To listen to a tape
To operate the APS (Automatic Program Sensor)
system
The start of each song on a prerecorded music tape can be
found by using the Fast forward APS button (1) or
Rewind APS button (5). As many as 7 programs can be
skipped over in this manner.
Fast forward APS operation:
Press the APS button (1) to the number of songs you
desire to skip over. The frequency-display window will
display the number songs selected. The tape will be
fast-forwarded to the start of the song, and playback will
begin.
Rewind APS operation:
Press the APS button (5) to the number of the selection
you desire to skip over including the one now being
played. The frequency-display window will display the
number of songs selected. The tape will be rewind to the
start of the song, and playback will begin.
To listen to a CD
To select CD mode
Mode change button - 4
Select the desired mode (CD player mode or CD au-
tochanger mode) by pressing this button.
To select a desired track
Track up button - 1
Press this button until the desired track is reached.
Track down button - 5
Press this button until the desired track is reached.
The frequency display window will display the number
of tracks selected.
To select a desired disc (CD autochanger only)
Disc up button - 3
Press this button until the desired disc is reached.
FOR PLEASANT DRIVING 233
6

Handling of Compact Discs
(1) Use only the type of compact discs that have the mark
shown in the illustration above. (Playback of CD-R
discs may cause problems. CD-RW discs cannot be
played.)
(2) The use of special shaped, damaged compact discs
(like cracked discs) or low-quality compact discs (like
warped discs or burrs on the discs) such as those
shown below will damage the CD player.
H12F0180
H12F0172
234 FOR PLEASANT DRIVING

(3) In the following circumstances, moisture can form on
compact discs and inside the audio system, prevent-
ing normal operation.
²When there is high humidity (for example, when it
is raining).
²When the temperature suddenly rises, such as right
after the heater is turned on in cold weather.
In this case, wait until the moisture has had time to
dry out.
(4) When the CD player is subjected to violent vibra-
tions, such as during off-road driving, the tracking
may not work.
(5) When storing compact discs, always store them in
their separate cases. Never place compact discs in
direct sunlight, or in any place where the temperature
or humidity is high.(6) Never touch the flat surface of the disc where there
isn't a label. This will damage the disc surface and
could affect the sound quality. When handling a
compact disc, always hold it by the outer edge and
the center hole.
(7) To clean a disc, use a soft, clean, dry cloth. Wipe
directly from the center hole toward the outer edge.H12F090
FOR PLEASANT DRIVING 235
6

Do not wipe in a circle. Never use any chemicals such
as benzine, paint thinner, a disc spray cleaner, or an
anti-static agent on the disc.
(8) Do not use a ball point pen, felt pen, pencil, etc. to
write on the label surface of the disc.
(9) Do not put additional labels (A) or stickers (B) on
compact discs. Also, do not use any compact disc on
which a label or sticker has started to peel off or anycompact disc that has stickiness or other contamina-
tion left by a peeled-off label or sticker. If you use
such a compact disc, the CD player may stop working
properly and you may not be able to eject the
compact disc.
CD player laser warning
WARNING!
Operating the CD player in a manner other than
specifically instructed herein may result in hazard-
ous radiation exposure.
Do not remove the cover and attempt to repair the
CD player by yourself. There are no user serviceable
parts inside. In case of malfunction, contact an
authorized dealer.
RADIO OPERATION AND CELLULAR PHONES
Under certain conditions, the operation of a cellular
phone in your vehicle can cause erratic or noisy perfor-
mance from your radio. This condition may be lessened
or eliminated by relocating the cellular phone antenna.
H12F0160
236 FOR PLEASANT DRIVING

This condition is not harmful to the radio. If your radio
performance does not satisfactorily ªclearº by the repo-
sitioning of the antenna, it is recommended that the radio
volume be turned down or off during cellular phone
operation.
VENTS
1. Center vents
2. Side vents
Air flow rate and direction adjustments
Center and side vents
H16A3610
H16A3660
FOR PLEASANT DRIVING 237
6

Change the direction of the airflow from side to side by
moving the knob (A). Change the vertical direction of the
air flow up and down by pushing the top button edge of
the vents.
NOTE: On rare occasions, air from the vents of an
air-conditioned vehicle may look like fog. This is moist
air suddenly cooled and there is no abnormality in the air
conditioning system.
AIR CONDITIONING
Control panel
1. Blower switch
2. Air conditioning switch
3. Temperature control dial
4. Mode selection dial
5. Air selection switch
H23A2840
238 FOR PLEASANT DRIVING

Changing the blower speed
The blower may be operated (when the ignition key is in
the ON position) at 4 different speeds. Select the best
speed to fit your needs. When the blower switch is set to
the ``O'' position, all air conditioning functions will stop.
Changing the temperature
Select the desired temperature level by turning the tem-
perature control dial either clockwise or counterclock-
wise. Turning the temperature control dial clockwise
makes the air warmer.
NOTE: When the engine coolant temperature is low, the
temperature of air introduced into the passenger com-
partment does not change even if the temperature control
dial is moved to the high temperature side.
H23A2860H23A2870
FOR PLEASANT DRIVING 239
6

Changing mode selection
To change air flow to the different outlets, turn the mode
selection dial to the desired position.
Face position
Air flows exclusively to the upper part of the passenger
compartment.
H03I0670
H13D0543
