FEATURES OF YOUR HYUNDAI
17
B060A01TG-GAT POWER WINDOWS
The power windows operate when the ignition key is in the "ON" position. The main switches are located on the driver's armrest and control the frontand rear windows on both sides of the vehicle. The windows may be opened by depressing the appropriate windowswitch and closed by pulling up the switch. To open the window on the driver's side, press the switch halfwaydown. The window moves as long as the switch is operated. B060A01TG NOTE: If the battery has been recharged or disconnected, the auto up/down win- dow system must be reset as fol-lows;
1. Turn the ignition key to "ON"
position.
2. Close each window and continue
pulling up on each power window switch for at least 0.5 second after the window is completely closed.
If the auto up/down window is notreset, it may not be operated prop- erly.
Front Auto Up/Down Windows
Open Close
B060A02TG
Driver's side
Front passenger's side
The auto up/down window is controlled by the window switch on the driver's and front passenger's armrest. To fully open the window automatically,press the switch fully down. To fully close the window automatically, pull the switch fully up. In automatic opera-tion, the window will fully open or close even if you let go of the switch. To stop the window at the desired position whilethe window is in operation, pull up or depress and release the switch to the opposite direction of the movement.

1FEATURES OF YOUR HYUNDAI
18
B060A03TG
Close
Open
Window lock
!
CAUTION:
o The safety window will only oper- ate when the automatic up win- dow operation feature is used. Safety window will not operate ifthe window is raised using the halfway down position on the power window switch.
o If an object less than 4 mm in diameter is caught between thewindow glass and the upper win-dow channel, the safety window may not detect the resistance and will not operate. Therefore, al-ways check for any obstructions before raising any window.
B060C01TG-GAT Front Safety Windows If the upward movement of the window is blocked by an object or part of thebody, the window will detect the resis- tance and will stop upward movement. The window will then lower approxi-mately 30cm to allow the object to be cleared.B060A04TG
NOTE: The power windows can be operated for 30 seconds after the ignition key is turned to the "ACC" or "LOCK"positions, or removed from the igni- tion switch. If the front doors are opened duringthese 30 seconds period, the power windows can no longer be operated without the ignition key turned to the"ON" position.
In order to prevent operation of thepassenger front and rear windows, a window lock switch is provided on the armrest of the driver's door. To disablethe power windows, press the window lock switch. To revert to normal opera- tion, press the window lock switch asecond time.

1
FEATURES OF YOUR HYUNDAI
19
!WARNING:
o Be careful that someone's head, hands and body are not trapped by a closing window.
o Never try to operate the main switch on the driver's door andthe individual door windowswitch in opposing directions at the same time. If this is done, the window will stop and cannot beopened or closed.
o Do not leave children alone in the
car. Always remove the ignition key for their safety. B060D01TG-GAT Closing and Opening the Win- dows with a Key The driver’s and passenger’s windows can be closed or opened with a key inthe driver’s door.
To close the windows, turn the key toward the front of the vehicle for 3 seconds. If the key is turned toward the rear of thevehicle while closing the window, the window will stop upward movement.
HTG2201
To open the windows, turn the key toward the rear of the vehicle for 3 seconds. If the key is turned toward the front of the vehicle while opening the window, the window will stop downward move-ment.
HTG2200
!WARNING:
Be careful that someone’s head, hands and body are not trapped by a closing window.

1FEATURES OF YOUR HYUNDAI
26
NOTE:
o If the battery has been rechargedor disconnected, the driving posi- tion memory will be lost.
o The buzzer sounds 10 times if there is a malfunction of theintergrated memory system. Havethe I.M.S checked by an autho- rized Hyundai dealer.
I.M.S control switch It is located on the driver's door trim and will function as follows; SET : When the button is pressed, the
system will memorize the posi- tion with a beep sound.
1,2 : It indicates that the system can
memorize positions up to 2 occu-pants.
B090E01TG-AAT Lumbar Support Control (Driver's seat only) To adjust the lumbar support, press the control switch the outboard side of the seat cushion. To increase the amount of lumbar support, press the front por-tion of the switch. To decrease it, press the rear portion of the switch. HTG2042-2
I.M.S (INTEGRATED MEMORY SYSTEM)
B090E01TG-GAT (If Installed) The Integrated Memory System con- trols are located on the driver's door trim. After adjusting the position of thedriver's seat and steering wheel col- umn (with electric tilt and telescopic type), use the I.M.S to memorize them.Two different driving position profiles can be entered in the I.M.S. If you turn the ignition key to the "ON" position, thememorized position is adjusted auto- matically. B090E01TG

1
FEATURES OF YOUR HYUNDAI
27
CAUTION:
In the following conditions, the I.M.S will not activate.
1. When the key is in the "OFF" posi- tion.
2. When the vehicle is running above 3 km/h.
3. When the seat is being adjusted.
4. When the shift lever is positioned in other than "P" position.
! CAUTION:
In the following conditions, the I.M.S will not memorize.
1. When the "1" or "2" button is not pushed within five seconds.
2. When the seat is being adjusted.
3. When the key is not in the "ON"
position.
4. When the shift lever is positioned in other than "P" position. To activate the memorized posi- tion
1. Place the shift lever into "P" while
the ignition switch is ON.
2. When you push button "1" or "2", the driving position will be automatically adjusted to the position recorded forthat button.
!
To memorize driving position
1. Place the shift lever into "P" while
the ignition switch is ON.
2. Adjust the driver's seat and steering wheel column (with electric tilt and telescopic type) to the desired posi-tion.
3. Push the "SET" button on the I.M.S
until the signal beeps.
4. Within five seconds, push button "1" or "2" until the signal beeps twice.The beep sounds mean that the po-sitions are memorized in the I.M.S. Reverse Parking Aid Function While the vehicle is moving backward, the outside rearview mirror(s) will movedownward to aid reverse parking safely. According to the position of the outside rearview mirror switch knob, the out-side rearview mirror(s) will operate as follows.B090E02TG

1FEATURES OF YOUR HYUNDAI
28
!
NOTE:
o The seat warmer may not operate
if ambient temperature is warm enough.
o If the seat warmer doesn't work when the ambient temperature islower than 24°C, it must bechecked at an authorized dealer.
WARNING:
Be very careful not to injure by lowtemperature burn or an attack offever as following occupants; infants, children, old man, drunken man, people who is taken sleeping drug orcold remedy.B100A01TG-GAT SEAT WARMER (If Installed) The front seats can be electrically heated individually when the ignition switch is ON. When the switch is ON, anumber ranging from 1 to 5 is displayed on the switch (5 = warmest setting). To turn off the seat warmer, set theswitch to 0. B100A01TG
L
: When the remote control outside
rearview mirror switch knob is se-lected to the "L" position, both ofthe outside rearview mirrors will move downward.
R : When the remote control outside
rearview mirror switch knob is se-lected to the "R" position, only thepassenger's outside rearview mir- ror will move downward.
Neutral :When the remote control out-
side rearview mirror switchknob is placed in the middle position, the outside rearviewmirrors will not operate while the vehicle is moving back- ward.
NOTE: When the ignition key is in the "LOCK" position, the shift lever is moved to any position except "R"position, or the remote control out- side rearview mirror switch knob is placed in the middle position, theoutside rearview mirrors will auto- matically revert to original position.

1FEATURES OF YOUR HYUNDAI
34
It will also lock if you try to lean forward too quickly. Check to make sure thatthe belt is properly locked and that the belt is not twisted. NOTE: If the seat belt is not fastened when the ignition key is turned from the "OFF" position to the "ON" position, the seat belt warning will activate toremind the driver and front passen- ger to fasten the seat belt as follows. B260E01TG-GAT Seat Belt Warning Light
(Except E.C)
The seat belt warning light blinks for about 6 seconds when the ignition keyis turned from the "OFF" position to the "ON". NOTE: You can find the front passenger's seat belt warning light on the center fascia panel.
*1) When the ignition key is turned from "OFF" position to "ON" within 1 minute.
*2) If the vehicle speed exceeds 9km/ h, the seat belt chime also soundsfor about 1~2 minutes.If the vehicle speed is below 9km/h, 1 minute later the seat belt chime also sounds for about 1~2 minutes.
The seat belt warning light and chimewill activate to the following table.
B265E01TG-GAT
Seat Belt Warning Light
and Chime (E.C only)
User (Driver+Front Passenger) Condition Sat Belt WarningLight
Seat Belt Ignition Switch
Unbuckled ON Stay on until buckled up
Buckled ON Come on for 6 seconds
Unbuckled ON * 1
Blink until buckled up
ON Blink until buckled up* 2
Buckled



Unbuckled NOTE:
o You can find the front passenger's
seat belt warning light on the cen- ter fascia panel.
o If the driver's seat belt is operated in this order "unbuckled

buck-
led

unbuckled" within 9 sec-
onds after the seat belt is buckled, the seat belt warning light and chime will not activate.
o Although the front passenger seat is not occupied, the seat belt warn-ing light will illuminate for 6 sec-onds.
o The seat belt warning light can be
operated when luggage is placedon the front passenger seat.

1
FEATURES OF YOUR HYUNDAI
45
!!
AIR
BAG
CAUTION:
o Because the sensor that activates the SRS airbag is connected with pre-tensioner seat belt, the SRS airbag warning light on the instrument panel will illuminatefor approximately 6 seconds af- ter the ignition key has been turned to the "ON" position, andthen it should turn off.
o If pre-tensioner seat belt is not
working properly, this warninglight will illuminate even if there is no malfunction of the SRS airbag. If the SRS airbag warninglight does not illuminate when the ignition key is turned to "ON", or if it blinks for a second andremains illuminated after illumi- nating for approximately 6 sec- onds, or if it illuminates while thevehicle is being driven, please have an authorized Hyundai dealer inspect the pre-tensioner seat beltor SRS airbag system as soon as possible. WARNING:
o Pre-tensioners are designed to operate only one time. After acti- vation, pre-tensioner seat beltsmust be replaced. All seat belts, of any type, should always be replaced after they have beenworn during a collision.
o The pre-tensioner seat belt as-
sembly mechanisms become hotduring activation. Do not touch the pre-tensioner seat belt as- semblies for several minutes af- ter they have been activated.
o Do not attempt to inspect or re-
place the pre-tensioner seat beltsyourself. This must be done by an authorized Hyundai dealer.
o Do not strike the pre-tensioner seat belt assemblies.
o Do not attempt to service or repair the pre-tensioner seat belt system in any manner.
o Improper handling of the pre-tensioner seat belt assemblies, and failure to heed the warnings not tostrike, modify, inspect, replace, service or repair the pre-tensioner seat belt assemblies may lead toimproper operation or inadvertent activation and serious injury.
o Always wear the seat belts when driving or riding in a motor ve-hicle.
