FEATURES OF YOUR HYUNDAI
13THEFT-ALARM SYSTEM
B070A01A-AAT (If Installed) This system is designed to provide protection from unauthorized entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an audible alarm with blinking of the turnsignal lights.
B070B01TG-AAT Armed Stage
B070B01TG1) Remove the ignition key from the
ignition switch.
2) Make sure that the engine hood and trunk lid are closed and latched.
3) Lock the doors using the transmitter
of the keyless entry system.
If the steps are completed as above, the security LED lamp on the passenger’s crash pad will illuminate for about 30 seconds, and then thelamp will blink continuously when the system is entered into the armed stage. The turn signal lights will blink once toindicate that the system is armed. NOTE:
1) If any door, trunk lid or engine hood remains open, the system will not be armed.
2) If this happens, rearm the system
as previously described.
Lock
Unlock
Trunk Unlock
Park the car and stop the engine. Arm the system as described below.
! CAUTION:
Do not arm the system until all pas- sengers have left the car. If the sys- tem is armed while a passenger(s)remains in the car, the alarm may be activated when the remaining passenger(s) leaves the car.
1
FEATURES OF YOUR HYUNDAI
15
B070F01NF-GAT Keyless Entry System (If Installed)Locking doors
1. Close all doors.
2. Push the " " button on the transmitter.
3. At the same time, all doors lock and the turn signal lights will blink once to indicate that the system is armed.
Unlocking doors
1. Push the " " button on the transmitter.
2. At the same time, all doors unlock
and the turn signal lights will blink twice to indicate that the system is disarmed.
Releasing the trunk lid Push the trunk lid release button ( ) on the transmitter for longer than 1 second.
B070E01NF-GAT Replacing the battery When the transmitter's battery begins to get weak, it may take several pusheson the button to lock or unlock the doors, and the LED will not light. Re- place the battery as soon as possible. Battery type : CR2032 Replacement instructions:
1. Separate the case with a coin as shown in the illustration. B070E01TG HTG2006
Battery
2. Remove the old battery from the case and note the polarity. Make sure the polarity of the new battery is the same(+side facing up), theninsert it in the transmitter.
