FU(H4DOTC)-54
FUEL INJECTION (FUEL SYSTEM)
Fuel
24.Fuel
A: OPERATION
1. RELEASING OF FUEL PRESSURE
WARNING:
 Place “NO FIRE” signs near working area.
 Be careful not to spill fuel on floor.
1) Disconnect the connector from fuel pump relay.
2) Start and run the engine until it stalls.
3) After the engine stalls, crank it for 5 more sec-
onds.
4) Turn the ignition switch to OFF.
2. DRAINING FUEL
WARNING:
 Place “NO FIRE” signs near working area.
 Be careful not to spill fuel on floor.
1) Set the vehicle on a lift.
2) Disconnect the ground cable from battery.
3) Open the fuel filler flap lid and remove the fuel
filler cap.
4) Lift-up the vehicle.5) Drain fuel from the fuel tank.
Set a container under vehicle and remove the drain
plug from fuel tank.
6) Tighten the fuel drain plug.
Tightening torque:
26 N
⋅m (2.7 kgf-m, 19.2 ft-lb)
FU-00262
FU-00009
FU-00089
FU-00089

FUJI HEAVY INDUSTRIES LTD. G8080GE3
