2005 MITSUBISHI LANCER EVOLUTION IX Workshop Manual

GENERAL INFORMATION - HOW TO READ THE WIRING DIAGRAMS0-7
ItemNoConnector / EarthSymbolDetails
Terminals and
connectors-Different terminal symbols are
used to indicate male terminals,
which are inserted into another
terminal, and female terminals,
which receive other terminal. A
connector containing male
terminals is called a male
connector, and a connector
containing female connectors is
called a female connector. The
connector symbol for a male
connector has a two-line outline,
whereas the symbol for a female
connector has a single-line outline,
in order to distinguish them in the
diagrams.
Connector
symbols1The symbol shows the connector
used in the actual vehicle, as
viewed from the direction of the
illustration. At the connection with
the device, the connector symbol
on the device side, and the
intermediate connector are shown
by male connector symbols.
Spare connectors and inspection
connectors are not connected to
the device, and therefore, these
are represented by a harness side
connector symbol. Note, however,
that the above does not apply to
diagnosis connectors.
2
3
Male connector
Male connector Male
terminal
Female
terminal
Device
Intermediate connector
Spare connector / Inspection connectorMale
terminal
Female
terminal

SUMMARY - OVERVIEW OF CIRCUIT DIAGRAMS0-8
ItemNoConnector / EarthSymbolDetails
Connector
connections4Aconnection between a device
and a harness side connector
may be achieved by direct
insertion into the device (direct
connection type) or by connecting
to a harness connector on the
device (harness connection type).
These types of connection are
shown differently in the diagrams.
5
6
Earths7The earth may be a vehicle body
earth, a device earth, or an earth
provided inside the control unit.
They are depicted differently in
the diagrams.
8
9
Harness connection type
Intermediate connector
Vehicle body earth
Device earth
Earth in control unitDirect connection type

GENERAL INFORMATION - HOW TO READ THE WIRING DIAGRAMS0-9
If a cable has two colours, the first colour code indicates the standard colour (the basic colour of the cable coating), and the
second colour code indicates the marking colour.
Note :
• * : No indication : 0.5 mm2.
Cable colour in brackets indicates 0.3 mm2.
Abbreviation Symbols
The abbreviation symbols used in the wiring diagrams have the following meanings.
1. Abbreviations of System Names
Wire Colour Codes
The different wire colours are indicated by the following letter codes.
Example
M3000011000154
--

GENERAL INFORMATION - HOW TO READ THE WIRING DIAGRAMS0-10
2. Abbreviations used in internal circuits of combination meter
3. Abbreviations used in switch and relay circuits

GENERAL INFORMATION - HOW TO READ THE WIRING DIAGRAMS0-11
4. Other abbreviations

1-1
Section 1
Layout Diagrams
CONTENTS
General Layout Diagram ........................1-3
Engine Compartment .............................1-4
Engine / Transmission ...........................1-6
Instrument Panel...................................1-10Floor / Roof ...........................................1-16
Door .......................................................1-18
Boot Compartment ...............................1-20

LAYOUT DIAGRAMS1-2
