2004 SUBARU FORESTER sensor

ME(H4SO)-15
MECHANICAL
General Description
C: CAUTION
 Wear working clothing, including a cap, protec-
tive goggles and protective shoes during operation.
 Remove contamination including dirt and corro-
sion before removal, installation or disassembly.
 Keep the disassembled parts in order and pro-
tect them from dust or dirt.
 Before removal, installation or disassembly, be
sure to clarify the failure. Avoid unnecessary re-
moval, installation, disassembly and replacement.
 Be careful not to burn yourself, because each
part in the vehicle is hot after running.
 Be sure to tighten bolts and nuts to the specified
torque.
 Place shop jacks or rigid racks at the specified
points.
 Before disconnecting electrical connectors of
sensors or units, be sure to disconnect the ground
cable from battery.
 All parts should be thoroughly cleaned, paying
special attention to the engine oil passages, pis-
tons and bearings. Rotating parts and sliding parts such as piston,
bearing and gear should be coated with oil prior to
assembly.
 Be careful not to let oil, grease or coolant contact
the timing belt, clutch disc and flywheel.
 All removed parts, if to be reused, should be re-
installed in the original positions and directions.
 Bolts, nuts and washers should be replaced with
new ones as required.
 Even if necessary inspections have been made
in advance, proceed with assembly work while
making rechecks.
 Remove or install engine in an area where chain
hoists, lifting devices, etc. are available for ready
use.
 Be sure not to damage coated surfaces of body
panels with tools, or not to stain seats and windows
with coolant or oil. Place a cover over fenders, as
required, for protection.
 Prior to starting work, prepare the following:
Service tools, clean cloth, containers to catch cool-
ant and oil, wire ropes, chain hoist, transmission
jacks, etc.
 Lift-up or lower the vehicle when necessary.
Make sure to support the correct positions.
D: PREPARATION TOOL
1. SPECIAL TOOL
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS
18231AA010 CAM SPROCKET
WRENCH Used for removing and installing cam
sprocket. (LH side)
 Also the CAM SPROCKET WRENCH
(499207100) can be used.
24082AA230
(Newly adopted tool)CARTRIDGE Troubleshooting for electrical systems.
ST18231AA010
ST24082AA230

ME(H4SO)-34
MECHANICAL
Engine Assembly
9. Engine Assembly
A: REMOVAL
1) Set the vehicle on lift arms.
2) Open the front hood fully, and then support with
the front hood stay.
3) Release the fuel pressure. 47, RELEASING OF FUEL PRESSURE, OPERA-
TION, Fuel.>
4) Disconnect the A/C pressure hoses from A/C
compressor.
5) Remove the fuel filler cap.
6) Disconnect the ground cable from battery.
7) Remove the air intake duct and air cleaner case.

Case.>
8) Remove the under cover.
9) Remove the radiator from vehicle. CO(H4SO)-28, REMOVAL, Radiator.>
10) Remove the air cleaner case stay.
 MT model
 AT model11) Disconnect the following connectors and ca-
bles.
(1) Front oxygen (A/F) sensor connector
(2) Rear oxygen sensor connector
(3) Engine ground cable
FU-00009
ME-00204
ME-00205
EX-00029
EX-00030
ME-00206

ME(H4SO)-53
MECHANICAL
Cam Sprocket
16.Cam Sprocket
A: REMOVAL
1. REMOVAL
1) Remove the V-belt. MOVAL, V-belt.>
2) Remove the crank pulley. 45, REMOVAL, Crank Pulley.>
3) Remove the belt cover. REMOVAL, Timing Belt Cover.>
4) Remove the timing belt assembly. ME(H4SO)-48, REMOVAL, Timing Belt.>
5) Remove the camshaft position sensor. FU(H4SO)-27, REMOVAL, Camshaft Position
Sensor.>
6) Remove the cam sprocket No. 2. To lock the
camshaft, use ST.
ST 18231AA010 CAM SPROCKET WRENCH
NOTE:
Also the CAM SPROCKET WRENCH (499207100)
can be used.
7) Remove the cam sprocket No. 1. Use ST to lock
the camshaft.
ST 499207400 CAM SPROCKET WRENCH
B: INSTALLATION
1) Install the cam sprocket No. 1. To lock the cam-
shaft, use ST.
ST 499207400 CAM SPROCKET WRENCH
Tightening torque:
78 N
⋅m (8.0 kgf-m, 57.9 ft-lb)
NOTE:
Do not confuse the right and left side cam sprock-
ets during installation. The cam sprocket No. 2 is
identified by a projection used to monitor camshaft
position sensor.
2) Install the cam sprocket No. 2. Use ST to lock
camshaft.
ST 18231AA010 CAM SPROCKET WRENCH
NOTE:
Also the CAM SPROCKET WRENCH (499207100)
can be used.
Tightening torque:
78 N
⋅m (8.0 kgf-m, 57.9 ft-lb)
3) Install the camshaft position sensor. FU(H4SO)-27, INSTALLATION, Camshaft Position
Sensor.>
4) Install the timing belt assembly. ME(H4SO)-49, INSTALLATION, Timing Belt.>
5) Install the belt cover. STALLATION, Timing Belt Cover.>
6) Install the crank pulley. INSTALLATION, Crank Pulley.>
7) Install the V-belt. STALLATION, V-belt.>
ME-00250
ST
ME-00251
ST
ME-00251
ST
ME-00250
ST

ME(H4SO)-54
MECHANICAL
Cam Sprocket
C: INSPECTION
1) Check the cam sprocket teeth for abnormal wear
and scratches.
2) Make sure there is no free play between cam
sprocket and key.
3) Check the cam sprocket notch for sensor for
damage and contamination of foreign matter.

ME(H4SO)-55
MECHANICAL
Crank Sprocket
17.Crank Sprocket
A: REMOVAL
1) Remove the V-belt. MOVAL, V-belt.>
2) Remove the crank pulley. 45, REMOVAL, Crank Pulley.>
3) Remove the belt cover. REMOVAL, Timing Belt Cover.>
4) Remove the timing belt assembly. ME(H4SO)-48, REMOVAL, Timing Belt.>
5) Remove the cam sprocket. 53, REMOVAL, Cam Sprocket.>
6) Remove the crank sprocket.
B: INSTALLATION
1) Install the crank sprocket.
2) Install the cam sprocket. INSTALLATION, Cam Sprocket.>
3) Install the timing belt assembly. ME(H4SO)-49, INSTALLATION, Timing Belt.>
4) Install the belt cover. STALLATION, Timing Belt Cover.>
5) Install the crank pulley. INSTALLATION, Crank Pulley.>
6) Install the V-belt. STALLATION, V-belt.>
C: INSPECTION
1) Check the crank sprocket teeth for abnormal
wear and scratches.
2) Make sure there is no free play between crank
sprocket and key.
3) Check the crank sprocket notch for sensor for
damage and contamination of foreign matter.
ME-00252
ME-00252

ME(H4SO)-58
MECHANICAL
Camshaft
19.Camshaft
A: REMOVAL
1) Remove the V-belt. STALLATION, V-belt.>
2) Remove the crank pulley. 45, REMOVAL, Crank Pulley.>
3) Remove the belt cover. REMOVAL, Timing Belt Cover.>
4) Remove the timing belt assembly. ME(H4SO)-48, REMOVAL, Timing Belt.>
5) Remove the cam sprocket. 53, REMOVAL, Cam Sprocket.>
6) Remove the crank sprocket. 55, REMOVAL, Crank Sprocket.>
7) Remove the belt cover No. 2 (LH).
8) Remove the belt cover No. 2 (RH).
NOTE:
Do not damage or lose the seal rubber when re-
moving belt covers.
9) Remove the tensioner bracket.
10) Remove the camshaft position sensor support.
(LH side only)
11) Remove the oil level gauge guide. (LH side only)
12) Remove the valve rocker assembly. ME(H4SO)-56, REMOVAL, Valve Rocker Assem-
bly.>
13) Remove the camshaft cap.(1) Remove the bolts (a) through (b) in alpha-
betical sequence.
(2) Equally loosen the bolts (c) through (j) all the
way in alphabetical sequence.
(3) Remove the bolts (k) through (p) in alpha-
betical sequence using ST.
ST 499497000 TORX PLUS
(4) Remove the camshaft cap.
14) Remove the camshaft.
15) Remove the oil seal.
ME-00258
ME-00259
ME-00260
(b)(a)
ME-00261
(c)(e)
(g)
(h)
(d) (f) (j)(i)
ME-00262
(k)
(o)
(n) (l) (p) (m)
ME-00263

ME(H4SO)-60
MECHANICAL
Camshaft
(6) Tighten the bolts (o) through (v) in alphabet-
ical sequence.
Tightening torque:
10 N
⋅m (1.0 kgf-m, 7.2 ft-lb)
(7) Tighten the bolts (w) through (x) in alphabet-
ical sequence.
Tightening torque:
10 N
⋅m (1.0 kgf-m, 7.2 ft-lb)
3) Apply a coat of grease to oil seal lips, and then
install the oil seal (A) on camshaft using ST1 and
ST2.
NOTE:
Use a new oil seal.
ST1 499597000 OIL SEAL GUIDE
ST2 499587500 OIL SEAL INSTALLER
4) Install the plug using ST.
ST 499587700 CAMSHAFT OIL SEAL IN-
STALLER
5) Adjust the valve clearance. 32, ADJUSTMENT, Valve Clearance.>
6) Install the rocker cover and connect PCV hose.7) Install the oil level gauge guide. (LH side only)
8) Install the camshaft position sensor support. (LH
side only)
9) Install the tensioner bracket.
Tightening torque:
25 N
⋅m (2.5 kgf-m, 18.1 ft-lb)
10) Install the belt cover No. 2 (RH).
Tightening torque:
5 N
⋅m (0.5 kgf-m, 3.6 ft-lb)
11) Install the belt cover No. 2 (LH).
Tightening torque:
5 N
⋅m (0.5 kgf-m, 3.6 ft-lb)
12) Install the crank sprocket. 55, INSTALLATION, Crank Sprocket.>
13) Install the cam sprocket. 53, INSTALLATION, Cam Sprocket.>
14) Install the timing belt assembly. ME(H4SO)-49, INSTALLATION, Timing Belt.>
15) Install the belt cover. INSTALLATION, Timing Belt Cover.>
16) Install the crank pulley. INSTALLATION, Crank Pulley.>
17) Install the V-belt. STALLATION, V-belt.>
ME-00270
(o)
(r)(q)
(v)(u)
(p)(s)
(t)
ME-00271
(x) (w)
ME-00272(A)
ST2
ST1
ME-00273
ME-00274

EX(H4SO)-3
EXHAUST
General Description
(1) Front exhaust pipe upper cover
CTR(14) Muffler (28) Rear catalytic converter upper
cover
(15) Cushion rubber
(2) Front exhaust pipe lower cover
CTR(16) Rear exhaust pipe (29) Rear catalytic converter lower
cover
(17) Clamp
(3) Clamp (18) Center exhaust pipe upper cover (30) Rear catalytic converter
(4) Front exhaust pipe upper cover LH (19) Center exhaust pipe lower cover (31) Gasket
(5) Front exhaust pipe lower cover LH (20) Protector
(6) Front exhaust pipe (21) GasketTightening torque: N
⋅m (kgf-m, ft-lb)
(7) Front exhaust pipe lower cover RH (22) Front oxygen (A/F) sensorT1: 8 (0.8, 5.8)
(8) Front exhaust pipe upper cover
RH(23) Front catalytic converterT2: 13 (1.3, 9.4)
(24) Center exhaust pipeT3: 18 (1.8, 13.0)
(9) Gasket (25) Front catalytic converter lower
coverT4: 21 (2.1, 15.2)
(10) SpringT5: 30 (3.1, 22.4)
(11) Chamber (26) Front catalytic converter upper
coverT6: 35 (3.6, 26.0)
(12) GasketT7: 48 (4.9, 35.4)
(13) Self-locking nut (27) Rear oxygen sensor
