2005 Hyundai Azera warning

1
FEATURES OF YOUR HYUNDAI
11
NOTE:
o When locking the door this way, be careful not to lock the door with the ignition key left in thevehicle.
o To discourage theft, always re-
move the ignition key, close allwindows and lock all doors when leaving your vehicle unattended.
B040D01NF-AAT Locking from the Inside To lock the doors from the inside, sim- ply close the door and push the lock switch to the "LOCK" position. NOTE:
o When the door is locked, the redmark on the switch is not visible.
o The driver's and front passenger's doors can be opened by pulling the inside door handle even if theinside lock switch is pushed to the "LOCK" position. HTG2009
LOCK
UNLOCK
WARNING:
Be careful not to pull the inside door handle while driving. If you pull the inside door handle, the door can beopened and you may be ejected from the vehicle and can be injured or killed.!

1FEATURES OF YOUR HYUNDAI
12
!
Your Hyundai is equipped with a "child- protector" rear door lock assembly. When the lock mechanism is engaged,the rear door cannot be opened from the inside. Its use is recommended whenever there are small children inthe rear seat. To engage the child-protector feature so that the door cannot be opened from the inside, move the child-protec- tor lever to the "
" position and close
the door. Move the lever to the "
"
position when normal door operation is desired. If you wish to be able to open the door from the outside, the outside door handlewill function normally.
B040E04A-AAT Child-Protector Rear Door Lock
HTG2011-1
o The driver's and front passenger's
doors can be opened by pulling the inside door handle even if the front portion of the driver's or front passenger's central door lockingswitch has been depressed to lock the doors.
WARNING:
Be careful not to pull the inside door handle while driving. If you pull the inside door handle, the door can be opened and you may be ejected fromthe vehicle and can be injured or killed.B040G01NF-AAT Central Door Locks
The central door locking switch is lo- cated on the driver's and front passenger's armrest. It is operated bydepressing the door lock switch. If any door is open when the switch is de- pressed to the "LOCK" position, thedoor will remain locked when closed. NOTE:
o When pushing the front portion of the driver's or front passenger's door lock switch, all vehicle doors will lock.
o When pushing the rear portion of these switches, all vehicle doorswill unlock. B040G01TG
Driver's side
Front passenger's side
LOCK
UNLOCKLOCK
UNLOCK

1
FEATURES OF YOUR HYUNDAI
19
!WARNING:
o Be careful that someone's head, hands and body are not trapped by a closing window.
o Never try to operate the main switch on the driver's door andthe individual door windowswitch in opposing directions at the same time. If this is done, the window will stop and cannot beopened or closed.
o Do not leave children alone in the
car. Always remove the ignition key for their safety. B060D01TG-GAT Closing and Opening the Win- dows with a Key The driver’s and passenger’s windows can be closed or opened with a key inthe driver’s door.
To close the windows, turn the key toward the front of the vehicle for 3 seconds. If the key is turned toward the rear of thevehicle while closing the window, the window will stop upward movement.
HTG2201
To open the windows, turn the key toward the rear of the vehicle for 3 seconds. If the key is turned toward the front of the vehicle while opening the window, the window will stop downward move-ment.
HTG2200
!WARNING:
Be careful that someone’s head, hands and body are not trapped by a closing window.

1
FEATURES OF YOUR HYUNDAI
21
!
!
SEATS
B080A01A-AAT
ADJUSTABLE FRONT SEATS
WARNING:
Never attempt to adjust the seat while the vehicle is moving. This could result in loss of control, or an accident which may cause death,serious injury, or property damage. B080B02A-AAT Adjusting Seat Forward and Rearward To move the seat toward the front or rear, pull the lock release lever up-ward. This will release the seat on its track so you can move it forward or rearward to the desired position. Whenyou find the position you want, release the lever and slide the seat forward or rearward on its track until it locks intothe desired position and cannot be moved further.HTG2033
B080C01A-AAT Adjusting Seatback Angle To recline the seatback, lean forward to take your weight off it, then pull up on the recliner control lever at the outsideedge of the seat. Now lean back until the desired seatback angle is achieved.
HTG2034
WARNING:
To ensure the seat is locked se-curely, attempt to move the seat forward or rearward without usingthe lock release lever.

1FEATURES OF YOUR HYUNDAI
22
!
!
WARNING:
WARNING:
To minimize risk of severe injury in the event of a collision or a suddenstop, both the driver and passen- ger seatbacks should always be in an upright position while the ve-hicle is in motion. The protection provided by the seat belts and airbags may be reduced signifi-cantly when the seatbacks are re- clined. There is greater risk that the driver and passenger will slide un-der the seat belt which may result in serious injury if a crash occurs when the seatbacks are reclined.The seat belt cannot provide full protection to an occupant if the seatback is reclined. B080D02JM-AAT Adjustable Headrests
Headrests are designed to help reduce the risk of neck injuries. To raise the headrest, pull it up. Tolower it, push it down while pressing the lock knob. To remove the head- rest, raise it as far as it can go thenpress the lock knob while pulling up-
ward. This should only be done when the seat is not occupied. B080D02TG
To lock the seatback into position,release the recliner control lever.
B080D01TGo For maximum effectiveness in caseof an accident the headrest shouldbe adjusted so the middle of the headrest is at the same height as the top of the occupant's eyes. Forthis reason, the use of a cushion that holds the body away from the seatback should not be recom-mended.
o Do not operate vehicle with the
headrests removed as injury tothe occupants may occur in the event of an accident. Headrests may provide protection against
Lock knob

1FEATURES OF YOUR HYUNDAI
24
!
B090B01NF-GAT Adjusting Seat Forward and Rearward Pull the control knob forward or back- ward to move the seat forward or back-ward to the desired position. Release the control knob and the seat will re- main at that position. HTG2037B080F01NF-GAT Seat Cushion Height Adjustment (Driver's Seat Only) (If Installed) To raise or lower the seat, raise or lower the control lever to the desired seatheight.
HTG2035B090A01TG-AAT FRONT POWER SEATS (If Installed) The front seats can be adjusted appro- priately by using the control knob of theseat. Before driving, adjust the seat to the proper position so as to easily control the steering wheel, pedals andswitches on the instrument panel.
CAUTION:
Do not operate two knobs at thesame time.
WARNING:
o Never attempt to adjust the seat while the vehicle is moving. Thiscould result in loss of control, or an accident causing death, seri- ous injury, or property damage.
o Do not sit or lean unnecessarily close to the airbag.
!

1
FEATURES OF YOUR HYUNDAI
25
!
B090D01NF-GAT Adjusting Seatback Angle Pull the upper portion of the control knob forward or backward to recline the seatback to the desired position.Release the control knob and the seatback will remain in that position. HTG2040WARNING:
To minimize the risk of personalinjury in the event of a collision or a sudden stop, both the driver'sand passenger's seatback should remain in an upright position while the car is in motion. The protectionprovided by the seat belts and airbags may be reduced signifi- cantly when the seatbacks are re-clined. There is a greater risk that the seat occupants will slide under the belt resulting in serious injuryif a crash occurs when the seatbacks are reclined. The seat belt cannot provide full protection to an occu-pant if the seatback is reclined.B090C01Y-AAT Seat Cushion Height Adjustment (Driver's seat only) Move the front portion of the control knob up or down to raise or lower the front part of the seat cushion. Move therear portion of the control knob up or down to raise or lower the rear part of the seat cushion. HTG2041

1FEATURES OF YOUR HYUNDAI
28
!
NOTE:
o The seat warmer may not operate
if ambient temperature is warm enough.
o If the seat warmer doesn't work when the ambient temperature islower than 24°C, it must bechecked at an authorized dealer.
WARNING:
Be very careful not to injure by lowtemperature burn or an attack offever as following occupants; infants, children, old man, drunken man, people who is taken sleeping drug orcold remedy.B100A01TG-GAT SEAT WARMER (If Installed) The front seats can be electrically heated individually when the ignition switch is ON. When the switch is ON, anumber ranging from 1 to 5 is displayed on the switch (5 = warmest setting). To turn off the seat warmer, set theswitch to 0. B100A01TG
L
: When the remote control outside
rearview mirror switch knob is se-lected to the "L" position, both ofthe outside rearview mirrors will move downward.
R : When the remote control outside
rearview mirror switch knob is se-lected to the "R" position, only thepassenger's outside rearview mir- ror will move downward.
Neutral :When the remote control out-
side rearview mirror switchknob is placed in the middle position, the outside rearviewmirrors will not operate while the vehicle is moving back- ward.
NOTE: When the ignition key is in the "LOCK" position, the shift lever is moved to any position except "R"position, or the remote control out- side rearview mirror switch knob is placed in the middle position, theoutside rearview mirrors will auto- matically revert to original position.
