2005 MITSUBISHI LANCER EVOLUTION IX Workshop Manual

PART INSTALLATION POSITIONS - ECU2-7
Front ECU
Headlamp ASSY
(with built-in discharge ECU) Radiator fan
controller
Radiator ASSY
Column switch (column
ECU built into wiper
switch)
Immobiliser
ECU
Blower
unit
Blower pulse
controllerEngine ECU

PART INSTALLATION POSITIONS - ECU2-8
Glove box
Power window main
switch (built-in ECU)Sunroof motor ASSY
(built-in ECU)
Power window main
switch (built-in ECU)

PART INSTALLATION POSITIONS - RELAY2-9
RELAYS
Fuel pump relay 3
Electric pump relay
Hydraulic unit
A/C compressor relay
Engine control relay
Ignition coil relay
Starter relayCompressor fan relay (HI)
Compressor fan relay (LO)
Horn relay
Fog lamp relay
Radiator fan control relay
M3020000400514

PART INSTALLATION POSITIONS - SOLENOID VALVES2-10
SOLENOID VALVES
Fuel pump relay 1
Intercooler water
spray relay
Fuel pump relay 2Fuel pump relay 1
Blower relay
Power window relay
Oil feeder control
valveFuel pressure
solenoid valve
Purge control
solenoid valve

PART INSTALLATION POSITIONS - SOLENOID VALVES2-11
Alternator
Secondary air
control solenoid valve
Hydraulic unit
(with in-built solenoid valve)
Waste gate solenoid
valve 1
Waste gate solenoid
valve 2 Battery Hydraulic unit ASSY
Proportional
valve
(for ACD)
Proportional
valve (for AYC)Directional valve
(left, right)

PART INSTALLATION POSITIONS - FUSIBLE LINKS / FUSE2-12
FUSIBLE LINKS / FUSES
Fusible
links 6, 7
Dedicated fuses
1 – 18, 24
Generic
fuses 1 – 20 Dedicated
fuses 21, 23 Fusible
links 4, 5
Fusible
links 2,3
Fusible
link 1

PART INSTALLATION POSITIONS - INSPECTION CONNECTORS / SPARE CONNECTORS2-13
INSPECTION CONNECTORS / SPARE CONNECTORS
Front ECU
Spare connector
for fog lamp relay
Spare audio
connector
Spare generic
connectorSpare connector for
fog lamp switch
Connector for detecting
engine speed

PART INSTALLATION POSITIONS - EARTH CABLES2-14
EARTH CABLES
Diagnosis
connector
