2004 YAMAHA TT600RE Service Manual

2-20
SPECLUBRlCATlON POINTS AND LUBRICANT TYPE
LUBRlCATlON POINTS AND LUBRICANT TYPES
ENGINE
Lubrication points (part name) Lubricant type
Oil seal edges (completely)
Bearing retainer
Rod pins
Rod (big end)
Piston and piston rings
Hub (weight drive sprocket)
Piston pin
Valve stim and guide
Oil seal (valve stim end)
Rocker shaft and rocker arm
Cam and bearing (camshaft)
Rotor and rotor housing (oil pump)
Push rod (clutch)
Primary driven gear and main shaft
Sliding gear (transmission)
Idle gear (transmission)
Shift forks and bar
Shift cam and bearing (gearshift cam)
Shift shaft
Rod housing coupled surfaces Bonding agent (rapid seal adhesive)®
Yamaha bond No. 1215®
Coupled surfaces (cylinder head and cylinder head cover) Bonding agent (rapid seal adhesive)®
Yamaha bond No. 1215®
ProCarManuals.com

2-21
SPECLUBRlCATlON POINTS AND LUBRICANT TYPE
CHASSIS
Lubrication points (part name) Lubricant type
Gear unit (tachometer)
Oil seal edges (completely)
Wheel axle (front and rear wheels)
Rear wheel hub and clutch
Bearings brasses (rear arm) and bearing push cover
Front footrest
Pivot points (brake pedal and shift pedal)
Bearings (steering head)
Pivot points (brake lever and clutch lever)
Clutch cable end
Pivot points (sidestand)
Grease nipples (rear arm-front axle)
ProCarManuals.com

2-22
SPECLUBRICATION LAYOUT
LUBRICATION LAYOUT
(1) Oil tank
(2) Oil pump
(3) Oil filter (oil tank)
(4) Oil strainer (engine)
(5) Oil vapour retrieval hose
(6) Oil blow-by retrieval hose[A] DELIVERY
[B] RETRIEVAL
ProCarManuals.com

SPECLUBRICATION LAYOUT
2-23
(1) Oil pump
(2) Oil filter
(3) Camshaft
(4) Oil delivery hose
(5) Main driving shaft
(6) Drive shaft[A] DELIVERY
[B] RETRIEVAL
A
B
ProCarManuals.com

SPECLUBRICATION LAYOUT
2-24
(1) Oil filter
(2) Camshaft
(3) Connecting rod pin
(4) Main driving shaft
(5) Secondary drive shaft
(6) Drain plug[A] DELIVERY
[B] RETRIEVAL
A
B
ProCarManuals.com

SPECLUBRICATION LAYOUT
2-25
(1) Oil pump
(2) Oil filter
(3) Oil delivery hose
(4) Transmission
(5) Oil strainer[A] DELIVERY
[B] RETRIEVAL
A
B
ProCarManuals.com

SPECCABLE ROUTING
2-26

































CABLE ROUTING
(1) Clutch cable
(2) Brake hose holder
(3) Brake hose
(4) Throttle cables
(5) Bands
(6) Lighting wire
harness
(7) Brake and engine
stop switch wire
harness(8) Tachometer/
odometer cable
(9) Complete wire
harness
(10) Socket cover
(11) Engine stop switch
connector
(12) Headlight wire
harness connector
(13) Left turn light
connector(14) Right turn light
connector
(15) Meter wire harness
connector
(16) Main switch wire
harness connector
(17) Clutch switch
(18) Headlight connector
(19) Side/taillight
connector(20) Clutch switch
connector
(21) Brake switch
connector
(22) Clip
[A] Lay the brake hose
throught the holder
on the handle
crown.
ProCarManuals.com

SPECCABLE ROUTING
2-27









































(1) Front brake hose
(2) Brake hose holder
(3) Left tube guard
(4) Plastic plate
(5) Throttle cables
(6) Tachometer/
odometer cable
(7) Clutch cable
(8) Clutch cable holder
(9) Throttle cables
holder
(10) Wire harness band(11) Fuel pipe from fuel
cock
(12) Flasher relay
(13) Main relay
(14) Sidestand switch
(15) Diodes (n. 3)
(16) A.C. generator wire
harness (engine)
(17) Engine oil breather
pipe (to engine oil
tank)
(18) Main switch(19) Oil hose (oil tank to
engine)
(20) Oil hose (engine to
oil tank)
(21) C.D.I. unit
(22) Starting motor plus
cable
(23) Starting motor
minus cable
(24) Battery
(25) Starting relay
(26) Fuse (reserve)
(27) Fuse (main)(28) Wire extension
(29) Battery plus cable
[A] Lay the brake hose
behind the left tube
guard and fasten it
down by means of
the plate 4.
[B] Attach throttle
cables 5.
[C] Fasten the fuel pipe
11 to the tank.
[D] Fit the 3 diodes
inside the chassis,
against the coil clip.
