2004 MERCEDES-BENZ G55AMG Owner's Manual

97 Controls in detail
Seats
Removing rear seat head restraints
Pull out head restraint with both hands.
Installing rear seat head restraints

Insert the head restraint and push it
down to the stop.
Ensure proper head restraint positioning
(
page 36).
Multicontour seat*
The multicontour seat has a movable seat
cushion and inflatable air cushions built
into the seat backrest to provide additional
lumbar and side support.
The seat cushion movement and amount of
seat backrest cushion height and curva-
ture can be continuously varied with regu-
lators on the right side of the seat after
turning the SmartKey in the starter switch
to position2.1Seat cushion length
2Backrest bottom
3Backrest center
4Backrest side bolsters

Make sure the ignition is switched on.
All the lamps in the instrument cluster
come on.
Seat cushion length

Adjust the seat cushion to the length of
your upper leg using switch1.
iThe head restraint(s) should be stored
in a secure place.

98 Controls in detailSeatsBackrest contour
Adjust the contour of the backrest to
the desired position using switches2
and 3.
Backrest side bolsters

Adjust the backrest side bolsters so
that they provide good lateral support
using switch4.
Heated seats
Driver’s and front passenger seats
The switch is located in the center console.
1Normal heating
2Rapid heating
Make sure the ignition is switched on.
All the lamps in the instrument cluster
come on.Switching on seat heating

Press upper switch position1.
A red indicator lamp on the switch
comes on.
Switching off seat heating

Press upper switch position1 again.
Switching on rapid seat heating

Press lower switch position2.
Both red indicator lamps on the switch
come on.iThe seat heater will be automatically
switched off after approximately
30 minutes.iThe system switches over to normal
heating mode after approximately five
minutes. Only one indicator lamp re-
mains lit.

99 Controls in detail
Seats
Switching off rapid seat heating
Press lower switch position2 again.Rear seats
The switch is located on the B (center) pil-
lar.
1Normal heating
2Rapid heating

Make sure the ignition is switched on.
All the lamps in the instrument cluster
come on.Switching on seat heating

Press upper switch position1.
A red indicator lamp on the switch
comes on.
Switching off seat heating

Press upper switch position1 again.
Switching on rapid seat heating

Press lower switch position2.
Both red indicator lamps on the switch
come on.
iIf one or both of the lamps on the seat
heater switch are blinking, there is in-
sufficient voltage available as too many
electrical consumers are turned on.
The seat heater switches off automati-
cally.
The seat heater will switch back on
again automatically as soon as suffi-
cient voltage is available.
iThe seat heater will be automatically
switched off after approximately
30 minutes.iThe system switches over to normal
heating mode after approximately five
minutes. Only one indicator lamp re-
mains lit.

100 Controls in detailSeatsSwitching off rapid seat heating
Press lower switch position2 again.iIf one or both of the lamps on the seat
heater switch are blinking, there is in-
sufficient voltage available as too many
electrical consumers are turned on.
The seat heater switches off automati-
cally.
The seat heater will switch back on
again automatically as soon as suffi-
cient voltage is available.

101 Controls in detail
Memory function
Memory function
The memory button and stored position
switch are located on the door.
You can store up to three different settings
per SmartKey.
The following settings are saved for each
stored position:

Driver’s seat and seat backrest posi-
tion


Steering wheel position


Driver’s side exterior rear view mirror
position


Passenger-side exterior rear view mir-
ror position


Front passenger seat position
These key-dependent memory settings
can be deactivated if desired
(
page 135).
!Prior to operating the vehicle, the driv-
er should check and adjust the seat
height, seat position fore and aft, and
seat backrest angle if necessary, to en-
sure adequate control, reach and com-
fort. The head restraint should also be
adjusted for proper height. See also the
section on airbags (
page 57) for
proper seat positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, opera-
tion and comfort. Both the interior and
exterior rear view mirrors should be ad-
justed for adequate rear vision.
Fasten seat belts. Infants and small
children should be seated in a properly
secured restraint system that complies
with U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and Canadian
Motor Vehicle Safety Standards 213
and 210.2.
Warning!
G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.

102 Controls in detailMemory function1Memory button
2Stored position buttons
Make sure the ignition is switched on
or the relevant door is open and the
SmartKey is inserted in the starter
switch.
Storing positions into memory
Adjust the seats, steering wheel and
exterior rear view mirrors to the de-
sired position (
page 34).

Press memory button1.

Release memory button and push posi-
tion button2 within three seconds.
All the settings are stored at the select-
ed position.
Recalling positions from memory
Press and hold position button2 until
the seat, steering wheel and rear view
mirrors have fully moved to the stored
positions.iReleasing the button immediately
stops movement to the stored posi-
tions.Warning!
G
Do not operate the power seats using the
memory button if the seat backrest is in an
excessively reclined position. Doing so
could cause damage to front or rear seats.
First move seat backrest to an upright posi-
tion.

103 Controls in detail
Memory function
Storing exterior rear view mirror park-ing position
For easier parking, you can adjust the pas-
senger-side exterior rear view mirror so
that you can see the right rear wheel as
soon as you engage reverse gearR.
For information on activating the parking
position, see “Activating exterior rear view
mirror parking position” (
page 153).
1Adjustment button
2Driver’s side mirror
3Passenger-side mirror
4Memory button

Stop the vehicle.

Switch ignition on (if not already on).

Press button3.
The passenger-side exterior rear view
mirror is selected.

Adjust the exterior rear view mirror
with button1 so that you see the rear
wheel and the curb.

Press memory button4 on the door.

Within three seconds, press bottom of
adjustment button1 above the exteri-
or lamp switch.
The parking position is stored if the
mirror does not move.
iYou can store a parking position for the
passenger-side exterior rear view mir-
ror for each SmartKey using the memo-
ry switch.
iIf the mirror does move, repeat the
above steps. After the setting is stored
you can move the mirror again.

104 Controls in detailLighting
LightingFor notes on how to switch on the head-
lamps and use the turn signals, see the
“Getting started” section (
page 46).
Exterior lamp switch
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.MOff
UAutomatic headlamp mode
CParking lamps (also side marker
lamps, tail lamps, license plate
lamps, instrument panel lamps)
Canada only: When engine is run-
ning, the low beam is additionally
switched on.
BParking lamps plus low beam or
high beam headlamps (combination
switch pushed forward).
ˆStanding lamps, right (turn left one
stop)
‚Standing lamps, left (turn left two
stops)
iIf you drive in countries where vehicles
drive on the other side of the road than
the country where the vehicle is regis-
tered, you must have the headlamps
modified for symmetrical low beams.
Relevant information can be obtained
at your authorized Mercedes-Benz
Light Truck Center.
