Camshaft
3) Camshaft oil seal installation: Apply grease to
new oil seal lips and press onto front end of cam-
shaft by using ST1 and ST2.
NOTE:
Use a new oil seal.
ST1 499587600 OIL SEAL INSTALLER
ST2 499597200 OIL SEAL GUIDE
4) Rocker cover installation:
(1) Install the gasket on rocker cover. Install the
peripheral gasket and ignition coil gasket.
(2) Apply liquid gasket to four front open edges
of peripheral gasket.
Liquid gasket:
Part No. 004403007
THREE BOND 1215 or equivalent
 2.0 L MODEL 2.5 L MODEL
(3) Install the rocker cover on cylinder head.
Ensure the gasket is properly positioned during
installation.
(4) Tighten the rocker cover tightening bolt in al-
phabetical sequence shown in the figure, and
then tighten to specified torque.
Tightening torque:
6.4 N
⋅m (0.65 kgf-m, 4.7 ft-lb)
ME-00116
ST1
ST2
ME-00759
RH
LH
ME-00776
ME-00777
(E)
(F)(H)
(G)
(D),(L) (A),(I)(C),(K)
(B),(J)
