2003 NISSAN X-TRAIL sensor

TROUBLE DIAGNOSIS
EC-431
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC65 RSensor's power sup-
ply[Ignition switch “ON”]Approximately 5V
66 W/LPower supply for
ECM (Buck-up)[Ignition switch “OFF”]BATTERY VOLTAGE
(11 - 14V)
67 PPower steering pres-
sure sensor[Engineisrunning]
lSteering wheel is being turned.0.5 - 4.0V
[Engineisrunning]
lSteering wheel is not being turned.0.4 - 0.8V
71 PU/RCrankshaft position
sensor (POS)[Engineisrunning]
lWarm-up condition
lIdle speedApproximately 3V
[Engineisrunning]
lEngine speed is 2,000 rpmApproximately 3V
72 OR Mass air flow sensor[Engineisrunning]
lWarm-up condition
lIdle speed1.1 - 1.5V
[Engineisrunning]
lWarm-up condition
lEngine speed is 2,500 rpm.1.6 - 2.0V
73 WThrottlepositionsen-
sor 1[Ignition switch "ON"]
lGear position is "D" (A/T model)
lGear position is "1st" (M/T model)
lAccelerator pedal fully releasedMore than 0.36V
[Ignition switch “ON”]
lGear position is "D" (A/T model)
lGear position is "1st" (M/T model)
lAccelerator pedal fully depressedLess than 4.75V
74 GThrottlepositionsen-
sor 2[Ignition switch "ON"]
lGear position is "D" (A/T model)
lGear position is "1st" (M/T model)
lAccelerator pedal fully releasedLess than 4.75V
[Ignition switch “ON”]
lGear position is "D" (A/T model)
lGear position is "1st" (M/T model)
lAccelerator pedal fully depressedMore than 0.36V TER-
MINAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
PBIB0527E
PBIB0528E

EC-432
[QR (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS
75 R/LAccelerator pedal
position sensor 1[Ignition switch "ON"]lAccelerator pedal fully released0.41 - 0.71V
[Ignition switch "ON"]
lAccelerator pedal fully depressedMore than 3.9V
76 B/WAccelerator pedal
position sensor 2[Ignition switch "ON"]
lAccelerator pedal fully released0.09 - 0.48V
[Ignition switch "ON"]
lAccelerator pedal fully depressedMore than 1.9V
80 B/PMass air flow sensor
ground[Engine is running]
lWarm-up condition
lIdle speedApproximately 0V
81 L/B Vehicle speed sensor[Engine is running]
lLift up the vehicle
lVehicle speed is 40 km/h (25MPH)Approximately 2.3V
82 W Knock sensor[Engine is running]
lIdle speedApproximately 2.5V
83 R/LRefrigerant pressure
sensor[Engine is running]
lWarm-up condition
lBoth A/C switch and blower switch are “ON”.
(Compressor operates.)1.0 - 4.0V
84 Y/GIntake air tempera-
ture sensor[Engine is running]Approximately 0 - 4.8V
Output voltage varies with intake
air temperature.
86 LAccelerator pedal
position sensor 2
ground[Ignition switch “ON”]Approximately 0V
90 WAccelerator pedal
position sensor sig-
nal output[Ignition switch "ON"]
lAccelerator pedal fully released0.41 - 0.71V
[Ignition switch “ON”]
lAccelerator pedal fully depressedMore than 3.9V
92 G/WHeated oxygen sen-
sor 1[Engine is running]
lWarm-up condition
lEngine speed is 2,000 rpm.0 - Approximately 1.0V (Periodi-
cally change)
93 BR/YEngine coolant tem-
perature sensor[Engine is running]Approximately 0 - 4.8V
Output voltage varies with
engine coolant temperature.
95 OR/BHeated oxygen sen-
sor 2[Engine is running]
lWarm-up condition
lEngine speed is 2,000 rpm.0 - Approximately 1.0V TER-
MINAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
PBIB0531E

TROUBLE DIAGNOSIS
EC-435
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
ENGINE CONTROL COMPONENT PARTS/CONTROL SYSTEMS APPLICATION
X: Applicable
*1: This item includes 1st trip DTCs.
*2: This mode includes 1st trip freeze frame data or freeze frame data. The items appear on CONSULT-II screen in freeze frame data
mode only if a 1st trip DTC or DTC is detected. For details, refer toEC-402
.
CONSULT-II INSPECTION PROCEDURE
1. Turn ignition switch OFF.
ItemDIAGNOSTIC TEST MODE
WORK
SUPPORTSELF-DIAGNOSTIC
RESULTS
DATA
MONI-
TORDATA
MONI-
TOR
(SPEC)ACTIVE
TEST
DTC*1FREEZE
FRAME
DATA*2
ENGINE CONTROL COMPONENT PARTS
INPUT
Crankshaft position sensor (POS)´´´´
Camshaft position sensor (PHASE)´
Mass air flow sensor´´´
Engine coolant temperature sensor´´´´´
Heated oxygen sensor 1´´´
Heated oxygen sensor 2´´
Wheel sensor (Vehicle speed signal)´´´´
Accelerator pedal position sensor´´´
Throttlepositionsensor´´´
Intake air temperature sensor´´
Knock sensor´
Refrigerant pressure sensor´´
Ignition switch (start signal)´´
Closed throttle position switch (accelera-
tor pedal position sensor signal)´´
Air conditioner switch´´
Park/neutral position (PNP) switch´´
Stop lamp switch´´´
Power steering pressure sensor´´´
Battery voltage´´
Load signal´´
ENGINE CONTROL COMPONENT PARTS
OUTPUT
Injectors´´ ´
Power transistor (Ignition timing)´´ ´
Throttle control motor relay´´´
EVAP canister purge volume control sole-
noid valve´´ ´
Air conditioner relay´´
Fuel pump relay´´´´
Cooling fan relay´´´´
Heated oxygen sensor 1 heater´´
Heated oxygen sensor 2 heater´´
Intake valve timing control solenoid valve´´ ´
Calculated load value´´´

TROUBLE DIAGNOSIS
EC-437
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
*: This function is not necessary in the usual service procedure.
SELF-DIAG RESULTS MODE
Self Diagnostic Item
Regarding items of “DTC and 1st trip DTC”, refer toEC-379, "INDEX FOR DTC".)
Freeze Frame Data and 1st Trip Freeze Frame Data
*1: The items are the same as those of 1st trip freeze frame data.SELF-LEARNING CONT
lTHE COEFFICIENT OF SELF-LEARNING CONTROL
MIXTURE RATIO RETURNS TO THE ORIGINAL COEF-
FICIENT.When releasing fuel pressure
from fuel line
TARGET IDLE RPM ADJ*
lIDLE CONDITION When setting target idle speed
TARGET IGNITION TIMING ADJ*
lIDLE CONDITION When adjusting target ignition tim-
ing
After adjustment, confirm target
ignition timing with a timing light. WORK ITEM CONDITION USAGE
Freeze frame data
item*1Description
DIAG TROUBLE
CODE
[PXXXX]
lThe engine control component part/control system has a trouble code, it is displayed as “PXXXX”. (Refer
toEC-379, "
INDEX FOR DTC".)
FUEL SYS-B1
l“Fuel injection system status” at the moment a malfunction is detected is displayed.
lOne mode in the following is displayed.
“MODE 2”: Open loop due to detected system malfunction
“MODE 3”: Open loop due to driving conditions (power enrichment, deceleration enrichment)
“MODE 4”: Closed loop - using oxygen sensor(s) as feedback for fuel control
“MODE 5”: Open loop - has not yet satisfied condition to go to closed loop
CAL/LD VALUE [%]
lThe calculated load value at the moment a malfunction is detected is displayed.
COOLANT TEMP [°C]
or [°F]
lThe engine coolant temperature at the moment a malfunction is detected is displayed.
S-FUEL TRIM-B1 [%]
l“Short-term fuel trim” at the moment a malfunction is detected is displayed.
lThe short-term fuel trim indicates dynamic or instantaneous feedback compensation to the base fuel
schedule.
L-FUEL TRIM-B1 [%]
l“Long-term fuel trim” at the moment a malfunction is detected is displayed.
lThe long-term fuel trim indicates much more gradual feedback compensation to the base fuel schedule
than short-term fuel trim.
ENGINE SPEED
[rpm]
lThe engine speed at the moment a malfunction is detected is displayed.
VHCL SPEED [km/h]
or [mph]
lThe vehicle speed at the moment a malfunction is detected is displayed.
B/FUEL SCHDL
[msec]
lThe base fuel schedule at the moment a malfunction is detected is displayed.
INT/ATEMPSE[°C]
or [°F]
lThe intake air temperature at the moment a malfunction is detected is displayed.

EC-438
[QR (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS
DATA MONITOR MODE
Monitored Item
´: Applicable
Monitored item
[Unit]ECM
INPUT
SIG-
NALSMAIN
SIG-
NALSCAN
DIAG
SUP-
PORT
MNTRDescription Remarks
ENG SPEED [rpm]´´
lIndicates the engine speed computed
from the signal of the crankshaft position
sensor (POS).
lAccuracy becomes poor if engine
speed drops below the idle rpm.
lIf the signal is interrupted while the
engine is running, an abnormal
value may be indicated.
MAS A/F SE-B1 [V]´´
lThe signal voltage of the mass air flow
sensor is displayed.lWhen the engine is stopped, a
certain value is indicated.
COOLAN TEMP/S
[°C] or [°F]´´
lThe engine coolant temperature (deter-
mined by the signal voltage of the
engine coolant temperature sensor) is
displayed.
lWhen the engine coolant tempera-
ture sensor is open or short-cir-
cuited, ECM enters fail-safe mode.
The engine coolant temperature
determined by the ECM is dis-
played.
HO2S1 (B1) [V]´´
lThe signal voltage of heated oxygen
sensor 1 is displayed.
HO2S2 (B1) [V]´´
lThe signal voltage of heated oxygen
sensor 2 is displayed.
HO2S1 MNTR (B1)
[RICH/LEAN]´´
lDisplay of heated oxygen sensor 1 sig-
nal during air-fuel ratio feedback control:
RICH ... means the mixture became
“rich”, and control is being affected
toward a leaner mixture.
LEAN ... means the mixture became
“lean”, and control is being affected
toward a rich mixture.lAfter turning ON the ignition
switch, “RICH” is displayed until
air-fuel mixture ratio feedback
control begins.
lWhen the air-fuel ratio feedback is
clamped, the value just before the
clamping is displayed continu-
ously.
HO2S2 MNTR (B1)
[RICH/LEAN]´
lDisplay of heated oxygen sensor 2 sig-
nal:
RICH ... means the amount of oxygen
after three way catalyst is relatively
small.
LEAN ... means the amount of oxygen
after three way catalyst is relatively
large.
lWhen the engine is stopped, a
certain value is indicated.
VHCL SPEED SE
[km/h] or [mph]´´
lThe vehicle speed computed from the
vehicle speed signal is displayed.
BATTERY VOLT
[V]´´
lThe power supply voltage of ECM is dis-
played.
ACCEL SEN 1 [V]´´
lThe accelerator pedal position sensor
signal voltage is displayed.
ACCEL SEN 2 [V]´
THRTL SEN 1 [V]´´
lThe throttle position sensor signal volt-
age is displayed.
THRTL SEN 2 [V]´
INT/ATEMPSE
[°C] or [°F]´´
lThe intake air temperature (determined
by the signal voltage of the intake air
temperature sensor) is indicated.
START SIGNAL
[ON/OFF]´´
lIndicates [ON/OFF] condition from the
starter signal.lAfter starting the engine, [OFF] is
displayed regardless of the starter
signal.

TROUBLE DIAGNOSIS
EC-439
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
CLSD THL POS
[ON/OFF]´´lIndicates idle position [ON/OFF] com-
puted by ECM according to the acceler-
ator pedal position sensor signal.
AIR COND SIG
[ON/OFF]´´
lIndicates [ON/OFF] condition of the air
conditioner switch as determined by the
air conditioner signal.
P/N POSI SW
[ON/OFF]´´
lIndicates [ON/OFF] condition from the
park/neutral position (PNP) switch sig-
nal.
PW/ST SIGNAL
[ON/OFF]´´
l[ON/OFF] condition of the power steer-
ing system (determined by the signal
voltage of the power steering pressure
sensor signal) is indicated.
LOAD SIGNAL
[ON/OFF]´´
lIndicates [ON/OFF] condition from the
electrical load signal.
ON ... Rear window defogger switch is
ON and/or lighting switch is in 2nd posi-
tion.
OFF ... Both rear window defogger
switch and lighting switch are OFF.
IGNITION SW
[ON/OFF]´´
lIndicates [ON/OFF] condition from igni-
tion switch.
HEATER FAN SW
[ON/OFF]´
lIndicates [ON/OFF] condition from the
heater fan switch signal.
BRAKE SW
[ON/OFF]´
lIndicates [ON/OFF] condition from the
stop lamp switch signal.
INJ PULSE-B1
[msec]´
lIndicates the actual fuel injection pulse
width compensated by ECM according
to the input signals.lWhen the engine is stopped, a
certain computed value is indi-
cated.
B/FUEL SCHDL
[msec]´
l“Base fuel schedule” indicates the fuel
injection pulse width programmed into
ECM, prior to any learned on board cor-
rection.
IGN TIMING
[BTDC]´
lIndicates the ignition timing computed
by ECM according to the input signals.lWhen the engine is stopped, a
certain value is indicated.
A/F ALPHA-B1 [%]´
lThe mean value of the air-fuel ratio
feedback correction factor per cycle is
indicated.
lWhen the engine is stopped, a
certain value is indicated.
lThis data also includes the data
for the air-fuel ratio learning con-
trol.
CAL/LD VALUE [%]
l“Calculated load value” indicates the
value of the current airflow divided by
peak airflow.
MASS AIRFLOW
[g·m/s]
lIndicates the mass airflow computed by
ECM according to the signal voltage of
the mass air flow sensor. Monitored item
[Unit]ECM
INPUT
SIG-
NALSMAIN
SIG-
NALSCAN
DIAG
SUP-
PORT
MNTRDescription Remarks

EC-440
[QR (WITHOUT EURO-OBD)]
TROUBLE DIAGNOSIS
PURG VOL C/V
[%]
lIndicates the EVAP canister purge vol-
ume control solenoid valve control value
computed by the ECM according to the
input signals.
lThe opening becomes larger as the
value increases.
INT/V TIM (B1)
[°CA]
lIndicates [°CA] of intake camshaft
advanced angle.
INT/V SOL (B1) [%]
lThe control condition of the intake valve
timing control solenoid valve (deter-
mined by ECM according to the input
signals) is indicated.
ON ... intake valve timing control is oper-
ating.
OFF ... Intake valve timing control is not
operating.
AIRCONDRLY
[ON/OFF]´
lThe air conditioner relay control condi-
tion (determined by ECM according to
the input signals) is indicated.
FUEL PUMP RLY
[ON/OFF]´
lIndicates the fuel pump relay control
condition determined by ECM according
to the input signals.
THRTL RELAY
[ON/OFF]
lIndicates the throttle control motor relay
control condition determined by the
ECM according to the input signals.
COOLING FAN
[HI/LOW/OFF]
lIndicates the condition of the cooling fan
(determined by ECM according to the
input signals).
HI ... High speed operation
LOW ... Low speed operation
OFF ... Stop
HO2S1 HTR (B1)
[ON/OFF]
lIndicates [ON/OFF] condition of heated
oxygen sensor 1 heater determined by
ECM according to the input signals.
HO2S2 HTR (B1)
[ON/OFF]
lIndicates [ON/OFF] condition of heated
oxygen sensor 2 heater determined by
ECM according to the input signals.
IDL A/V LEARN
[YET/CMPLT/
INCMP]
lDisplay the condition of idle air volume
learning
YET ... Idle air volume learning has not
been performed yet.
CMPLT ... Idle air volume learning has
already been performed successfully.
INCMP ... Idle air volume learning has
not been performed successfully.
TRVL AFTER MIL
[km] or [mile]
lDistance traveled while MI is activated.
AC PRESS SEN
[V]
lThe signal voltage from the refrigerant
pressure sensor is displayed. Monitored item
[Unit]ECM
INPUT
SIG-
NALSMAIN
SIG-
NALSCAN
DIAG
SUP-
PORT
MNTRDescription Remarks

TROUBLE DIAGNOSIS
EC-441
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
NOTE:
lAny monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.
DATA MONITOR (SPEC) MODE
Monitored Item
NOTE:
lAny monitored item that does not match the vehicle being diagnosed is deleted from the display automatically. Voltage [V]
lVoltage, frequency, duty cycle or pulse
width measured by the probe.
lOnly “#” is displayed if item is
unable to be measured.
lFigures with “#”s are temporary
ones. They are the same figures
as an actual piece of data which
was just previously measured. Frequency
[msec], [Hz] or [%]
DUTY-HI
DUTY-LOW
PLS WIDTH-HI
PLS WIDTH-LOW
CAN COMM
[OK/NG]´
lIndicates the communication condition
of CAN communication line.lThese items are not displayed in
"SELECTION FROM MENU"
mode. CANCIRC1
[OK/UNKWN]´
CANCIRC2
[OK/UNKWN]´
CANCIRC3
[OK/UNKWN]´
CANCIRC4
[OK/UNKWN]´
CANCIRC5
[OK/UNKWN]´ Monitored item
[Unit]ECM
INPUT
SIG-
NALSMAIN
SIG-
NALSCAN
DIAG
SUP-
PORT
MNTRDescription Remarks
Monitored item [Unit]ECM
input
signalsMain
signalsDescription Remarks
ENG SPEED [rpm]´
lIndicates the engine speed computed
from the signal of the crankshaft position
sensor (POS).
MAS A/F SE-B1 [V]´´
lThe signal voltage of the mass air flow
sensor specification is displayed.lWhen engine is running specification
range is indicated.
B/FUEL SCHDL
[msec]
l“Base fuel schedule” indicates the fuel
injection pulse width programmed into
ECM, prior to any learned on board cor-
rection.
lWhen engine is running specification
range is indicated.
A/F ALPHA-B1 [%]´
lThe mean value of the air-fuel ratio feed-
back correction factor per cycle is indi-
cated.lWhen engine is running specification
range is indicated.
lThis data also includes the data for the
air-fuel ratio learning control.
