2004 DAEWOO LACETTI Section 6

9G – 10IINTERIOR TRIM
DAEWOO V–121 BL4
4. Install the screws to the rear portion of the floor
console.
5. Connect the negative battery cable.
6. Install the glove box, instrument panel lower cover,
cigar lighter trim panel and stereo cassette player.
7. Install the console cover.
FLOOR CARPET
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the rear seat cushion. Refer to Section 9H,
Seats.
3. Remove the left and the right rear rocker trim pan-
els. Refer to ”Rear Rocker Trim Panel” in this sec-
tion.
4. Remove the bolts and the left and the right lower
front seat belt anchors from the B–pillar.
5. Remove the left and the right front rocker trim pan-
els.
6. Remove the left and the right lower B–pillar trim
panels. Refer to ”Lower B–Pillar Trim Panel” in this
section.
7. Remove the front seats. Refer to Section 9H,
Seats.
8. Remove the left and the right kick panels. Refer to
”Kick Panel” in this section.
9. Remove the floor console. Refer to ”Floor Console”
in this section.
10. Remove the gearshift housing bolts and nuts and
reposition the gearshift housing.
11. Remove the floor carpet.
Installation Procedure
1. Install the floor carpet.
2. Install the gearshift housing with the bolts.
Tighten
Tighten the gearshift housing bolts and nuts to 8 NSm
(70 lb–in).

INTERIOR TRIM 9G – 11
DAEWOO V–121 BL4
3. Install the floor console. Refer to ”Floor Console” in
this section.
4. Install the left and the right kick panels. Refer to
”Kick Panel” in this section.
5. Install the front seats. Refer to Section 9H, Seats.
6. Install the left and the right lower B–pillar trim pan-
els. Refer to ”Lower B–Pillar Trim Panel” in this
section.
7. Install the left and the right front rocker trim panels.
8. Install the left and the right lower front seat belt an-
chors to the B–pillar with the bolts.
Tighten
Tighten the seat belt anchor bolts to 38 NSm (28 lb–ft).
9. Install the left and the right rear rocker trim panels.
Refer to ”Rear Rocker Trim Panel” in this section.
10. Install the rear seat cushion. Refer to Section 9H,
Seats.
11. Connect the negative battery cable.
LUGGAGE COMPARTMENT REAR
LOW COVER
Removal Procedure
1. Remove the clips and the rear panel cover.
Installation Procedure
1. Install the rear panel cover with the clips.

9G – 12IINTERIOR TRIM
DAEWOO V–121 BL4
LUGGAGE COMPARTMENT
WHEELHOUSE TRIM PANEL
Tools Required
KM–475–B Trim Remover
Removal Procedure
1. Remove the luggage compartment rear panel cov-
er. Refer to ”Luggage Compartment Rear Panel
Cover” in this section.
2. Remove the plastic retaining clips using the trim
remover KM–475–B and reposition the luggage
compartment rear trim panel.
Installation Procedure
1. Install the wheelhouse trim panel with the plastic
clips.
2. Install the luggage compartment rear panel cover.
Refer to ”Luggage Compartment Rear Panel Cover”
in this section.
DRIVER’S SIDE KNEE BOLSTER
Removal Procedure
1. Remove the screws.
2. Separate the hood release cable from the hood
latch release handle.
3. Carefully pull the instrument panel under cover until
the mounting clips are released and the instrument
panel under cover.
4. Remove the bolts from the driver’s side knee bol-
ster.
5. Remove the knee bolster.

INTERIOR TRIM 9G – 13
DAEWOO V–121 BL4
Installation Procedure
1. Install the knee bolster with the bolts.
Tighten
Tighten the driver’s side knee bolster mounting bolts
to 10 NSm (89 lb–in).
2. Install the instrument panel under cover.
3. Connect the hood release cable to the hood latch
release handle.
4. Install the screws.
HATCHBACK DOOR LOWER
GARNISH MOLDING
Tools Required
KM–475–B Trim Remover
Removal Procedure
1. Open the hatchback door.
2. Remove the hatchback door upper garnish molding.
Refer to ”Hatchback Door upper garnish Molding” in
this section.
3. Remove the lower garnish molding clips using the
trim remover KM–475–B.
4. Remove the lower garnish molding.
Installation Procedure
1. Install the lower garnish molding with the clips.
2. Install the hatchback door upper garnish molding.
3. Close the hatchback door.

9G – 14IINTERIOR TRIM
DAEWOO V–121 BL4
HATCHBACK DOOR UPPER
GARNISH MOLDING
Removal Procedure
1. Open the hatchback door.
2. Pry off the hatchback door upper garnish molding.
Installation Procedure
1. Install the hatchback door upper garnigh moling.
2. Close the hatchback door.
LUGGAGE COMPARTMENT
WHEELHOUSE TRIM PANEL
(HATCHBACK)
Removal Procedure
1. Remove the luggage compartment rear trim panel.
Refer to ”Luggage Compartment Rear Trim Panel”
in this section.
2. Remove the clips and the screw.
3. Remove the wheelhouse trim panel.
Installation Procedure
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
1. Install the wheelhouse trim panel with the clips the
screw.
2. Install the luggage compartment rear trim panel. Re-
fer to ”Luggage Compartment Rear Trim Panel” in
this section.
LUGGAGE COMPARTMENT REAR
TRIM PANEL
Removal Procedure
1. Remove the plastic retaining clips and the rear trim
panel.

SECTION : 9H
SEATS
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS9H–2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 9H–2. . . . . . . . . . .
MAINTENANCE AND REPAIR9H–3 . . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9H–3. . . . . . . . . . . . . . . . . . . . .
Front Bucket Seat 9H–3. . . . . . . . . . . . . . . . . . . . . . . . .
Front Seatback 9H–4. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Seat Cushion 9H–5. . . . . . . . . . . . . . . . . . . . . . . .
Lumbar Support Lever 9H–5. . . . . . . . . . . . . . . . . . . . . .
Height Adjustment Knobs 9H–6. . . . . . . . . . . . . . . . . . .
Front Seat Trim 9H–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . Head Restraint 9H–7. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Seat Cushion 9H–8. . . . . . . . . . . . . . . . . . . . . . . . .
Split Rear Seatback 9H–8. . . . . . . . . . . . . . . . . . . . . . . .
Split Rear Seatback Hinge 9H–9. . . . . . . . . . . . . . . . . .
Rear Seat Center Armrest 9H–9. . . . . . . . . . . . . . . . . .
Seat Covers 9H–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child Seat Anchorage 9H–10. . . . . . . . . . . . . . . . . . . . .
Hatchback Child Seat Anchorage 9H–11. . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION9H–12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seats 9H–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9H – 4ISEATS
DAEWOO V–121 BL4
5. Install the bolts into the rear portion of the front
seat.
Tighten
Tighten the front seat–to–floor bolts to 25 NSm (18 lb–
ft).
6. Install the plastic caps.
7. Connect the negative battery cable.
FRONT SEATBACK
Removal Procedure
1. Remove the front bucket seat from the vehicle. Re-
fer to ”Front Bucket Seats” in this section.
2. Remove the each seat trim.
3. Disconnect the electrical connectors.
4. Remove the bolts and the seatback.
Installation Procedure
1. Install the seatback onto the seat cushion.
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
2. Install the front seatback bolts.
Tighten
Tighten the front seatback bolts to 45 NSm (33 lb–ft).
3. Connect the electrical connectors.

SEATS 9H – 5
DAEWOO V–121 BL4
4. Install the seat trims to its original position.
5. Install the front bucket seat in the vehicle. Refer to
”Front Bucket Seats” in this section.
FRONT SEAT CUSHION
Removal Procedure
1. Remove the front seat from the vehicle. Refer to
”Front Bucket Seats” in this section.
2. Remove the seat trims.
3. Remove the seat cushion nuts.
4. Remove the cushion from the seat track.
Installation Procedure
1. Install the cushion onto the seat track.
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
2. Install the seat cushion with the nuts.
Tighten
Tighten the front seat cushion nuts to 12 NSm (106 lb–
in).
3. Install the seat trims.
4. Install the front seat in the vehicle. Refer to ”Front
Bucket Seats” in this section.
LUMBAR SUPPORT LEVER
Removal Procedure
1. Remove the lumbar support lever.
