REAR DISC BRAKE
BR-37
C
D
E
G
H
I
J
K
L
MA
B
BR

INSPECTION AFTER DISASSEMBLY
Cylinder Body
CAUTION:
Use new brake fluid to clean. Do not use mineral oils such as gasoline or kerosene.

Check inside surface of cylinder for score, rust wear, damage or foreign materials. If any of the above con-
ditions are observed, replace cylinder body.

Minor damage from rust or foreign materials may be eliminated by polishing surface with a fine emery
paper. Replace cylinder body if necessary.
To r q u e M e m b e r
Check for wear, cracks, and damage. If damage or deformation is present, replace torque member.
Piston
CAUTION:

Piston sliding surface is plated, do not polish with emery paper even if rust of foreign materials
are stuck to sliding surface.

Check piston for score, rust, wear, damage or presence of foreign materials. Replace if any of the
above condition are observed.
Sliding Pin Bolts and Sliding Pin Boots
Check sliding pin bolts and sliding pin boots, for wear, damage and cracks. If damage or deformation is
present, replace the applicable part.
ASSEMBLY
1. Apply polyglycol ether based lubricant to piston seal, and install
them to cylinder body.
CAUTION:
Do not reuse piston seal.
2. Apply rubber grease to piston boot. Cover piston end with piston
boot, and install cylinder side lip on piston boot properly into the
groove on cylinder body.
CAUTION:
Do not reuse piston boot.
3. Apply brake fluid to piston, and press piston into cylinder body
by hand to assemble piston side lip on piston boot properly into
groove on piston.
CAUTION:
Press piston evenly and vary the pressing point to prevent
cylinder inner wall from being rubbed.
SFIA2278E
SFIA2498E
SFIA2279E

BR-38
REAR DISC BRAKE

4. Fix piston boot with retaining ring.
CAUTION:

Make sure boot is firmly in cylinder body groove on.

Do not reuse retainer ring.
5. Apply PBC (Poly Butyl Cuprysil) grease or silicone-based
grease to between shim and shim cover. Install inner shim, inner
shim cover to inner pad, and outer shim, outer shim cover to
outer pad.
6. Install pad retainers and, inner pad assembly and outer pad
assembly to torque member.
CAUTION:
Securely assemble pad retainer so that it is not being lifted
up from torque member.
7. Install sliding pin boot to torque member.
8. Press in piston until pads can be installed, and then install cylin-
der body to torque member. Use a disc brake piston tool (commercial service tool) to easily press piston
in.
9. Install cylinder body to torque member, and then tighten sliding pin bolt to the specified torque. Refer to
BR-33, "
Components" .
SFIA2280E
PFIA0273E

FAX-1
FRONT AXLE
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION FA X
A
B
FA X

FRONT AXLE
PRECAUTIONS .......................................................... 2
Caution ..................................................................... 2
PREPARATION ........................................................... 3
Special Service Tools ............................................... 3
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 4
NVH Troubleshooting Chart ..................................... 4
FRONT WHEEL HUB AND KNUCKLE ...................... 5
On-Vehicle Inspection .............................................. 5
WHEEL BEARING INSPECTION ......................... 5
Removal and Installation .......................................... 5
COMPONENT ....................................................... 5
REMOVAL ............................................................. 5
INSPECTION AFTER REMOVAL ......................... 6
INSTALLATION ..................................................... 7
FRONT DRIVE SHAFT ............................................... 8
On-Vehicle Inspection .............................................. 8
DRIVE SHAFT BOOT REPLACEMENT ............... 8
Removal and Installation (LH) ................................. 11
COMPONENT ...................................................... 11
REMOVAL ............................................................ 11
INSPECTION AFTER REMOVAL ....................... 12
INSTALLATION ................................................... 12
Removal and Installation (RH) ............................... 13
COMPONENT ..................................................... 13
REMOVAL ........................................................... 13
INSPECTION AFTER REMOVAL ....................... 14
INSTALLATION ................................................... 14Disassembly and Assembly (Models With VQ23DE:
LH) .......................................................................... 15
COMPONENT ..................................................... 15
DISASSEMBLY ................................................... 15
INSPECTION AFTER DISASSEMBLY ................ 16
ASSEMBLY ......................................................... 17
Disassembly and Assembly (Models With VQ35DE
and QR20DE: LH) .................................................. 19
COMPONENT ..................................................... 19
DISASSEMBLY ................................................... 19
INSPECTION AFTER DISASSEMBLY ................ 20
ASSEMBLY ......................................................... 20
Disassembly and Assembly (Models With VQ23DE:
RH) ......................................................................... 22
COMPONENT ..................................................... 22
DISASSEMBLY ................................................... 22
INSPECTION AFTER DISASSEMBLY ................ 24
ASSEMBLY ......................................................... 25
Disassembly and Assembly (Models With VQ35DE
and QR20DE: RH) .................................................. 28
COMPONENT ..................................................... 28
DISASSEMBLY ................................................... 28
INSPECTION AFTER DISASSEMBLY ................ 30
ASSEMBLY ......................................................... 30
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 34
Wheel Bearing ........................................................ 34
Drive Shaft .............................................................. 34
Dynamic Damper .................................................... 34

PREPARATION
FAX-3
C
E
F
G
H
I
J
K
L
MA
B
FA X

PREPARATIONPFP:00002
Special Service Tools BDS0007H
Tool number
Tool nameDescription
HT72520000
Ball joint remover
a: 33 mm (1.30 in)
b: 50 mm (1.97 in)
r: 11.5 mm (0.453 in)Removing steering outer socket
KV40107300
Boot band crimping toolInstalling boot band
KV40107500
Drive shaft attachmentRemoving drive shaft
KV38105500
Protector
a: 32 mm (1.26 in) dia.Installing drive shaft
ST17130000
Drift
a: 32 mm (1.26 in) dia.
b: 60 mm (2.36 in) dia.Removing support bearing
ST35271000
Drift
a: 72 mm (2.83 in) dia.
b: 63 mm (2.48 in) dia.Installing support bearing
ST33252000
Drift
a: 82 mm(3.23 in) dia.
b: 60 mm (2.36 in) dia.Installing support bearing
NT546
ZZA1229D
ZZA1230D
ZZA0835D
ZZA0836D
ZZA0837D
ZZA0838D

FAX-6
FRONT WHEEL HUB AND KNUCKLE

7. Separate wheel hub and bearing assembly from drive shaft by
lightly tapping the end with a hammer (suitable tool) and a wood
block, and then remove hub lock nut. Remove wheel hub and
bearing assembly.
CAUTION:

Do not place drive shaft joint at an extreme angle. Also be
careful not to overextend slide joint.

Do not allow drive shaft to hang down without support for
housing (or joint sub-assembly), shaft and the other
parts.
NOTE:
Use a puller (suitable tool) if wheel hub and bearing assembly
and drive shaft cannot be separated even after performing the above procedure.
8. Remove splash guard from steering knuckle.
9. Remove cotter pin of steering outer socket and steering knuckle,
and then loosen nut. Refer to PS-17, "
COMPONENTS" .
10. Remove steering outer socket from steering knuckle so as not to
damage ball joint boot using the ball joint remover [SST].
CAUTION:
Temporarily tighten the nut to prevent damage to threads
and to prevent ball joint remover [SST] from suddenly com-
ing off.
11. Remove nut and bolt, and then remove steering knuckle from
transverse link.
12. Remove fixing nuts and bolts, and then remove steering knuckle
from strut assembly. Refer to FSU-7, "
Components" .
13. Remove stopper bolt from steering knuckle.
INSPECTION AFTER REMOVAL
Check components for deformation, cracks, and other damage. Replace if there are.
Ball Joint Inspection
Check boots of transverse link and steering outer socket ball joint for breakage, axial play, and torque. Refer to
FSU-14, "
INSPECTION AFTER REMOVAL" , “TRANSVERSE LINK”, PS-23, "INSPECTION AFTER DISAS-
SEMBLY" , “STEERING GEAR AND LINKAGE”.
SDIA1821E
SDIA2637E
SGIA0725E
SEIA0411J

FAX-8
FRONT DRIVE SHAFT

FRONT DRIVE SHAFTPFP:39100
On-Vehicle InspectionBDS0007M

Check drive shaft mounting point and joint for looseness and other damage.

Check boot for cracks and other damage.
CAUTION:
Replace entire drive shaft assembly when noise or vibration occur from drive shaft.
DRIVE SHAFT BOOT REPLACEMENT
1. Remove tires from vehicle.
2. Remove wheel sensor from steering knuckle. Refer to BRC-33, "
WHEEL SENSORS" .
CAUTION:
Do not pull on wheel sensor harness.
3. Remove torque member fixing bolts. Hang torque member in a place where it will not interfere with work.
Refer to BR-26, "
FRONT DISC BRAKE" .
NOTE:
Do not depress brake pedal while brake caliper is removed.
4. Remove disc rotor. Refer to FA X - 5 , "
Removal and Installation" .
5. Remove cotter pin, then loosen hub lock nut.
6. Separate wheel hub and bearing assembly from drive shaft by
lightly tapping the end with hammer (suitable tool) and a wood
block, and then remove hub lock nut.
CAUTION:

Do not place drive shaft joint at an extreme angle. Also be
careful not to overextend slide joint.

Do not allow drive shaft to hang down without support for
housing (or joint sub-assembly), shaft and the other
parts.
NOTE:
Use a puller (suitable tool) if wheel hub and drive shaft cannot
be separated even after performing the above procedure.
7. Remove fixing nuts and bolts, and then remove steering knuckle
from strut assembly. Refer to FSU-7, "
Components" .
8. Remove drive shaft from wheel hub and bearing assembly.
9. Remove boot bands, and then remove boot from joint sub-
assembly.
10. Screw a drive shaft puller (suitable tool) into joint sub-assembly
screw part to a length of 30 mm (1.18 in) or more. Support drive
shaft with one hand and pull out joint sub-assembly with a slid-
ing hammer (suitable tool) from shaft.
CAUTION:

Align a sliding hammer and drive shaft and remove them
by pulling firmly and uniformly.

If joint sub-assembly cannot be pulled out, try after
removing drive shaft from vehicle.
SDIA1821E
SEIA0411J
SDIA0881J

FRONT DRIVE SHAFT
FAX-9
C
E
F
G
H
I
J
K
L
MA
B
FA X

11. Remove circular clip from shaft.
12. Remove boot from shaft.
13. Clean the old grease on joint sub-assembly with paper towels.
14. Apply the appropriate amount of grease (NISSAN genuine
grease or equivalent) inside joint sub-assembly serration hole
until grease begins to ooze from ball groove and serration hole.
After inserting grease, use a shop cloth to wipe off old grease
that has oozed out.
15. Wrap serration on shaft with tape to protect boot from damage.
Install new boot and boot bands to shaft.
NOTE:
Do not reuse boot bands and boot.
16. Remove the tape wrapped around the serration on shaft.
17. Position circular clip on groove at shaft edge. Align both counter
axles of shaft edge and joint sub-assembly. Then, assemble
shaft with circular clip onto joint sub-assembly.
NOTE:

Do not reuse circular clip.

Drive joint inserter (suitable tool) is recommended when
installing circular clip.
18. Install joint sub-assembly to shaft using plastic hammer.
CAUTION:
Confirm that joint sub-assembly is correctly engaged while
rotating drive shaft.
19. Apply the balance of the specified amount of grease (NISSAN
genuine grease or equivalent) into boot inside from large diame-
ter side of boot.
SDIA2489E
SDIA2775E
SDIA2490E
Engine model Grease amount
QR20DE
88 – 108 g (3.10 – 3.80 oz)
VQ23DE
VQ35DE 115 – 125 g (4.06 – 4.41 oz)
SDIA2372E

FAX-10
FRONT DRIVE SHAFT

20. Install boot securely into grooves (indicated by *marks) shown in
the figure.
CAUTION:
If there is grease on boot mounting surfaces (indicated by *
marks) of shaft and housing, boot may come off. Remove
all grease from surfaces.
21. Make sure boot installation length “L” is the length indicated
below. Insert flat-bladed screwdriver or similar tool into smaller
side of boot. bleed air from boot to prevent boot deformation.
CAUTION:

Boot may break if boot installation length is less then standard value.

Take care not to touch the tip of screwdriver to inside of boot.
22. Secure the large and small ends of boot with new boot bands
using boot band crimping tool [SST: KV40107300] as shown in
the figure.
NOTE:

Do not reuse boot bands.

Secure boot band so that dimension “M” meets the specifica-
tion as shown.
23. Secure joint sub-assembly and shaft, and then make sure that
they are in the correct position when rotating boot. Install them
with new boot band when boot installation positions become
incorrect.
24. Confirm that circular clip on transaxle side is fully engaged.
25. Insert drive shaft to wheel hub and bearing assembly, and then
temporarily tighten hub lock nut.
26. Install nuts and bolts of steering knuckle and strut. Refer to FSU-7, "
Components" , “FRONT SUSPEN-
SION ASSEMBLY” for tightening torque.
27. Install disc rotor. Refer to FAX-5, "
Removal and Installation" .
28. Install torque member fixing bolts to steering knuckle. Refer to BR-26, "
FRONT DISC BRAKE" .
29. Install wheel sensor to steering knuckle. Refer to BRC-33, "
WHEEL SENSORS" .
30. Tighten lock nut to the specified torque. Refer to FA X - 11 , "
COMPONENT"
31. Install cotter pin.
NOTE:
Do not reuse cotter pin.
32. Install tires to vehicle.Engine model Boot installation length L
QR20DE
141.7 – 143.7 mm (5.58 – 5.66 in)
VQ23DE
VQ35DE 155.3 – 161.3 mm (6.11 – 6.35 in)
SDIA1760E
RAC1133D
Dimension “M” : 2.0 – 3.0 mm (0.079 – 0.118 in)
DSF0047D
