2004 DAEWOO LACETTI Section 6

9O – 6IBUMPERS AND FASCIAS
DAEWOO V–121 BL4
4. Install the screws behind the fascia.
5. Install the splash shields with the screws.
6. Install the mud guards with the screws.
7. Install the rear wheels. Refer to Section 2E, Tires
and Wheels.
HATCHBACK REAR BUMPER
FASCIA
Removal Procedure
1. Remove the rear wheels. Refer to Section 2E,
Tires and Wheels.
2. Remove the screws and the splash shields.
3. Remove the screws behind the fascia.
4. Remove the luggage compartment wheelhouse trim
panels. Refer to Section 9G, Interior Trim.
5. Remove the bolts and the nuts in the luggage
compartment.
6. Remove the screws.
7. Remove the rear bumper fascia.

BUMPERS AND FASCIAS 9O – 7
DAEWOO V–121 BL4
Installation Procedure
1. Install the rear bumper fascia with the screws.
2. Install the bolts and the nuts in the luggage
compartment.
3. Install the luggage compartment wheelhouse trim
panels. Refer to Section 9G, Interior Trim.
4. Install the screws behind the fascia.
5. Install the splash shields with the screws.
6. Install the rear wheels. Refer to Section 2E, Tires
and Wheels.
REAR BUMPER IMPACT BAR
Removal Procedure
1. Remove the rear bumper fascia. Refer to ”Rear
Bumper Fascia” in this section.
2. Remove the screws and the impact bar.

9O – 8IBUMPERS AND FASCIAS
DAEWOO V–121 BL4
Installation Procedure
1. Install the impact bar with the screws.
2. Install the rear bumper fascia. Refer to ”Rear
Bumper Fascia” in this section.

SECTION : 9P
DOORS
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS9P–2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specification 9P–2. . . . . . . . . . . . .
SCHEMATIC AND ROUTING DIAGRAMS9P–3 . . . . .
Power Door Locks Circuit 9P–3. . . . . . . . . . . . . . . . . . . .
Power Windows Circuit (Front Only) 9P–4. . . . . . . . . .
Power Windows Circuit (Front and Rear) 9P–5. . . . . .
DIAGNOSIS9P–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Windows 9P–6. . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND REPAIR9P–16 . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9P–16. . . . . . . . . . . . . . . . . . . .
Outside Channel Molding 9P–16. . . . . . . . . . . . . . . . . . .
Front Door Glass Run 9P–16. . . . . . . . . . . . . . . . . . . . . .
Door Weatherstrip 9P–17. . . . . . . . . . . . . . . . . . . . . . . . .
Rear Door Glass Run 9P–18. . . . . . . . . . . . . . . . . . . . . .
Front Door Secondary Weatherstrip 9P–18. . . . . . . . . .
Rear Door Secondary Weatherstrip 9P–19. . . . . . . . . .
Front Door Opening Weatherstrip 9P–19. . . . . . . . . . . .
Rear Door Opening Weatherstrip 9P–20. . . . . . . . . . . . Door Seal Trim 9P–20. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Striker 9P–21. . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Striker Adjustment 9P–22. . . . . . . . . . . . . . .
Front Door Lock 9P–23. . . . . . . . . . . . . . . . . . . . . . . . . . .
Childproof Rear Door Lock 9P–23. . . . . . . . . . . . . . . . . .
Inside Door Handle 9P–24. . . . . . . . . . . . . . . . . . . . . . . .
Outside Door Handle 9P–24. . . . . . . . . . . . . . . . . . . . . . .
Inside Lock Rod 9P–25. . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Cylinder 9P–25. . . . . . . . . . . . . . . . . . . . . . . .
Power Window Regulator 9P–26. . . . . . . . . . . . . . . . . . .
Door Assembly 9P–26. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Hinge 9P–27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Hold–Open Link 9P–28. . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION9P–29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Striker 9P–29. . . . . . . . . . . . . . . . . . . . . . . . . .
Childproof Rear Door Lock 9P–29. . . . . . . . . . . . . . . . . .
Power Door Locks 9P–29. . . . . . . . . . . . . . . . . . . . . . . . .
Power Windows 9P–29. . . . . . . . . . . . . . . . . . . . . . . . . . .

9P – 16IDOORS
DAEWOO V–121 BL4
MAINTENANCE AND REPAIR
ON–VEHICLE SERVICE
OUTSIDE CHANNEL MOLDING
(Front Door Shown, Rear Door Similar)
Removal Procedure
1. Lower the window completely.
2. Remove the outside channel molding screw.
3. Lift the outside channel molding off the door.
Installation Procedure
1. Press the outside channel molding onto the door.
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
2. Install the outside channel molding screw.
Tighten
Tighten the outside channel molding screw to 1.3 NSm
(12 lb–in).
3. Raise the window.
FRONT DOOR GLASS RUN
Removal Procedure
1. Remove the outside rearview mirror. Refer to Sec-
tion 9L, Glass and Mirrors.
2. Remove the front door glass. Refer to Section 9L,
Glass and Mirrors.
3. Remove the glass run.

DOORS 9P – 17
DAEWOO V–121 BL4
Installation Procedure
1. Install the glass run.
2. Install the front door glass. Refer to Section 9L,
Glass and Mirrors.
3. Install the outside rearview mirror. Refer to Section
9L, Glass and Mirrors.
DOOR WEATHERSTRIP
(Front Door Shown, Rear Door Similar)
Removal Procedure
1. Remove the door hold–open link–to–body bolt and
the door hold–open link.
2. Remove the door weatherstrip.
Installation Procedure
1. Install the door weatherstrip.

9P – 18IDOORS
DAEWOO V–121 BL4
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
2. Install the door hold–open link to the body with the
bolt.
Tighten
Tighten the door hold–open link–to–body bolt to 25
NSm (18 lb–ft).
REAR DOOR GLASS RUN
Removal Procedure
1. Remove the rear door glass. Refer to Section 9L,
Glass and Mirrors.
2. Remove the rear door glass run.
Installation Procedure
1. Install the rear door glass run.
2. Install the rear door glass. Refer to Section 9L,
Glass and Mirrors.
FRONT DOOR SECONDARY
WEATHERSTRIP
Removal Procedure
1. Remove the outside rearview mirror. Refer to Sec-
tion 9L, Glass and Mirrors.
2. Remove the front door secondary weatherstrip.

DOORS 9P – 19
DAEWOO V–121 BL4
Installation Procedure
1. Install the front door secondary weatherstrip.
2. Install the outside rearview mirror. Refer to Section
9L, Glass and Mirrors.
REAR DOOR SECONDARY
WEATHERSTRIP
Removal Procedure
1. Remove the interior garnish molding.
2. Remove the screws and the exterior garnish mold-
ing.
3. Remove the rear door secondary weatherstrip.
Installation Procedure
1. Install the rear door secondary weatherstrip.
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
2. Install the exterior garnish molding with the screws.
3. Install the interior garnish molding.
FRONT DOOR OPENING
WEATHERSTRIP
Removal Procedure
1. Remove the kick panel, the front rocker panel, and
the lower B–pillar trim panel. Refer to Section 9G,
Interior Trim.
2. Remove the front door opening weatherstrip.
