2005 DODGE STRATUS COUPE Owners Manual

The intermittent intervals are adjustable from approxi-
mately 3 to 18 seconds by rotating the adjusting knob at
the end of the stalk.
LO = Slow
HI = Fast
INTERMITTENT WIPERS
Use the intermittent feature when weather conditions
make a single wiping cycle, with a pause between cycles,
desirable.For maximum delay between wipes, rotate the knob
toward you. To shorten the delay, rotate the knob away
from you.
The delay can be regulated between approximately 3 and
18 seconds.
NOTE:Vehicle speed is monitored and the delay will be
shortened when the vehicle is moving above 10 mph (16
km/h) and lengthened when the vehicle is moving below
10 mph (16 km/h).
E13A1510
Adjusting knob
FAST
SLOW
INSTRUMENTS AND CONTROLS 129
4

WINDSHIELD WASHER
The windshield washer can be operated by pulling the
lever toward you to spray fluid when the ignition key is
in either the ªONº or ªACCº position.
When washer fluid is sprayed, the wipers will automati-
cally operate several times.
The spraying fluid stops when the lever is released.
PRECAUTIONS TO OBSERVE WHEN USING
WIPERS AND WASHERS
CAUTION!
If the washer is used in cold weather, the washer
fluid sprayed onto the glass might freeze, resulting
in poor visibility. Heat the glass with the defroster
before using the washer.
NOTE
1. Do not use the wipers when the glass is dry; this could
scratch the glass and wear the wiper blades prematurely.
2. Before operating the wipers in cold weather, check to
be sure that the wiper blades are not frozen to the
windshield. Attempting to operate the wipers while the
blades are frozen could damage the wiper motor.
3. If the wipers become blocked by ice or other deposits
on the glass, the motor may be damaged even if the
wiper switch is OFF. If obstruction occurs, park your
E13A1300
130 INSTRUMENTS AND CONTROLS

vehicle in a safe place, turn off the ignition, and clean the
deposits from the glass so that the wipers operate
smoothly.
4. Avoid using the washer for more than 20 seconds at a
time. To avoid pump damage, do not operate the washer
when the fluid reservoir is empty.
5. During cold weather, be sure to add a washer solution
that will not freeze in the washer reservoir. Failure to do
so could result in the loss of windshield washer function
and damage to the system components.
6. Replace wiper blades when they are worn to avoid
loss of visibility when in use. Use the appropriate size
replacement blades; if you have questions, ask your
authorized dealer.DOME LIGHT
The dome/reading light can be operated by moving the
switch as follows:
1. (ON) - The dome light ``ON''.
2. (DOOR) - The dome light goes on when any door is
opened.
3. (OFF) - The dome light stays ``OFF''.
E19A0970
Type 1
INSTRUMENTS AND CONTROLS 131
4

Push the light switch (A) to turn on the light, and push
the light switch again to turn them off.
LIGHTS (DOME LIGHTS, ETC.) AUTO-CUTOUT
FUNCTION
If any of the interior lights is left on with the ignition key
in the ``LOCK'' position, the light goes off automatically
after approximately 30 minutes to prevent the battery
from running down.
The light comes on again if the ignition key is turned to
the9ON9or9ACC9position (except ``Dome Light'' Type
2), or ``ON'' position (``Dome light'' Type 2 only), any
door is opened and closed, or the keyless entry system is
operated.
G08C0070
132 INSTRUMENTS AND CONTROLS

READING LIGHTS
1. Driver 's side
2. Passenger 's side
Push the right or left reading light switch (lens) to turn on
the light.
This light produces a spot beam for convenient use as a
map light at night.
Push the reading light switch again to turn the light off.
NOTE:
²If the reading lights are left on for prolonged periods of
time with the engine turned off, the battery will be
discharged (run down).G08C0070
E19A1280
INSTRUMENTS AND CONTROLS 133
4

REAR PERSONAL LIGHTS
ON - The light illuminates
OFF - The light illuminates when a door is opened and
goes out when it is closed.
HORN SWITCH
Pressing on or around themark on the steering wheel,
causes the horn to honk.
GARAGE DOOR OPENER (IF SO EQUIPPED)
The HomeLinkyUniversal Transceiver replaces up to
three remote controls that operate devices such as garage
door openers, motorized gates, or home lighting. It
triggers these devices at the push of a button, located on
your Electrochromic inside rearview mirror (if so
E19A1270E23A0020T
134 INSTRUMENTS AND CONTROLS

equipped). The transmitter operates off your vehicle's
battery and charging system; no batteries are needed.
For additional information on HomeLinky, call toll-free
for customer assistance at 1±800±355±3515, or on the
internet at www.homelink.com.
WARNING!
²A moving garage door can cause injury to people
and pets in the path of the door. People or pets
could be seriously or fatally injured. Only use this
transceiver with a garage door opener that has a
ªstop and reverseº feature as required by federal
safety standards. This includes most garage door
opener models manufactured before April 1, 1982.
Do not use a garage door opener without these
safety stop and reverse features it could cause
injury or death. Call toll-free for customer assis-
tance at 1±800±355±3515, or on the internet at
www.homelink.jci.com for safety information or
assistance.
Training The Universal Transceiver
For best results, install a new battery in the hand held
transmitter before programming. If your garage door
opener (located in the garage) is equipped with an
antenna, make sure that the antenna is hanging straight
down.
1. Turn off the engine.
WARNING!
²Vehicle exhaust contains carbon monoxide, a dan-
gerous gas. Do not run the vehicle's exhaust while
training the transceiver. Exhaust gas can cause
serious injury or death.
²Your motorized door or gate will open and close
while you are training the universal transceiver.
Do not train the transceiver if people or pets are in
the path of the door or gate. A moving door or gate
can cause serious injury or death to people and
pets or damage to objects.
2. Erase the factory test codes by pressing the two
outside buttons (A and B) on the universal transceiver.
INSTRUMENTS AND CONTROLS 135
4

Release the buttons when the light in the indicator (D)
begins to flash after 20 seconds.
A - Universal Transceiver button 1
B - Universal Transceiver button 2
C - Universal Transceiver button 3
D - Indicator light
NOTE:
²Step 2 does not have to be followed to program
additional hand held transmitters (E).3. Choose one of the three buttons to train. Place the
hand held transmitter 1 to 3 inches from the universal
transceiver while keeping its indicator light in view.
4. Using both hands, press the hand held transmitter
button and the desired universal transceiver button. Do
not release the buttons until step 5 has been completed.
F21A0100
F21A0110
136 INSTRUMENTS AND CONTROLS
