2005 Hyundai Azera warning

!
SAFETY AND VEHICLE DAMAGE WARNING
This manual includes information titled as WARNING, CAUTION and NOTE. These titles indicate the following:
WARNING:
This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded. Follow the advice provided with the warning.
CAUTION:
This indicates that a condition may result in damage to your vehicle or its equipment if the caution is not heeded. Follow the advice provided with the caution. NOTE: This indicates that interesting or helpful information is being provided.
A090A01A-AAT
!

1. Headlight Leveling Device Switch (If Installed)
2. Rear Fog Light Switch (If Installed)
3. Electronic Stability Program (ESP) Switch(If Installed)
4. Panel Brightness Control Knob (Rheostat Switch)
5. Steering Wheel Tilt & Telescopic Lever
6. Hood Release Lever
7. Cigarette Lighter
CAUTION:
When installing a container of liquid air freshener inside the vehicle, do not place it near the instrument cluster nor on the instrument panel pad surface. If there is any leakage from theair freshener onto these areas (instrument cluster, instrument panel pad or air ventilator), it may damage these parts. If the liquid from air freshener does leak onto these areas, wash them with water immediately.
!
NOTE: Switch arrangements from No. 1 to No. 4 can be changed according to options. 8. Front Ashtray
9. Front Seat Warmer (If Installed)
10. Rear Window Curtain Switch (If Installed)
11. Digital Clock
12. Passenger's Seat Belt Warning Light (If Installed)
13. Hazard Warning Switch
14. Power Outlet

1. Digital Clock
2. Passenger's Seat Belt Warning Light (If Installed)
3. Hazard Warning Switch
4. Electronic Stability Program (ESP) Switch(If Installed)
5. Steering Wheel Tilt & Telescopic Lever
6. Panel Brightness Control Knob (Rheostat Switch)
7. Rear Fog Light Switch (If Installed)
CAUTION:
When installing a container of liquid air freshener inside the vehicle, do not place it near the instrument cluster nor on the instrument panel pad surface. If there is any leakage from the air freshener onto theseareas (instrument cluster, instrument panel pad or air ventilator), it may damage these parts. If the liquid from air freshener does leak onto these areas, wash them with water immediately.
!
NOTE: Switch arrangements from No. 6 to No. 8 can be changed according to options. 8. Headlight Leveling Device Switch (If Installed)
9. Hood Release Lever
10. Front Seat Warmer (If Installed)
11. Front Ashtray
12. Cigarette Lighter
13. Rear Window Curtain Switch (If Installed)
14. Power Outlet

YOUR VEHICLE AT A GLANCE
B255A01TG-GAT INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER
High Beam Indicator Light Door Ajar Warning Light
Seat Belt Warning Light
Turn Signal Indicator LightsPassenger's Front Airbag OFF Indicator Light (If Installed)
ABS Service Reminder Indicator (SRI)
Low Oil Pressure Warning Light Parking Brake/Low Brake Fluid Level Warning Light Charging System Warning Light
SRS (Airbag) Service Reminder Indicator (SRI)
Cruise Indicator Light (If Installed)
Malfunction Indicator Light
Electronic Stability Program Indicator Lights (If Installed)
Low Windshield Washer Fluid Level Warning Light
Front Fog Indicator Light
Cruise SET Indicator Light (If Installed)
* More detailed explanations of these items will be found beginning on page 1-62.Low Fuel Level Warning Light
Trunk Lid Open Warning Light Immobilizer Warning Light (If Installed)

Fuel Recommendations ............................................... 1-2
Breaking In Your New Hyundai .................................... 1-3
Keys .............................................................................. 1-4
Immobilizer System ...................................................... 1-5
Door Locks ................................................................... 1-9Theft-Alarm System ..................................................... 1-13
Windows ...................................................................... 1-16
Seats ........................................................................... 1-20
I.M.S (Integrated Memory System) .............................. 1-26
Seat Belts .................................................................... 1-31
Child Restraint System ................................................ 1-37
Supplemental Restraint (AIRBAG ) System................. 1-46
Instrument Cluster and Indicator Lights .......................1-58
Warning and Indicator Lights....................................... 1-62
Trip Computer .............................................................. 1-73
Multi-function Light Switch ........................................... 1-77
Windshield Wiper/Washer Switch ................................1-80
Sunroof ........................................................................ 1-89
Mirror ........................................................................... 1-96
Hood R elease ............................................................ 1-105
Cruise Co ntrol............................................................ 1-109
Heating and Cooling Control ...................................... 1-113
Stereo Sound System ............................................... 1-133
Audio System ............................................................ 1-136
Antenna ..................................................................... 1-167
FEATURES OF YOUR HYUNDAI
1
1

1FEATURES OF YOUR HYUNDAI
8
B880D01TG-GAT Limp Home Procedures 2. Wait for 3~10 seconds.
3. You may set the remaining number
of digits by following the same pro- cedures 1 and 2.
4. If all of four digits have been tried
successfully, turn the ignition key"ON" and check that the immobi- lizer indicator illuminates. From thistime, you have to start your engine within 30 seconds. If you start your engine after 30 seconds, your en-gine will not start.
NOTE: If the engine dies while driving after limp home procedure, you can startyour engine within 3 seconds with- out limp home procedure again.
5. If the immobilizer indicator blinks for five seconds, you have to try the limp home procedure again fromthe beginning.
After doing the limp home procedure,you have to consult with your autho- rized Hyundai dealer as soon as pos- sible.
HTG3012
In case the immobilizer warning indica-tor blinks for five seconds when theignition key is turned to "ON" position, this indicates that the immobilizer sys- tem is out of order. And you cannotstart the engine without the limp home procedures with ignition key. The following procedure is how to startthe engine with the function of the limp home (0, 1, 2, 3 as a sample pass- word). NOTE: You can get the limp home pass- word when the vehicle is first deliv- ered to you. If you do not have thepassword, consult your authorized Hyundai dealer.
1. To set the password you may turn
the ignition key "ON" and then turn it "OFF" according to the digit num-bers, then the immobilizer indicator will blink along with the operation of the ignition key. For example, turnthe ignition key once for digit num- ber "1", and twice for "2", and so on. However, for the digit number "0",you must turn the ignition key for 10 times.
B880D01TG
Conventional Type
Supervision Type

1
FEATURES OF YOUR HYUNDAI
9
B030C01JM-AAT ILLUMINATED IGNITION SWITCH Whenever either front door is opened, the ignition switch will be illuminatedfor your convenience, provided the ignition switch is not in the "ON" posi- tion.The light will go off approximately 10 seconds after closing the door or when the ignition switch is turned on. B030C01E
CAUTION:
o If you fail to try the limp home procedure with the sequence ofthree times, you have to wait forabout one hour to do the limp home procedure again.
o If you cannot start your engine in
spite of limp home procedure,have your vehicle towed by an authorized Hyundai dealer.
!!
DOOR LOCKS
B040A01NF-GAT
WARNING:
o Unlocked doors can be danger- ous. Before you drive away (es- pecially if there are children inthe car), be sure that all the doors are securely closed and locked so that the doors cannot be inad-vertently opened from the inside. This helps ensure that doors will not be opened accidentally. Also,when combined with the proper use of seat belts, locking the doors will keep occupants frombeing ejected from the car in case of an accident.
o Before opening the door, always
look for and avoid oncoming traffic.
o In case of accident, the door is
unlocked automatically (If In- stalled).
o Do not lock the door using the key
or the transmitter until all passen-gers have left the car because the door is not unlocked by the door lock switch when locking the doorusing the key or the transmitter (If Installed).

1FEATURES OF YOUR HYUNDAI
10
!
B040B01TG-AAT Locking and Unlocking Front Doors With a Key
o The door can be locked or unlocked
with a key.
o Lock the door by turning the key toward the front of the vehicle and unlock it by turning the key toward the rear. B040C02Y-AAT Locking from the Outside The doors can be locked without a key. To lock the doors from the outside, first push the inside lock switch to the"LOCK" position, so that the red mark on the switch is not visible, then close the door.The door will not lock if the key is left in the ignition switch when the front doors are closed. This is normal.
HTG2008 B040C01TG
LOCK UNLOCK
Leaving children, helpless adults,or pets in an enclosed vehicle isdangerous. They can be overcome by the extreme heat and suffer permanent injuries or even deathfrom heat stroke.
WARNING:
Do not lock the door using the key or the transmitter until all passengers have left the car because the door isnot unlocked by the door lock switch when locking the door using the key or the transmitter (If Installed). Leav-ing children, helpless adults, or pets in an enclosed vehicle is dangerous. They can be overcome by the ex-treme heat and suffer permanent in- juries or even death from heat stroke.
