ELECTRICAL COMPONENTS
384
64L013
2. Make sure the inoperative component is turned off. Pull
the suspected fuse straight out with the pull±out tool and
check it. If it has blown, push a new fuse into the clips.
64G008

Good
Blown
a. Look carefully at the fuse. If the thin wire is broken, the fuse
has blown. If you are not sure or if it is too dark to see, try
replacing the suspected fuse with one of the same value that
you know is good.
b. Only install a fuse with the amperage rating designated on
the fuse box lid.
If you do not have a spare fuse, in an emergency you can pull
out the ªCIGº, ªRADIO NO.1º or ªOBDº fuse, which may b\
e
dispensable for normal driving, and use it if its amperage rating
is the same.
If you cannot use one of the same amperage, use one lower
than, but as close to the amperage as possible. If the
amperage is lower than that specified, the fuse might blow out
again but this does not indicate anything wrong. Be sure to get
the correct fuse as soon as possible and return the substitute
to its original clips.
04 06.30

ELECTRICAL COMPONENTS
385
It is a good idea to purchase a set of spare fuses and keep them
in your vehicle for emergencies.
If the new fuse immediately blows out, there is a problem with
the electrical system. Have your Lexus dealer correct it as
soon as possible.
CAUTION
Never use a fuse with a higher amperage rating, or any
other object, in place of a fuse. This may cause
extensive damage and possibly a fire.
CHECKING THE CARTRIDGE TYPE
FUSES
SV64005

1Good 2Melted
If the headlights or other electrical components do not
work and the blade type fuses are O.K., check the
cartridge type fuses. If any of the cartridge type fuses are
blown, they must be replaced.
If there is an overload in the circuits from the battery, the fuses
are designed to blow before the entire wiring harness is
damaged.
04 06.30

ELECTRICAL COMPONENTS
386
CAUTION
Always use a genuine Lexus fuse or equivalent for
replacement. Never install an ordinary wire ± even for a
temporary fix. This may cause extensive damage and
possibly a fire.
NOTICE
Before replacing the fuses, have the cause of electricaloverload determined and repaired by your Lexus dealer.
ADDING WASHER FLUID
SS64013
If the washer tank becomes nearly empty, add washer
fluid.
You may use plain water as washer fluid. However, in cold
areas where temperatures range below the freezing point, use
washer fluid containing antifreeze. This product is available at
your Lexus dealer and most auto parts stores. Follow the
manufacturer's directions for how much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute because it may damage your vehicle's paint.
04 06.30

ELECTRICAL COMPONENTS
387
CHECKING THE HEADLIGHT AIM
SV64027

1Vertical movement adjusting bolt 1
2Vertical movement adjusting bolt 2
Before checking the headlight aim:
1. Be sure that the body around the headlight is not deformed.
2. Park the vehicle on a level spot.
3. The driver gets into the driver's seat and puts the vehicle in
a state readying for a driving (with a full tank).
4. Bounce the vehicle several times.
Adjusting the vertical aiming
SV64051
1. Turn the vertical movement adjusting bolt 1 in either
direction. At this time, keep the turning direction and number
of turns in mind.
04 06.30

ELECTRICAL COMPONENTS
388
SB64028
2. Turn the vertical movement adjusting bolt 2 the same
number of turns and in the same direction as step 1.
REPLACING LIGHT BULBS
The illustration on the following pages show the locations of
light bulbs. If it is necessary to replace a bulb, take your vehicle
to your Lexus dealer as soon as possible. Use bulbs with the
bulb numbers and wattage ratings given in the table.
CAUTION
 To prevent burning yourself, do not replace the light
bulbs while they are hot.
 Halogen bulbs have pressurized gas inside and
require special handling. They can burst or shatter if
scratched or dropped. Hold a bulb only by its plastic
or metal case. Do not touch the glass part of a bulb
with bare hands.
Vehicles with discharge headlightsÐ
 Do not touch the high voltage socket when the
headlight turns on. 20000 V is momentarily generated
and may cause severe injury by electric shock.
 Do not disassemble, repair or take apart the headlight
bulbs, connector, power supply circuits and rotated
components. Or you may be injured by electric
shocks. Call your dealer when the headlights fail to
work or have to be replaced or disposed of.
NOTICE
Only use a bulb of the listed type.
04 06.30

ELECTRICAL COMPONENTS
389
The inside of the lens of exterior lights such as headlights may
temporarily
fog up when the lens becomes wet in the rain or in
a car wash. This is not a problem because the fogging is
caused by the temperature dif ference between the outside and
inside of the lens, just like the windshield fogs up in the rain.
However, if there is a large drop of water on the inside of the
lens, or if there is water pooled inside the light, contact your
Lexus dealer. LIGHT LOCATION
SV64032
Light Bulbs
Bulb No. W Type
1Headlights (High beam) HB3 60 A
2Parking lights 168 5 E
3Headlights (Low beam) D2R 35 B
4Front fog lights ±±± 55 C
5Front turn signal lights ±±± 21 D
6Front side marker lights 194 3.8 E
04 06.30

ELECTRICAL COMPONENTS
390Sedan
SV64013
Light Bulbs
Bulb No. W Type
1High mounted stop light 921 18 E
2License plate lights 168 5 E
3Tail/stop lights 7443 5/21 E
Rear fog lights 7440 21 E
4Back±up lights7440 21 E
5Rear turn signal lights ±±± 21 G
6Rear side marker lights 194 3.8 E
7Tail/stop lights 7443 5/21 E
8Trunk light 194 3.8 E SportCross
SV64026
Light Bulbs
Bulb No. W Type
1Tail/stop lights 7443 5/21 E
2Rear side marker lights 194 3.8 E
3Rear turn signal lights ±±± 21 D
4Back±up lights 921 18 E
5Tail/stop lights7443 5/21 E
Rear fog lights 7440 21 E
6License plate lights 168 5 E
7Luggage compartment light ±±± 5 F
04 06.30

ELECTRICAL COMPONENTS
391
SV64012
Light BulbsBulb No. W Type
1Front personal lights
with moon roof ±±± 10 H
without moon roof ±±± 8 H
2Vanity lights ±±± 3 F
3Glove box light±±± 1.2 E
4Door courtesy lights 194 3.8 E
5Interior light ±±± 8 F A: HB3 halogen bulbs
B: D2R discharge bulbs
C: H3 halogen bulbs
D: Wedge base bulbs (amber)
E: Wedge base bulbs
F: Double end bulbs
G: Single end bulbs (amber)
H: Single end bulbs
