2005 DODGE STRATUS COUPE Owners Manual

Foot/face position
Air flows to the upper part of the passenger compart-
ment and flows to the leg area.
NOTE: Air flows mostly to the upper part of the pas-
senger compartment with the dial within position (1),
and flows mostly to the leg area with the dial within
position (2).
H13D0553
FOR PLEASANT DRIVING 241
6

Foot position
Air flows mainly to the leg area.
Foot/defroster position
Air flows to the leg area, windshield, and door windows.
H13D0563H13D0573
242 FOR PLEASANT DRIVING

NOTE: Air flows mostly to the leg area with the dial
within position (1), and flows mostly to the windshield
with the dial within position (2).Defroster position
Air flows exclusively to the windshield and door win-
dows.
H13D0583
FOR PLEASANT DRIVING 243
6

NOTE: When the mode selection dial is set to the ªº
or ª
º position, the air conditioning compressor will
operate automatically. The outside air position will also
be selected automatically. (In this case, the air condition-
ing indicator will not change.) This is done for optimum
performance.
Changing air selection
Normally use the ªoutsideº position to keep the wind-
shield and side windows clear and, also to quicklyremove fog or frost from the windshield.
When air conditioning is selected, the air selection will be
controlled automatically for optimum performance.
When the air conditioning is turned off, the air selection
will be set to the outside position.
The air selection indicator will show the selected posi-
tion.
If desired, you can change the air selection. Every time
the air selection switch is pushed, the mode for ªoutsideº
(Indicator OFF) and ªrecirculationº (Indicator ON) will
alternate.
If high cooling performance is desired, or if the outside
air is dusty or otherwise contaminated, use the ªrecircu-
lationº position. Although, switch to the outside position
periodically to prevent window fog up.
CAUTION!
Using the ªrecirculationº position for extended time
periods causes the windows to fog up.H23A2880
244 FOR PLEASANT DRIVING

Air conditioning switch
The air conditioning can be operated while the engine is
running.
Push the switch, and the air conditioning (cooling/
dehumidifying function) will operate. When ªONº, the
operation indicator lamp (A) will illuminate.
Push the switch again and the air conditioning will stop.
CAUTION!
When using the air conditioning, the idle speed is
slightly increased. Therefore, make sure your foot is
firmly on the brake pedal when shifting the trans-
mission to drive.
For the 3.0 liter engine model, if the air conditioning
indicator (A) blinks, it is suspected that something is
wrong with the air conditioning. Move the vehicle to
a safe place and stop the engine. Then run the engine
again and see the air conditioning indicator (A). If
the indicator goes out, there is nothing wrong with
the air conditioning. If it blinks again, have the
system checked by the authorized dealer.
H23A3260
FOR PLEASANT DRIVING 245
6

How to use the controls
Heating
Set the mode selection dial to the position shown in the
illustration and set the air selection switch (A) to the
ªoutsideº position.
Adjust the temperature by turning the temperature con-
trol dial clockwise. Select the desired blower speed.
NOTE: When maximum heating is needed, set the
blower speed to the fourth position.
Defrosting or defogging of the windshield and
door windows
CAUTION!
For safety, make sure you have a clear view through
all windows before driving.
To remove frost or fog from the windshield and door
windows, use the mode selection dial (ª
ºorªº).
H03B0710
H03H0320
246 FOR PLEASANT DRIVING

To keep the windshield and door windows defogged,
and to keep leg area heated (when driving in rain or
snow).
1. Set the mode selection dial to the
position.
2. Adjust the blower to the desired speed.
3. Set the desired temperature.
For quick defrosting
1. Set the mode selection dial to the
position.
2. Adjust the blower to the maximum blower speed.
3. Adjust the temperature control to the maximum tem-
perature.
NOTE
1. When the mode selection dial is set to the ªº
or ª
º position, the air conditioning compressor will
operate automatically. The outside air position will also
be selected automatically. (In this case, the air condition-
ing indicator will not change.)
2. While in ª
ºorªº position, you cannot turn the
air conditioning off or select the recirculation position.
This ensures that the windows will not fog up.
3. To defog effectively, direct the air flow from the side
vents toward the door windows.
4. When defrosting, do not set the temperature control
dial around the max. cool position. Cool air will blow
against the window glass and fog it up.
H03D1500
FOR PLEASANT DRIVING 247
6

Combination of unheated air and heated air
Set the mode selection dial to the position shown in the
illustration and set the air selection switch (A) to the
outside position.
The air will be directed to the leg area and the upper part
of the passenger compartment. Select the desired blower
speed.
Warm air flows to the leg area and unheated or slightly
warm air flows to the upper part of the passenger
compartment.
Cooling
Set the mode selection dial to the ªº position shown in
the illustration.
Set the air selection switch (A) to the outside position and
push the air conditioning switch (B).
1. Setting for ordinary cooling
2. Setting for cooling the leg area
H03C0680H04F0970
248 FOR PLEASANT DRIVING
