2003 VOLVO XC70 Owners Manual

2003 VOLVO XC70

Sideview mirror controls
Electrically operated sideview mirrors
The mirror control switches are located on the driver's door armrest.
Driver's side: Press the L switch (an LED in the switch will light up) to activate th\
e adjustment control
and then use this control to adjust the driver's door mirror.
Passenger's door: Press the R switch (an LED in the switch will light up) and then use t\
he adjustment
control to adjust the passenger's door mirror.
After you have adjusted the mirror(s), press the L or R switch again (\
the LED will go out) to deactivate
the adjustment control.
Remote central locking and sideview mirror memory If you lock the car and later unlock it with the
same remote control and open the driver's door, the sideview mirrors will au\
tomatically move to the
position they were in when you left the car. This feature will work in t\
he same way with all of the
remote control transmitters (up to 3) that you use with your car.
This feature will not function if you lock your car with the key. WARNING!
The mirrors should always be adjusted prior to driving. Objects seen in \
the wide-angle sideview
mirror are closer than they appear to be.


pg. 42 Sun roof (option)
file:///K|/ownersdocs/2003/2003_XC70/03xc70_02b.htm (15 of 18)12/30/20\
06 4:17:54 PM

2003 VOLVO XC70


Sun roof switch
Electrically operated sun roof
To operate the sun roof, the ignition key must first be turned to the in\
termediate or drive position
(position I or II).
l To slide open the sun roof : Pull the switch back to the first detent ("stop") and hold it until th\
e sun
roof has opened to the position you prefer. The sun roof will initially \
open to the "comfort" * position.
Pull and hold the switch again to open the sun roof completely.
l AUTO open: Pull the switch as far back as possible and release it to automatically \
slide open the sun
roof to the "comfort" * position. Pull the switch again to open the sun \
roof completely. Ventilation position

Sliding sun roof
l To close the sun roof: Push the switch forward to the first detent ("stop") and hold it unti\
l the sun
roof has closed completely.
l AUTO close:Push the switch forward as far as possible and release it to automatical\
ly close the sun
file:///K|/ownersdocs/2003/2003_XC70/03xc70_02b.htm (16 of 18)12/30/20\
06 4:17:54 PM

2003 VOLVO XC70
roof.
NOTE: If the sun roof is impeded during AUTO close, it will reverse direction, reopen and stop.
l Ventilation position (opening the rear edge of the sun roof): With the sun roof closed, push up the
rear section of the switch.
To close, pull the front section of the switch straight down until the s\
un roof has closed completely.
WARNING!
l Never open/close the sun roof if it is obstructed in any way when in ope\
ration.
l Never allow a child to operate the sun roof.
l Never extend any object or body part though the open sun roof, even if t\
he vehicle's ignition on is
completely switched off.
l Never leave a child alone in a vehicle.
CAUTION!
l Remove ice and snow before opening the sun roof.
l Do not operate the sun roof if it is frozen closed.
l Never place heavy objects on the sun roof.
* A position where the sun roof is not quite fully open which helps alle\
viate rumbling wind noise.

pg. 43 Sun visor


Sun visor
Sun visor:
file:///K|/ownersdocs/2003/2003_XC70/03xc70_02b.htm (17 of 18)12/30/20\
06 4:17:54 PM

2003 VOLVO XC70
The optional sun roof also features a sliding sun visor. The visor slide\
s open automatically when the sun
roof is opened. The visor must be closed manually.



Contents | Top of Page
file:///K|/ownersdocs/2003/2003_XC70/03xc70_02b.htm (18 of 18)12/30/20\
06 4:17:54 PM

2003 VOLVO XC70
2 0 0 3
VOLVO XC70
Chapter 3 - Climate control system


pg. 45 Climate control system

Ventilation 46
Climate control system - general information47
Electronic Climate Control (ECC)48

pg. 46 Ventilation


Air vents in dash
Air vents (dash)
A Open
B Closed
file:///K|/ownersdocs/2003/2003_XC70/03xc70_03.htm (1 of 12)12/30/2006\
4:17:55 PM

2003 VOLVO XC70
C Horizontal air flow
D Vertical air flow
Direct the outer air vents toward the side windows to demist.
In cold weather, close the air vents in the center of the dash to direct\
as much air as possible toward the
windows.
Air flow
The air that is drawn into the passenger compartment is distributed from\
14 ventilation points.

Air vents in door pillars
Air vents in door pillars
file:///K|/ownersdocs/2003/2003_XC70/03xc70_03.htm (2 of 12)12/30/2006\
4:17:55 PM

2003 VOLVO XC70
A Open
B Closed
C Horizontal air flow
D Vertical air flow
Direct the air vents toward the rear side windows to demist.
Direct the air vents toward the rear seat for the best heating/cooling e\
ffect.

pg. 47 Climate control system - general information
Condensation on the inside of the windows
Keeping the insides of the windows clean will help reduce the amount of \
condensation that forms on the
windows. Use a commercial window cleaning agent to clean the windows.
Ice and snow
Always keep the air intake grille at the base of the windshield free of \
snow.
Cabin air filter
Replace the cabin air filter with a new one at the recommended intervals\
. The filter should be replaced
more often when driving under dirty and dusty conditions. The filter can\
not be cleaned and therefore
should always be replaced with a new one.
Sensors
The sunlight sensor on the dashboard and passenger compartment temperatu\
re sensor in the ECC control
panel should not be covered in any way as this could cause incorrect inf\
ormation to be sent to the ECC
system.
Parking the car in warm weather
If your car has been parked in the sun in warm weather, opening the wind\
ows and sun roof (option) for
file:///K|/ownersdocs/2003/2003_XC70/03xc70_03.htm (3 of 12)12/30/2006\
4:17:55 PM

2003 VOLVO XC70
several minutes before driving will help release the warm air from the p\
assenger compartment. When
the engine is running, close the windows and sun roof and use the recirc\
ulation function for several
minutes to enable the air conditioning to cool the compartment as quickl\
y as possible.
Windows and optional sun roof
The ECC system will function best if the windows and optional sun roof a\
re closed. If you drive with the
sun roof open, we recommend that you manually adjust the temperature and\
blower control (the LED in
the AUTO switch should be off).
Acceleration
The air conditioning is momentarily disengaged during full-throttle acce\
leration.
ECC maintenance
All maintenance on the climate control systems should be carried out by \
an authorized Volvo service
technician only.
Refrigerant
Volvo cares about the environment. The air conditioning system in your c\
ar contains a CFC-free
refrigerant - R134a. This substance will not deplete the ozone layer. Th\
e system contains 2.2 lbs (1000
g) R134a and uses PAG oil.
Passenger compartment blower
Approximately 50 minutes after the ignition is turned off, the blower ma\
y come on automatically, and
run for five minutes, to remove condensation in the A/C evaporator.

pg. 48 Electronic Climate Control (ECC)

file:///K|/ownersdocs/2003/2003_XC70/03xc70_03.htm (4 of 12)12/30/2006\
4:17:55 PM
