2004 KIA Amanti Owner's Manual

Knowing your vehicle94
3
1
2
3
4
5
6
7
8
9
Sunglass holder A sunglass storage compartment is
provided on the overhead console.
To open the sunglass holder, press
the cover and the holder will slowly
open. Place your sunglasses in the
compartment door with the lenses
facing out. Push to close.
✽ ✽
NOTICEMake sure the sunglass holder is
closed while driving.
1GHA2060B
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 94

395
1
2
3
4
5
6
7
8
9
Knowing your vehicle
Cigarette lighterFrontTo use the cigarette lighter, press
the front face then release it to allow
the cigarette lighter and ashtray to
slowly extend from center panel.
To operate the cigarette lighter, press
it in and release it. When it is heated,
it automatically pops out ready for
use.
If the engine is not running, the igni-
tion switch must be in the ACC posi-
tion for the lighter to operate.
✽ ✽NOTICE• Do not hold the lighter in after it is
already heated because it will
overheat.
• Only a genuine Kia lighter should be used in the cigarette lighter
socket. The use of plug-in acces-
sories (shavers, hand-held vacu-
ums, and coffee pots, for example)
may damage the socket or cause
electrical failure.
• If the lighter does not pop out within 30 seconds, remove it to
prevent overheating.
Ashtrays Front To use the ashtray, press the front
face and release it to allow the ciga-
rette lighter and ashtray to slowly
extend from center panel.
To remove the ashtray, grasp the
ashtray bucket (
➀) and carefully pull
it out.
INTERIOR FEATURES
1GHA2084
1GHA2084A
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 95

Knowing your vehicle96
3
1
2
3
4
5
6
7
8
9
Cup holderCups or small beverage cans may be
placed in the cup holders.
FrontTo open the cup holder cover, press
the cover and it will automatically
open. Push the cover to close after
use.
WARNING
- Ashtray use
 Do not use the vehicle ’s ash-
trays as waste receptacles.
 Putting lit cigarettes or match-
es in an ashtray with other
combustible materials may
cause a fire.
WARNING
- Hot liquids
 Do not place uncovered cups
of hot liquid in the cup holder
while the vehicle is in motion.
If the hot liquid spills, you
could be burned. Such a burn
to the driver could cause a
loss of control of the vehicle.
 To reduce the risk of personal
injury in the event of sudden
stop or collision, do not place
uncovered or insecure bot-
tles, glasses, cans, etc., in the
cup holder while the vehicle is
in motion.
2GHN2088
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 96

397
1
2
3
4
5
6
7
8
9
Knowing your vehicle
RearTo use cup holders in rear seat, pull
down the rear seat armrest.
✽ ✽NOTICEDo not place heavy cups or cans in
cup holders. Cup holders could be
damaged.
SunvisorUse the sunvisor to shield direct light
through the front or side windows.
To use a sunvisor, pull it downward.
To use a sunvisor for a side window,
pull it downward, unsnap it from the
bracket (
➀) and swing it to the side.
To use the vanity mirror, pull down
the visor and pull up the mirror cover
(
➁).
Pull the extension panel (
➂) of the
sunvisor to lengthen the sunvisor.
1GHA2089
2GHN482
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 97

Knowing your vehicle98
3
1
2
3
4
5
6
7
8
9
✽ ✽
NOTICEClose the vanity mirror cover
securely and return the sunvisor to
its original position after use. If the
vanity mirror is not closed securely,
the lamp will stay on and could
result in battery discharge and pos-
sible sunvisor damage.
Power socket (if equipped)The power outlets are designed to
provide power for mobile telephones
or other devices designed to operate
with vehicle electrical systems. The
devices should draw less than 10
amps with the engine running.
2GHN33401GHA2234
Front (if equipped)Rear
2GHN3350
Center (if equipped)
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 98

399
1
2
3
4
5
6
7
8
9
Knowing your vehicle
✽ ✽NOTICE• Use when the engine is running.
• Only use the electric appliances
which are less than 12V and 10A
in electric capacity.
• Adjust the air-conditioner or heater to the lowest operation
level when you have to use the
power socket while using air-con-
ditioner or heater.
• Close the cover when not in use.
ClockDigital (if equipped)Whenever the battery terminals, A/V
CLOCK fuse, or Power Connect are
disconnected, you must reset the
time.
Press the Clock Control PUSH but-
ton in front of the monitor to access
the mode set buttons. Use these
buttons to adjust the time/date dis-
played on the monitor. 1. Press the MODE button (
➀).
2. Select the mode to be reset; hour (
➁), minute (
➂), month (
➃) and
date (
➄).
3. Reset the data using button  (
\b)
or button  (
➆) while the selected
mode blinks.
If the  (
\b) or  (
➆) button(s) are
pressed for more than 3 seconds,
the display will begin to change
rapidly. When the  (\b) or  (
➆)
button(s) are pressed then
released, the display will change
in single increments.
4. Press the SET (
➇) button when
the data is correctly set.
1GHA2110
➀
➆
➇
\b
➁
➂
➃
➄
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 99

Knowing your vehicle100
3
1
2
3
4
5
6
7
8
9
If your vehicle is equipped with this
feature, you can slide or tilt your sun-
roof with the sunroof control buttons
located on the overhead console.
The sunroof can only be opened,
closed, or tilted when the ignition
switch is in the “ON”position.
✽ ✽
NOTICE• Do not continue to press the sun-
roof control button(s) after the
sunroof is in the fully open, closed,
or tilt position(s). Damage to the
motor or system components
could occur.
• The sunroof cannot slide when it is in the tilt position nor can it be tilt-
ed while in an open or slide posi-
tion.
Sliding the sunroof Autoslide open
To use the autoslide feature,
momentarily (more than 1 second)
press the SLIDE OPEN button on the
overhead console. The sunroof will
slide all the way open. To stop the
sunroof sliding at any point, press
any sunroof control button.
Manual slide open
Press the SLIDE OPEN button on
the overhead console for less than
0.5 second.
Close
To close the sunroof, press the
CLOSE button on the overhead con-
sole and hold it until the sunroof is
closed.
SUNROOF (IF EQUIPPED)
SLIDESLIDEOPENOPENTILTTILT UP UPCLOSECLOSESLIDESLIDEOPENOPENTILTTILT UP UPCLOSECLOSE
2GHA2060A
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 100

3 101
1
2
3
4
5
6
7
8
9
Knowing your vehicle
Tilting the sunroof Autotilt open
To use the autotilt feature, momen-
tarily (more than 1 second) press the
TILT UP button on the overhead
console. The sunroof will tilt all the
way open. To stop the sunroof tilting
at any point, press any sunroof con-
trol button.
Manual tilt open
Press the TILT UP button on the
overhead console for less than 0.5
second.
Close
To close the sunroof, press the
CLOSE button on the overhead con-
sole and hold it until the sunroof is
closed.
Sunshade The sunshade will be opened with
the glass panel automatically when
the glass panel is slid. You will have
to close it manually if you want it
closed.
✽ ✽NOTICE• Do not press any sunroof control
button longer than necessary.
Damage to the motor or system
components could occur.
• Periodically remove any dirt that may accumulate on the guide rail.
• If you try to open the sunroof when the temperature is below
freezing or when the sunroof is
covered with snow or ice, the glass
or the motor could be damaged.
• The sunroof is made to slide together with sunshade. Do not
leave the sunshade closed while
the sunroof is open.
• Remove any dirt that may be accumu-lated on the guide rail
periodically.
E2BLA361
WARNING
 Do not extend face or arms
outside through the sunroof
opening while driving.
 Make sure hand and face are
safely out of the way before
closing a sunroof.
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 101
