ESP OFF indicator lamp and SLIP indicator lamp are turned on, and
the condition of vehicle is the same as the condition of vehicles without ESP/TCS equipment. In case of trou-
ble to the throttle control system, the ABS control continues to operate normally without ESP/TCS control.
CAUTION:
If the fail-safe function is activated, then perform the self- diagnosis for ESP/TCS/ABS control system.
ABS, EBD SYSTEM
In case of electrical malfunctions with the ABS, ABS warning lamp, ESP OFF indicator lamp and SLIP indica-
tor lamp will turn on. In case of electrical malfunctions with the EBD, brake warning lamp, ABS warning lamp,
ESP OFF indicator lamp and SLIP indicator lamp will turn on. Simultaneously, the ESP/ TCS/ABS become one
of the following conditions of the fail-safe function.
1. For ABS trouble, only the EBD is activated and the condition of vehicle is the same condition of vehicles
without ESP/TCS/ABS equipment.
2. For EBD trouble, the EBD and ABS become inoperative, and the condition of vehicle is the same as the
condition of vehicles without ESP/TCS/ABS, EBD equipment.
NOTE:
In condition 1 described above, an ABS self-diagnosis sound may be heard. That is a normal condition
because a self-diagnosis for “Ignition switch ON” and “The first starting” are being performed.
