106 INSTRUMENTS AND CONTROLS

NCanadian Programming/Gate Programming . . . 137
NOperation...........................138NReprogramming a Signal Button...........139
INSTRUMENTS AND CONTROLS 107
4

INSTRUMENT CLUSTER
Meter cluster
1. Fuel gauge
2. Tachometer
3. Speedometer
4. Engine coolant temperature gauge
5. Odometer6. Trip odometer
7. Trip odometer reset button
D01A2700
108 INSTRUMENTS AND CONTROLS

Indicator and warning light package
1. Washer fluid level indicator!P. 121
2. Anti-lock braking system warning light
(if so equipped)!P. 1 1 5
3. Low-fuel warning light!P. 1 1 5
4. Brake warning light!P. 1 1 95. Supplemental Restraint System (SRS) - air bag
warning light!P. 1 1 8
6. Seat belt reminder/warning light!P. 120
7. Turn signal indicators/hazard warning light!P. 1 1 4
8. Trunk-ajar warning light!P115
9. Front fog light indicator!P. 1 1 6
10. Door-ajar warning light!P. 1 1 4
D50A439D
INSTRUMENTS AND CONTROLS 109
4

11. High beam indicator!P. 1 1 4
12. Cruise control indicator!P. 1 1 5
13. Theft-alarm indicator!P. 1 1 4
14. Malfunction indicator light
(SERVICE ENGINE SOON)!P. 1 1 7
15. Oil pressure warning light!P. 1 1 6
16. Charging system warning light!P. 1 1 6
17. Overheating warning light!P. 1 1 8
18. Traction control system warning light
(if so equipped)!P. 121
19. Automatic transaxle indicator
(Vehicles with Autostick automatic transaxle-if so
equipped)!P. 121
Speedometer
The speedometer indicates vehicle speed.
·The outer scale indicates miles per hour.
·The inner scale indicates kilometers per hour.
Tachometer
The tachometer indicates engine revolutions per minute.
This allows the driver to determine the most efficient
gear range and engine speed combinations.
D04A0500
2.4 liter
engine3.0 liter
engine
110 INSTRUMENTS AND CONTROLS

CAUTION!
The red zone indicates an engine speed in excess of
safe operation.
Select the correct gear to control engine speed so the
tachometer indicator does not enter the red zone.
Fuel gauge
The gauge shows the amount of fuel in the fuel tank
when the ignition key is turned to the ``on'' position.
The arrow A indicates that the fuel lid (fuel filler port) is
located on the right side of the vehicle. (Refer to ªFuel
fillerº on page 39.)
NOTE: Just after refueling, it takes a little time until the
correct fuel level is indicated after turning on the ignition
switch.
D05A0770
INSTRUMENTS AND CONTROLS 111
4

Odometer/Trip odometer
When the ignition switch is turned to the ªONº position,
an ªODOº or ªTRIPº indication is given.
Every time the reset button (3) is pressed lightly (less
than one second), the indicators will change from ªODOº
to ªTrip Aº to ªTrip Bº.
1. Odometer
2. Trip odometer
3. Reset buttonODO --- Odometer
The odometer indicates the total distance the vehicle has
travelled.
TRIP --- Trip odometer
The trip odometer indicates the distance traveled during
a particular trip or period.
As a feature, there are two trip odometer displays:
and.
Trip
can be used to measure the distance traveled
D03F0320
D03F0120
