2004 NISSAN 350Z Navigation Manual

3. The [BUTTON TONE/BEEP RESPONSE]
screen will be displayed.
When turning on/off the beep sound, select the
On orOff key .
When the PUSH ENTER button is pressed, the
selected key will be illuminated.
INFO:
Press the MAP button to return to the map.
SETTING THE DISPLA Y
MODE
Y ou can alter the display mode.
ADJUSTING THE DISPLAY
BRIGHTNESS
Y ou can choose the best brightness for the dis-
play .
1. Press the SETTING button.
2. Select the
Display key .3. The [DISPLA Y SETTINGS] screen will be
displayed.
Select the
Brightness/Contrast/Map Background
key .
INV1729
INV1730
INV1731
HOW DO I ADJUST THE DISPLAY?
11-17

4. Select theBrightness key .
When the joystick is tilted to the right, the
screen will brighten, and darken when tilted to
the left.
INFO:
The screen displayed before pressing the
SETTING button will be displayed as a
sample screen on the [DISPLA Y SETTINGS]
screen.
ADJUSTING THE DISPLAY
CONTRAST
Y ou can choose the best contrast for the dis-
play .
1. Press the SETTING button.
2. Select the
Display key .3. The [DISPLA Y SETTINGS] screen will be
displayed.
Select the
Brightness/Contrast/Map Background
key .
INV1732
INV1730
INV1731
HOW DO I ADJUST THE DISPLAY?
11-18

4. Select theContrast key .
When the joystick is tilted to the right, contrast
of the screen will be higher , and will be lower
when tilted to the left.
SWITCHING THE DISPLAY
COLOR
1. Press the SETTING button.2. Select the
Display key .
3. The [DISPLA Y SETTINGS] screen will bedisplayed.
Select the
Brightness/Contrast/Map Background
key .
4. Select the
Map Background key .
The display brightness will be altered.
HOW TO USE THED/N
(DAY/NIGHT) BUTTON
1. Press the D/N button.
INV1735INV1730
INV1731
INV1738
HOW DO I ADJUST THE DISPLAY?
11-19

2. When the D/N button is pressed, the
screen will repeatedly switch between nor-
mal lighting and dimmer lighting indepen-
dently of turning on or off of illumination.
DISPLAY OFF
The display can be turned off with the following
procedure.
1. Press the SETTING button.2. Select the
Display key .
3. The [DISPLA Y SETTINGS] screen will bedisplayed.
Select the
Display Off key .
The indicator of the [DISPLA Y OFF] will
turn green.
4. A comment will be displayed for 5 seconds
and the display will turn off.
T o restart the display , press the SETTING
button and select the
Display Off key
again.
INFO:

When the INFO and MAP buttons are
INV1739INV1730
INV1741
INV1742
HOW DO I ADJUST THE DISPLAY?
11-20

pressed with the display turned off, the
screen shows normally , then the display
turns off again.

When the D/N button is pressed with the
display turned off, the display brightness is
changed when the screen is re-displayed.
SETTING DISPLAY DURATION
Y ou can set the display duration time.
1. Press the SETTING button.
2. Select the
Display key .3. The [DISPLA Y SETTINGS] screen will be
displayed.
Select the
Setting Display Duration key .
INFO:
When you finish setting the display duration
time, the display will return to the previous dis-
play automatically .
HOW TO HANDLE THE DIS-
PLA Y
The display uses liquid crystal and should be
handled with care.
WARNING
Never disassemble the display . It
has some areas with extreme high
voltage. T ouching it may result in se-
rious personal injury .
CHARACTERISTICS OF LIQUID
CRYSTAL DISPLAY

If the temperature inside the vehicle is es-
pecially low, the display will stay relatively
dim or the movement of the images may be
slow. These conditions are normal; when
the temperature rises, the display will func-
tion normally .

Y ou may notice darker or brighter dots in
parts of the display; this is inherent in
monitor displays and is not a malfunction.

Y ou may also notice a remnant of the pre-
vious display image on the screen. This af-
INV1730
INV1744
HOW DO I ADJUST THE DISPLAY?
11-21

terimage is inherent in displays and is not
abnormal.
INFO:
The screen may become distorted by strong
magnetic fields.
MAINTENANCE OF THE DIS-
PLAY
CAUTION

T o clean the display , never use a
rough cloth, alcohol, benzine,
thinner , any kind of solvent, or pa-
per towel with chemical cleaning
agent. They will scratch or dete-
riorate the panel.

Do not splash any liquid such as
water or car fragrance on the dis-
play . Contact with liquid will
cause the system to malfunction.If you need to clean the display screen, use a
dry soft cloth. If additional cleaning is neces-
sary , use a small amount of neutral detergent
with a soft cloth. Never soak the exterior with
water or detergent.
HOW DO I ADJUST THE DISPLAY?
11-22

12 HOW DO I USE THE VEHICLE INFORMATION?
Maintenance information ........................... 12-2

MAINTENANCE INFORMA-
TION
1. Press the INFO button.
2. The [MAINTENANCE INFO.] screen will be
displayed.
3. T o set the maintenance information for the
Engine Oil or Oil Filter , choose an item us-
ing the joystick and press the PUSH ENTER
button.4. The [ENGINE OIL] screen will be displayed.
5. T o reset, select the
RESET key .
6. Set the distance of the maintenance sched-
ule.
T o determine the maintenance interval, refer to
the vehicle’s Owner’s Manual.
T o automatically display the [MAINTENANCE
INFO.] screen when setting trip distance is
reached, select the
Display Maintenance Notification key and
press the PUSH ENTER button.
INV1756
INV1750
HOW DO I USE THE VEHICLE INFORMATION?
12-2
